MOUNTING WITH THE SVS MULTI-ANGLE WALL BRACKET
Your SVS Prime Elevation Speaker is ready to be mounted right out of the box
and all the hardware you need to mount your SVS Prime Elevation Speaker is
included. It also features a universal mounting option with a ¼" brass insert that
works with many other mounting kits.
When installing the SVS Multi-Angle Wall Bracket (patent pending), it is best to
screw it directly into a stud or structural part of the wall. If mounting directly to a
stud is not a viable option, use drywall or masonry anchors rated to support
weights of 10 pounds or more.
Installation Hardware:
Speaker Bracket
PRIME ELEVATION
WALL MOUNTING TEMPLATE
OPTION #4 LEFT/SIDE-FIRING
THIS SIDE UP
Mounting Template
Multi-Angle Wall Bracket
(patent pending)
10
¼"-20 Screws
Screws &
Wall Anchors
