Installation
Link Wireless Telephone System
Link 3000 MCU
Part Number: 72-0059-01
Issue H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Link 3000 MCU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SpectraLink Link 3000 MCU

Summary of Contents for SpectraLink Link 3000 MCU

  • Page 1 Installation Link Wireless Telephone System Link 3000 MCU Part Number: 72-0059-01 Issue H...
  • Page 2 No representation or other affirmation of fact contained in this document including but not limited to statements regarding capacity, response-time performance, suitability for use, or performance of products described herein shall be deemed to be a warranty by SpectraLink for any purpose, or give rise to any liability of SpectraLink whatsoever.
  • Page 3 Note concerning shielded cable: SpectraLink recommends the use of shielded cable for all external signal connections in order to maintain FCC Part 15 emissions requirements. Note concerning the Wireless Telephone and Base Stations: This device complies with Part 15 of the FCC Rules.
  • Page 4 SpectraLink Corporation Installation Link WTS – Link 3000 MCU UL Information This symbol on the nameplate means the product is listed by Underwriter’s Laboratories, Inc. It is designed and manufactured to meet rigid U.L. safety standards against X-radiation, fire, casualty, and electrical hazards.

  • Page 5: Fcc Information

    You will be informed of your right to file a complaint with the FCC. If you experience trouble with this telephone equipment, please contact SpectraLink Corporation for information on obtaining service or repairs.
  • Page 6 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Industry Canada (IC) Notice Notice: The Industry Canada (IC) label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational, and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The department does not guarantee the equipment will operate to the user’s satisfaction.

  • Page 7: Table Of Contents

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU Table of Contents 1. ABOUT THIS DOCUMENT 1.1. Contacting SpectraLink 1.2. Icons Used in this Document 1.3. Installation Overview 2. LINK WIRELESS TELEPHONE SYSTEM DESCRIPTION 2.1. The Master Control Unit 2.2. Base Stations 2.3.
  • Page 8 SpectraLink Corporation Installation Link WTS – Link 3000 MCU 5.3. Install Outdoor Base Stations 5.4. Power Up and Check Diagnostics 6. SYSTEM INITIALIZATION 7. TEST SYSTEM 7.1. Voice-test each Base Station 7.2. Run Listen-Verify Diagnostic 8. SITE CERTIFICATION 9. INSTALLATION FORMS 9.1.

  • Page 9: About This Document

    Link WTS – Link 3000 MCU 1. About This Document This document explains installation and operation of the SpectraLink Link 3000 MCU and Base Stations. The installation process connects the Link Wireless Telephone System (Link WTS) to the facility’s telephone system, and activates the Wireless Telephones.
  • Page 10 SpectraLink Corporation Installation Link WTS – Link 3000 MCU The following table lists the installation steps and the person typically responsible for each step. Wire Customer Task Contractor Project Installer Description Mgr/ Sys Electrician Admin Site Preparation Required materials provided by customer...

  • Page 11: Link Wireless Telephone System Description

    As a Wireless Phone user moves within the coverage area the call is seamlessly passed between cells. The Link 3000 MCU supports up to 3,200 users and millions of square feet of coverage, resulting in a scalable enterprise-wide wireless voice solution.

  • Page 12: The Master Control Unit

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 2.1. The Master Control Unit The Master Control Unit (MCU) is the processing center for calls to and from the Wireless Telephone system. It consists of at least one primary shelf (MCS300) and may have up to 19 expansion shelves.
  • Page 13 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Shelf 2 - Expansion Shelf Shelf 1 - Primary Shelf Intershelf Junction Panel Shelf 3 - Expansion Shelf Shelf 20 - Expansion Shelf Link 3000 MCU - Star Topology Part Number: 72-0059-01-Ha.doc...
  • Page 14 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Shelf Shelves are designed for 19 inch rack or wall mounting. Each shelf has 12 universal card slots. The first two slots are reserved for controller cards, the remaining ten slots are for Interface Modules. Wiring to each card is on the front panel.

  • Page 15: Base Stations

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU connects the network, converting RJ-21 connections from the System Controller to the RJ-45 connection on the Shelf Controller. 2.2. Base Stations Radio Base Stations,or cells, provide the communication channel between the MCU and the Wireless Telephone.

  • Page 16: Link Wireless Telephones

    The system uses a proprietary software program for administration and maintenance. The software is loaded to the Operator’s Console, an IBM-compatible personal computer, located close to the Link 3000 MCU. The PC is used to register each Wireless Telephone and Base Station, enter user information, monitor system operations, and initiate remote diagnostics.

  • Page 17: Site Preparation

    An IBM-compatible PC is available to serve as the Operator’s Console for system administration. A system administrator is designated for the SpectraLink system. This person should be present for the installation. The SpectraLink installer will provide system training to the system administrator on the day following the installation.
  • Page 18 – Required with an RCO400 Outdoor Base Station or when a Base Quick Clip Fuse Station is located in a separate building from the Link 3000 MCU. Recommended Quick Clip Fuse is available from Reliable Electric, Model # RSCP-2. •...

