Using the control panel

1. Cycle Selector
Select the tumble pattern and spin speed for the cycle.
For more information on each cycle, refer to the "Using the Cycle Selector" section on page 26.
2. Digital graphic display
Displays the remaining wash cycle time, all cycle information, and error codes.
3. Temp.
button
Press this button repeatedly to cycle through the available water temperature options:
Cold water
, 20 ˚C, 30 ˚C, 40 ˚C , 60 ˚C and 95 ˚C
4. Rinse
button
Press this button to add additional rinse cycles. The maximum number of rinse cycles is five.
5. Spin
button
Press the button repeatedly to cycle through the available speeds for the spin cycle.
WF80F7E3P6*, WF80F7E3U6*, WF80F7E6P6*,
WF90F7E6P6*, WF90F7E6U6*
Rinse Hold: The laundry remains soaking in the final rinse water. Either a drain or spin cycle must be
performed to unload the laundry.
No spin: The laundry remains in the drum and no spin cycle is performed after the final drain.
6. Option
button
Press this button repeatedly to cycle through the options:
Soak > Intensive > Prewash > Soak + Intensive > Soak + Prewash > Intensive + Prewash > Soak + Intensive +
Prewash > off
Soak: Use this function to effectively remove stains from your laundry by soaking your laundry.
The Soak function is performed 13 minutes into the wash cycle.
The Soak function operates for 30 minutes with six cycles, where one cycle is a soak cycle that
spins for 1 minute and stands still for 4 minutes.
The Soak function is only available with the: Cotton
Daily Wash
Intensive: Use this function when the laundry is heavily soiled and needs to be washed intensively.
The cycle time is increased for each cycle.
Prewash: Use this function to prewash your laundry before the main wash cycle. The Prewash
function is only available with the Cotton
Garment
F700_WF80F7E-03245A-02_EN.indd 24
1
2
3
, Super Eco Wash
and Baby Care cycles.
, Daily Wash
, Super Eco Wash
English - 24
4
5
6
7
8
,
, 400, 800, 1200, 1400, 1600 rpm
, Synthetics
, Denim,
, Synthetics
, Denim
, Stain Away
and Baby Care
cycles.
9 10
11
12
13
Stain Away
,
, Dark
2013-9-24 11:17:35
