  • Page 1 Ultra Elevation Reference home theater speaker Owner’s Manual...
  • Page 3 OWNER’S MANUAL SPEAKER SERIES Thank you for choosing SVS. We believe an unrelenting passion for sonic excellence combined with design innovation are the keys to making world-class audio products. We think you’ll agree. ULTRA TOWER Breakthroughs in driver technology, tweeter design, material science,...
  • Page 4 Ultra Elevation Brings Audio to New Heights The SVS Ultra Elevation is the ultimate adaptation of the world’s most versatile home theater speaker. When we introduced the Prime Eleva- tion speaker, it quickly became one of the most popular products in SVS history bringing immersive surround sound and height effects to...

  • Page 5: Table Of Contents

    WIRING YOUR ULTRA ELEVATION SPEAKERS MOUNTING THE SVS MULTI-ANGLE WALL BRACKET OVERHEAD CEILING MOUNTING INSTALLING FEET FOR SURFACE PLACEMENT CONNECTING TO YOUR AV RECEIVER CARING FOR YOUR SVS ULTRA ELEVATION SPEAKERS WARRANTY SHARE YOUR THOUGHTS ULTRA ELEVATION SPEAKER FEATURES & SPECIFICATIONS page...

  • Page 6: Adjustable Svs Grille Logo

    Adjustable SVS Grille Logo A unique feature of the Ultra Elevation Speakers is the magnetic SVS grille logo that can be removed and reattached for proper alignment, no matter what position the speaker is being used in. Simply pull the magnetic logo off with your fingertips, rotate and reattach in the desired position.

  • Page 7: Down-Firing Height Effects Speaker

    Audio formats such as Atmos and DTS:X® make use of object based “height effect” speakers to create an even more immersive, three-dimensional audio experience. To achieve this effect, the SVS Ultra Elevation speakers should be mounted to the side walls, front wall, rear wall as close to the ceiling as possible, or to the ceiling directly.
  • Page 8 Recommended Ultra Elevation Placement Options 5.1.4 system with four side height channels 5.1.2 system with two side height channels page...
  • Page 9 Recommended Ultra Elevation Placement Options 5.1.4 system with four ceiling height channels 5.1.2 system with two ceiling height channels page...

  • Page 10: Up Or Down-Firing Center Channel Speaker

    . Up or Down-Firing Front Channel L-C-R Speaker The Ultra Elevation Speakers can also be used in an up or down-firing position as Front Left, Center, and Right speakers. As above, all three speakers can be placed closer to the floor and angled up towards the listening area.

  • Page 11: Side Or Rear Firing Surround Speaker

    Recommended Ultra Elevation Placement Options Side or Rear-Firing Surround Sound Speaker The SVS Ultra Elevation offers great flexibility as a surround sound speaker in any set-up, but especially when placement on a side or rear wall is not optimal. As a side surround, the Elevation can be placed towards the back of the room in a front firing position.

  • Page 12: Wiring Your Ultra Elevation Speakers

    Wiring Your Ultra Elevation Speakers The SVS Ultra Elevation Speakers include convenient gold-plated five-way binding posts, which accept cables terminated with banana plugs, speaker pins, spade connectors, and bare wire. As with any speaker wire run, always measure twice, cut once and allow an extra foot or two of cable, just to be safe.

  • Page 13: Mounting The Svs Multi-Angle Wall Bracket

    Mounting With the SVS Multi-Angle Wall Bracket Your SVS Ultra Elevation Speaker is ready to be mounted right out of the box with all the hardware included. It also features a universal mounting option with a ¼” brass insert that works with many other mounting kits.
  • Page 14 Mounting With the SVS Multi-Angle Wall Bracket Mounting Instructions: The SVS Ultra Elevation’s flexible Multi-Angle Wall Bracket allows you to position the speaker in any of four directions: up or down firing, and side or rear firing, depending on how it’s being used.

  • Page 15: Overhead Ceiling Mounting

    The foam EVA gasket will ensure a tight fit with the speaker. 5) Connect the speaker wire to your binding posts and hang the Ultra Elevation on the Multi-Angle Wall Bracket as shown. The gasket will make a tight fit and eliminate any possible vibration noise.

  • Page 16: Installing Feet For Surface Placement

    Overhead Ceiling Mounting 1) With Ultra Elevation mounted to the ceiling with the Multi-Angle Wall Bracket, align the Magnetic Ceiling Lock with the space between the bracket and ceiling. 2) Slide the Magnetic Ceiling Lock into place until the lip meets the edge of the Ultra Elevation Multi-Angle Wall Bracket.

  • Page 17: Connecting To Your Av Receiver

    Elevation, Height Effect or by the actual audio format (Atmos, DTS:X®, or others). If you’re using the Ultra Elevation as a height effect speaker and are having difficulty hearing the effects with clarity, you can raise the volume levels for that specific channel in your AV receiver settings to get the most impact possible.

  • Page 18: Warranty

    5-year Unconditional Warranty SVS offers the industry's most comprehensive warranty on all our products. SVS warrants the Ultra Elevation Speakers and all of its products to be free from defects in the workmanship for five years from date of purchase.

  • Page 19: Ultra Elevation Speaker Features & Specifications

    • Overall Dimensions: 11.3” (H) x 7.28” (W) x 9.17” (D) / 287mm (H) x 185mm (W) x 233mm (D) (includes grille, feet, and binding posts) • Overall Dimensions: 11.14” (H) x 7.28” (W) x 9.82” (D) / 283mm (H) x 185mm (W) x 249.4mm (D) (includes grille and SVS Multi-Angle Wall Bracket) •...