  • Page 19: Prepare Location For Shelves

    Perform or direct the receiving and shipping of components Train users with video and handouts The system administrator should be available for training at the time of the SpectraLink installation. The system administrator is given unlimited access to the SpectraLink 800 customer support line for additional assistance.

  • Page 20: Rack Mounting

    Prepare Rack or Wall The Link 3000 MCU can be mounted in a rack or on the wall. Rack or wall support must be adequate to support the number of shelves to be installed. Each fully loaded Link 3000 MCU shelf weighs approximately 35 pounds.

  • Page 21: Prepare Power For Shelves

    Wall Mounting Dimensions 3.3. Prepare Power for Shelves The Link 3000 MCU requires a –48V DC power source. The –48V connection is comprised of three wires: -48, +48 (neutral), and ground. SpectraLink recommends that a licensed electrician install the –48V power source. It...
  • Page 22 SpectraLink Corporation Installation Link WTS – Link 3000 MCU methods, and no disconnecting device is located in the grounded DC circuit conductor between the point of connection to the supply and the point of connection to the grounding electrode and equipment grounding conductors.

  • Page 23: Run Cables To Base Station Locations

    Wire Specifications The customer's wire contractor is responsible for adhering to all local codes for wiring. SpectraLink recommends UL-Listed Wire that conforms to the following specifications for AWG, distance, and number of power pairs required for this installation. Max Cable...

  • Page 24: Terminate Cables At Base Station Locations

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU Pull Cable Pull the cable from the MCU location (usually in the telephone equipment room) to the Base Station locations designated on the floor plans. If the cabling exits the building, refer to 5.3 Install Outdoor Base Stations.

  • Page 25: Prepare Demarc Blocks

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU When wiring multiple power pairs, use the following table as a guide. Pair Function Pin #s Data PWR 1 PWR 2 PWR 3 Power pairs are polarity sensitive; pins 7,4, and 6 must be the same polarity.
  • Page 26 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Two Wire Analog or Digital Interface The wiring diagram below shows the connections required for a two-wire analog or digital interface. The Interface Module can be a CPA316, CPU316, CPP316, or CPM316.
  • Page 27 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Four Wire Digital Interface The wiring diagram below shows the connections required for a four-wire interface (CPF316). Each Interface Module of this type requires two backboards which will be wired as indicated.

  • Page 28: Install Demarc Blocks

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 3.7. Install Demarc Blocks The demarcation blocks used to connect the telephone system and Base Stations to the MCU should be installed on a typical telephone facility backboard. A ½" or ¾" thick board mounted on the wall near the MCU is typical.

  • Page 29: Connect Cables From Base Stations And Phone Lines To Demarc Blocks

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 3.9. Connect Cables from Base Stations and Phone Lines to Demarc Blocks Two-pair twisted cable from Base Stations installed throughout the facility converge at the demarc block or backboard. Each Interface Module can support six Base Stations and 16 Wireless Telephones.
  • Page 30 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Two Wire Analog or Digital Demarc Block The demarc block for the two-wire analog or digital interface should be wired as follows: LINE1 ring LINE 2 ring LINE 3 25 PAIR MALE...
  • Page 31 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Four Wire Digital Demarc Block The four wire digital interface (future release) requires two demarc blocks, one to Connector A and one to Connector B on the Interface Module. They should be wired as...
  • Page 32 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Line 1 RX ring Line 2 RX ring 25 PAIR MALE Line 3 RX ring CONNECTOR Line 4 RX CABLE TO ring INTERFACE MODULE Line 5 RX ring CONNECTOR B Line 6 RX...
  • Page 33 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Connect Demarc Block 25-Pair Cable In some installations the demarc block is connected to the Interface Module using a 25- pair Telco cable with RJ-21 connector. The female connector one male one female is plugged into the right side of each cross-connect block.

  • Page 34: System Installation

    Phone lines for the Wireless Telephones are installed and properly terminated. Telephone system administrator is on-site to program the existing telephone system. If the work has not been completed, the SpectraLink installer may leave the site and reschedule the installation when the items have been completed or corrected, or may assist in preparing the site.

  • Page 35: Install Shelves

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU • – (CSC300 or CSO300) - one card for each Expansion Shelf Controller Card Expansion Shelf. This card is installed in Slot 2 and connected to the system controller by an Intershelf Junction Panel.

  • Page 36: Install Intershelf Junction Panel

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU Cards contain components that may be damaged by electrostatic discharge. Before handling any of the cards, attach the grounding strap (included in the Administration Kit) to your wrist, and attach the other end of the strap to ground.

  • Page 37: Connect Power To Shelves

    Link WTS – Link 3000 MCU 4.5. Connect Power to Shelves SpectraLink recommends that a licensed electrician install the –48V DC power supply and connect power to the shelves. When connecting the -48 V DC system to power, note the following...

