F500E-03439A-06_EN.indd 1
Washing machine
User manual
imagine the possibilities
Thank you for purchasing this Samsung product.
WF80F5*****
WF70F5*****
WF60F4*****
2016-08-23
1:59:34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF60F4 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung WF60F4 Series

Summary of Contents for Samsung WF60F4 Series

  • Page 1 WF80F5***** WF70F5***** WF60F4***** Washing machine User manual imagine the possibilities Thank you for purchasing this Samsung product. F500E-03439A-06_EN.indd 1 2016-08-23 1:59:34...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols What the icons and signs in this user manual mean: ..........4 Important safety precautions Instructions about the WEEE Setting up your washing machine...
  • Page 3 Cleaning your washing machine Draining the washing machine in an emergency Cleaning the debris filter Cleaning the exterior Cleaning the detergent drawer and drawer recess Cleaning the mesh filter Maintaining your washing machine Repairing a frozen washing machine Storing your washing machine Troubleshooting and information codes Checkpoints Information codes...

  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washing machine’s many benefits and features.

  • Page 5: Important Safety Precautions

    Important safety precautions WARNING: To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 6 WARNING: Critical installation WARNINGS The installation of this appliance must be performed by a qualified technician or service company. • Failure to do so may result in electric shock, fire, an explosion, problems with the product, or injury. The appliance is heavy, therefore take care when lifting it. Plug the power cord into a wall socket that meets local electrical specifications.
  • Page 7 CAUTION: Installation CAUTIONS This appliance should be positioned in such a way that the power plug is easily accessible. • Failure to do so may result in electric shock or fire due to electric leakage. Install your appliance on a solid, level floor that can support its weight. •...
  • Page 8 • Failure to do so may result in electric shock or fire. If any foreign substance enters into the appliance, unplug the power plug and contact you nearest Samsung Customer Service. • This may result in electric shock or fire.
  • Page 9 Do not stand on the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. • This may result in electric shock, fire, problems with the product, or injury. Do not spray volatile material such as insecticide onto the surface of the appliance. •...

  • Page 10: Instructions About The Weee

    Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH visit: samsung.com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/data_corner.html English - 10 F500E-03439A-06_EN.indd 10...

  • Page 11: Setting Up Your Washing Machine

    Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping or if you do not have all of the parts, contact the Samsung Customer Service or your Samsung dealer.

  • Page 12: Meeting The Installation Requirements

    Meeting the installation requirements Electrical supply and grounding WARNING: Never use an extension cord. Use only the power cord that comes with your washing machine. When preparing the installation, ensure that your power supply offers: • An AC 220 - 240 V / 50 Hz fuse or circuit breaker •...

  • Page 13: Drain

    Drain Samsung recommends a standpipe height of 65 cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory.

  • Page 14: Installing Your Washing Machine

    Installing your washing machine CAUTION: Do not plug the power cord into a wall socket before the installation is complete. WARNING: Packaging materials can be dangerous to children; keep all packaging material (plastic bags, polystyrene, etc.) well out of the reach of children. STEP 1 - Selecting a location Before you install the washing machine, make sure the location: •...

  • Page 15: Step 3 - Adjusting The Levelling Feet

    STEP 3 - Adjusting the levelling feet When installing your washing machine, ensure that the power plug, the water supply, and the drain are easily accessible. 1. Slide the washing machine into position. 2. Loosen all the lock nuts with the wrench. 3.
  • Page 16 3. First, loosen the four screws on the adaptor using a '+’ type part (D) part (E) screwdriver. Next, hold and turn following the arrow until there is a 5 mm gap. (*): 5 mm 4. Connect the adaptor to the water tap by tightening all the screws firmly while lifting the adaptor upwards.

  • Page 17: Connecting The Drain Hose

    Connecting the hot water supply hose (selected models) 1. Connect the red L-shaped arm fitting (A) for the hot water supply hose to the hot water supply intake at the back of the machine. Then tighten it by hand. 2. Connect the other end of the hot water supply hose to your sink’s hot water tap in the same way as you connected the cold water supply hose.
  • Page 18 STEP 6 - Running Calibration Mode Your Samsung washing machine detects the weight of the laundry automatically. For a more accurate weight detection, it is recommended running Calibration Mode immediately after installing the washing machine. Follow the steps below to run Calibration Mode.

