Table Of Contents - Samsung SENS R60 Plus Service Manual

4 4
SAMSUNG PROPRIETARY SAMSUNG PROPRIETARY
THIS DOCUMENT CONTAINS CONFIDENTIAL THIS DOCUMENT CONTAINS CONFIDENTIAL
PROPRIETARY INFORMATION THAT IS PROPRIETARY INFORMATION THAT IS
SAMSUNG ELECTRONICS CO'S PROPERTY. SAMSUNG ELECTRONICS CO'S PROPERTY.
DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS
EXCEPT AS AUTHORIZED BY SAMSUNG. EXCEPT AS AUTHORIZED BY SAMSUNG.
PRAHA EXT GFX
CPU :
Chip Set :
Remarks :
Model Name :
PBA Name
PCB Code
Dev. Step
Revision
T.R. Date
DRAW
Owner : SEC Mobile R & D
4 4
3 3
Intel Merom (800MHz)
RS600ME & SB600
Mobility Platform
PRAHA EXT GFX
: MAIN
:
NANYA:BA41-00806A
GCE :BA41-00812A
TPT :BA41-00814A
: PR2 (8-Layer)
: 1.0
: 2007.06.24
CHECK APPROVAL
Signature :
3 3
2 2

Table of Contents

Sheet 1. COVER
Sheet 2-6. DIAGRAM (Block/Power) & ANNOTATIONS
Sheet 7. CLOCK GENERATOR
Sheet 8-10. YONAH
Sheet 11. THERMAL SENSOR / FAN CONTROL
Sheet 12-16. RS600ME
Sheet17. DDR II SODIMM
Sheet18. DDR II TERMINATION
Sheet19-22. SB600
Sheet23. SB600 STRAPS
Sheet24. SPI ROM & DEBUG CARD CONN
Sheet26-30. ATI M64S VIDEO CHIP
Sheet31. LCD
Sheet32. CRT
Sheet33. EXPRESS CARD
Sheet34. 2 IN 1
Sheet35. MINICARD
Sheet36-38. AUDIO
Sheet39. HDD(SATA) & ODD(IDE)
Sheet40. MICOM
Sheet41. LOM WITH COMBO JACK
Sheet42. USB & MDC
Sheet43. LED & BLUETOOTH & TOUCHPAD & KEYBOARD & LID S/W
Sheet44. CHARGER
Sheet45. P3.3V_AUX & P5.0V_AUX
Sheet46. P1.2V & P1.2V_AUX & VCCP
Sheet47. DDR2 POWER
Sheet48. EXTERNAL GFX_POWER
Sheet49. CPU VRM
Sheet50. P1.5V POWER & SWITCHED POWER & MICOM RESET
Sheet50. ICT PORT
Sheet51. P1.2V_NB / P2.5V POWER
Sheet52. DISCHARGE & MOUNT HOLE
Sheet53. EMI FINGER / ICT CAPACITOR
Sheet54. TP