  • Page 38: Install Cards

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU Yellow White Ground Green Customer Green/Yellow Installed Wiring Before turning on the power switch, use a voltmeter to verify that the terminal labeled -48V is negative with respect to the terminal labeled +48V.
  • Page 39 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Install Interface Modules (CPA, CPU, CPM, CPP, CPF316) Slide the first Interface Module into Slot 3 of the Primary Shelf, until the card clicks into place. Tighten the screws at the top and bottom of the card to secure it.
  • Page 40 SpectraLink Corporation Installation Link WTS – Link 3000 MCU The shelf diagram below shows a fully loaded Expansion Shelf. Any type of Interface Module can be installed in slots 3-12. Empty Expansion Shelf Interface Modules Controller Slot 2 Slot Slots 3-12...

  • Page 41: Connect The Intershelf Junction Panel

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 4.7. Connect the Intershelf Junction Panel The Intershelf Junction Panel converts the RJ-21 connections on the system controller to the RJ-45 connections on the expansion shelf controller. RJ-45 Connectors to Shelf Controllers...

  • Page 42: Install Base Stations

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 5. Install Base Stations Be sure the Base Station is positioned clear of anything that might damage it. The Base Station should be well above head height, away from doors and other objects that might strike it, and away from areas open to the elements or possible water leaks.

  • Page 43: Mount Base Stations On Finished Ceilings

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 5.2. Mount Base Stations On Finished Ceilings If this site does not have a dropped tile ceiling, the Base Station can be mounted to a finished ceiling or wall with a 4-5" long 1/4" –20 TPI plastic or nylon screw or bolt (such as a lag screw).

  • Page 44: Power Up And Check Diagnostics

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU Mount and Connect Outdoor Base Stations 1. Mount the outdoor Base Station enclosure to a wall or pole. The enclosure should be attached at the highest point available that will provide central coverage for the outdoor area.

  • Page 45: System Initialization

    • If the system is connected to the telephone system via analog lines, refer to the Operator’s Console documentation. • If the Link 3000 MCU is connected to a digital key telephone system or PBX, refer to the section of LinkPlus Interface Guide that deals specifically with the brand of telephone system to which the Link WTS will interface.

  • Page 46: Test System

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 7. Test System The system should now be tested to ensure that it is functioning correctly. Power cycle the system. Verify that all Base Stations download and go to a running status. This takes about 30 seconds after connecting the Base Station cable to the Base Station’s RJ-45...

  • Page 47: Site Certification

    The installer should not leave the site before contacting SpectraLink to perform remote install verification. The installer should contact a SpectraLink engineer on the technical support line 800- 775-5330. The hours of operation are 7:00 a.m. to 6:00 p.m. Mountain Time, Monday through Friday, excluding holidays.

  • Page 48: Installation Forms

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 9. Installation Forms This section contains the following forms: Base Station Locations Extension Assignments Site Preparation Checklist Customer Acceptance Form Copy these forms as needed. Be sure to maintain completed forms for future reference.

  • Page 49: Base Station Location Form

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 9.1. Base Station Location Form Shelf Number: ________ Interface Module: ________ Location Interface Base Station # (e.g.: building, floor #, detailed description) Module Circuit # Base Station 1 Base Station 2...

  • Page 50: Extension Assignments Worksheet

    SpectraLink Corporation Installation Link WTS – Link 3000 MCU 9.2. Extension Assignments Worksheet Shelf: _______ Interface Module: _______ Interface Wireless Phone # Ext. # Name Module Comment Telephone Circuit # Serial # Phone 1 Phone 2 Phone 3 Phone 4...

  • Page 51: Site Preparation Checklist

    Link WTS – Link 3000 MCU 9.3. Site Preparation Checklist If upon arrival the SpectraLink installer determines that the pre-installation work has not been completed correctly, the installer has two options: 1) the installer can leave the site and reschedule the installation when the action items have been completed or corrected, or 2) the installer can assist in preparing the site, and thus spend additional time installing the system.

  • Page 52: Customer Acceptance Form

    Description & Serial Number The terms and conditions of original Quotation and Sales Agreement apply to all equipment listed above. _____ I accept the installation of the SpectraLink system as complete. _____ I decline the installation of the SpectraLink system because:...
  • Page 53 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Index Attenuation, 23 Customer Acceptance , 53 Base station location form, 50 Extension assignments, 51 Base Stations, 15 Site preparation checklist, 52 Cabling, 23, 24 High Density Base Stations, 15 High Density, 15...
  • Page 54 SpectraLink Corporation Installation Link WTS – Link 3000 MCU Controller, 18 Site preparation, 17 MCU, 21 Site preparation checklist, 52 Pairs, 23 System administrator, 18 Shelf requirements, 14 System Controller Power circuit, 21 Description, 14 Quick Clip Fuse, 18 Installing, 38...