  • Page 19: Using Your Washing Machine

    Using your washing machine With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash first. Detergent and Additives Information Using the proper detergent The type of detergent you should use is based on the type of fabric (cotton, synthetic, delicate items, wool), colour, wash temperature, and degree of soiling.
  • Page 20 1. Pull out the detergent drawer at the top left of the washing machine. 2. Add the recommended amount of laundry detergent into the main wash detergent compartment before starting your washing machine. To use liquid detergent, use the liquid detergent guide (refer to the "Using liquid detergent (selected models)"...

  • Page 21: Laundry Capsules

    Laundry capsules To get the best results from using laundry capsules, please follow these instructions. 1. Put the capsule in the bottom of the empty drum towards the rear. 2. Put the laundry in the drum on top of the capsule. CAUTION: For cycles using cold water or cycles that complete in less than one hour, it is recommended to use a liquid detergent.

  • Page 22: Doing Laundry For The First Time

    Doing laundry for the first time Before doing laundry for the first time, you must run a complete empty cycle (i.e. without laundry). 1. Press the Power button. 2. Add a little detergent to the main wash compartment in the detergent drawer. 3.

  • Page 23: Using The Control Panel

    Using the control panel 1. Cycle Selector Select the tumble pattern and spin speed for the cycle. For more information on each cycle, refer to the "Using the Cycle Selector" section on page 25. 2. Digital graphic display Displays the remaining wash cycle time, all cycle information, and error messages. 3.
  • Page 24 5. Options button Press this button repeatedly to cycle through the options: Soak > Intensive > Prewash > Rinse+ > Soak + Rinse+ > Intensive + Rinse+ > Prewash + Rinse+ > off Soak: Use this function to effectively remove stains from your laundry by soaking your laundry. •...

  • Page 25: Using The Cycle Selector

    Using the Cycle Selector Cycle Usage For averagely or lightly soiled cottons, bed linen, table linen, underwear, towels, shirts, etc. For bedding or bedding covers, the recommended spin cycle speed is 800 rpm (for COTTON a load of 2.0 kg or less). 6 kg-class models do not have a function for washing bedding.

  • Page 26: Child Lock

    Child Lock The Child Lock function allows you to lock the buttons so that the wash cycle you’ve chosen can’t be changed. Activating/Deactivating If you want to activate or deactivate the Child Lock function, hold down the Temp. and Spin buttons at the same time for 3 seconds. The "Child Lock "...

  • Page 27: Smart Check

    The Smart Check function has been optimized for Galaxy & iPhone series (applicable models only). Downloading the Samsung Smart Washer app Download the Samsung Smart Washer app to your mobile phone from the Android market or Apple App store and install it. You can easily find it by searching for "Samsung Smart Washer".

  • Page 28: Doing Laundry

    Doing laundry Doing laundry using the Cycle Selector Your new washing machine makes washing laundry easy, using Samsung’s automatic control system "Fuzzy Control". When you select a wash cycle, the machine will set the correct temperature, washing time, and washing speed.

  • Page 29: Doing Laundry Manually

    Doing laundry manually You can do laundry manually without using the Cycle Selector. 1. Turn the water supply on. 2. Press the Power button to turn the power on. 3. Open the door. 4. Add your laundry loosely into the drum without overfilling it. 5.
  • Page 30 Determining the load capacity Do not overload the washing machine or your laundry may not wash properly. Use the chart below to determine the load capacity for the type of laundry you are washing. Load Capacity (kg) Fabric Type WF80F5E WF70F5E WF60F4E COTTON...

  • Page 31: Cleaning Your Washing Machine

    Cleaning your washing machine Keeping your washing machine clean improves its performance, wards off unnecessary repairs, and lengthens its life. Draining the washing machine in an emergency If there is a power outage, drain all remaining water before removing your laundry. 1.

  • Page 32: Cleaning The Debris Filter

    Cleaning the debris filter We recommend cleaning the debris filter 5 or 6 times a year, or when the "5E" error message is displayed. If foreign substances accumulate at the debris filter, the performance of the Eco Bubble function will be degraded.

  • Page 33: Cleaning The Detergent Drawer And Drawer Recess

    Cleaning the detergent drawer and drawer recess 1. Press the release lever (A) on the inside of the detergent drawer and pull the detergent drawer out. 2. Remove the release lever (A) and the liquid detergent guide (optional) from the detergent drawer. 3.

  • Page 34: Maintaining Your Washing Machine

    Maintaining your washing machine Repairing a frozen washing machine If the temperature drops below freezing and your washing machine is frozen: 1. Unplug the washing machine from the electrical outlet. 2. Pour warm water over the water tap to loosen the water supply hose. 3.

  • Page 35: Troubleshooting And Information Codes

    Troubleshooting and information codes Checkpoints If you encounter a problem with the washing machine, first check the table below and try the suggestions. PROBLEM ACTION • Make sure the washing machine is plugged in. • Make sure the door is properly closed. •...
  • Page 36 PROBLEM ACTION • Make sure the drain hose is straightened all the way to the drain system. If you encounter a drain restriction, call for service. • Make sure the debris filter is not clogged. Close the door and press or tap Start/Pause. For your safety, the •...
  • Page 37 PROBLEM ACTION • Fully open both taps. • Make sure the temperature selection is correct. • Make sure the hoses are connected to the correct taps. Flush water lines. • Make sure the water heater is set to supply a minimum 120 °F (49 °C) hot water at the tap.

  • Page 38: Information Codes

    "UE" error message will be shown in the display window. • Call customer service. cE/3E/Uc For any codes not listed above, or if the suggested solution doesn’t fix the problem, call your Samsung Service Centre or local Samsung dealer. English - 38 F500E-03439A-06_EN.indd 38 2016-08-23...

  • Page 39: Cycle Chart

    Cycle chart Cycle chart ( user option) Spin Speed (MAX) Max load (kg) DETERGENT Max Temp PROGRAM (˚C) WF80F5 WF70F5 WF60F4 Prewash Wash Softener 1400 1200 1000 COTTON 1400 1200 1000 SYNTHETICS 1200 1200 1000 15’ QUICK WASH BABY CARE 1400 1200 1000...

  • Page 40: Fabric Care Chart

    Appendix Fabric care chart The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing (and dry cleaning when necessary). The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow the care label directions to maximize garment life and reduce laundery problems.

  • Page 41: Sheet Of Household Washing Machines

    (A) re 1 pW Dimensions Height Unit dimensions Width Depth Net weight Gross weight Package weight Water Pressure 50–800 Electrical connection Voltage 220–240 Power consumption 2000–2400 Frequency Name of company Samsung Electronics Co., Ltd. English - 41 F500E-03439A-06_EN.indd 41 2016-08-23 1:59:48...
  • Page 42 (A) re 1 pW Dimensions Height Unit dimensions Width Depth Net weight Gross weight Package weight Water Pressure 50–800 Electrical connection Voltage 220–240 Power consumption 2000–2400 Frequency Name of company Samsung Electronics Co., Ltd. English - 42 F500E-03439A-06_EN.indd 42 2016-08-23 1:59:48...
  • Page 43 (A) re 1 pW Dimensions Height Unit dimensions Width Depth Net weight Gross weight Package weight Water Pressure 50–800 Electrical connection Voltage 220–240 Power consumption 2000–2400 Frequency Name of company Samsung Electronics Co., Ltd. English - 43 F500E-03439A-06_EN.indd 43 2016-08-23 1:59:48...

  • Page 44: Information Of Main Washing Programmes

    1. Annual energy consumption is based on 220 standard washing cycles for COTTON programs at 60 °C and 40 °C at full and partial load, and the consumption of off and left-on modes. Actual energy consumption will depend on how the appliance is used. 2.
  • Page 45 Memo F500E-03439A-06_EN.indd 45 2016-08-23 1:59:48...
  • Page 46 Memo F500E-03439A-06_EN.indd 46 2016-08-23 1:59:48...
  • Page 47 Memo F500E-03439A-06_EN.indd 47 2016-08-23 1:59:48...
  • Page 48 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 0330 SAMSUNG (7267864) www.samsung.com/uk/support EIRE 0818 717100 www.samsung.com/ie/support DC68-03439A-06 F500E-03439A-06_EN.indd 48 2016-08-23 1:59:48...
