Summary of Contents for Samsung R59

  • Page 1 R59/R59 plus R60/R60 plus/P500 R61/R61 plus User Guide...

  • Page 2: Table Of Contents

    Chapter 1. Getting Started Product Features Before You Start Contents Safety Precautions Proper Posture During Computer Use Important Safety Information Replacement Parts and Accessories Regulatory Compliance Statements WEEE SYMBOL INFORMATION Overview Front View Status Indicators Right View Left View Back View Bottom View Turning the Computer On and Off Turning the computer on...

  • Page 3: Product Features

    Product Features High Performance Notebook Computer ■ Intel Core™2 Duo Processor . DDR II Memory ■ Wireless LAN , Bluetooth ■ 14.1" Wide LCD Easy-to-Use AV ■ AVStation Viewer and AVStation Premium are provided to easily play various multimedia files. Sophisticated Design for Increased Usability ■ AV Button and various shortcut keys on the keyboard ■ Multi card slot ■ Luxurious design with increased usability The items marked with this symbol are optional items that are supported depending on the computer model. Note...

  • Page 4: Before You Start

    User Guide ■ Some devices and software referred to in the You are currently reading the User Guide. To open the User Guide may not be provided and/or changed file at any time, double-click the icon on the Desktop. by upgrade. Note Alternatively, select Start > All Programs > Samsung > Note that the computer environment referred in User Guide > User Guide. the User Guide may not be the same as your own environment. This document includes the computer functions, how to use the functions, and how to use the program.
  • Page 5 Page XX about related functions or as a reference. Start > All This represents a menu path to run a Programs > program. Samsung > User Click the Start button and then select All Guide > User Programs > Samsung > User Guide > Guide User Guide in this order from the menu.

  • Page 6: Contents

    Charging Battery networks (peer-to-peer or ad hoc) Overview Checking Battery Residual Amount Wireless Network Setup Using the Front View Using Battery Longer Wireless LAN Setup Program Status Indicators Using the Security Lock Port Using Samsung Network Manager Right View Perform Network Settings Left View Using the network after moving location 80 Back View Chapter 7. Appendix Sharing Internet Access Bottom View Checking Network Status Turning the Computer On and Off...

  • Page 7: Safety Precautions

    Safety Precautions For your security and to prevent damage, please read the following safety instructions carefully. Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Installation Related Power Related The power plug and wall outlet figures may differ depending on the country specifications and the product model. Do not install the product in Keep a distance of 15cm or places exposed to humidity more between the computer and such as a bathrooms.
  • Page 8 If the power cord or power outlet Plug the power cord firmly into Do not bend the power cord makes a noise, disconnect the the power outlet and AC adapter. excessively or do not place a power cord from the wall outlet heavy object over the power Failing to do so may cause fire and contact a service center.
  • Page 9 Battery Usage Related Usage Related Disconnect all cables If water or another substance Keep the battery out of the connected to the computer enters the power input jack, reach of infants and pets, as before cleaning it. If you are AC adapter or the computer, they could put the battery into using a notebook computer,...
  • Page 10 Upgrade Related Do not place any container filled Avoid direct sunlight when with water or chemicals over or the computer is in an air-tight Never disassemble the power near the computer. location such as inside a supply or AC adapter. vehicle.
  • Page 11 Upgrade Related Custody and Movement Related Shut down the computer and Follow the instructions for the disconnect all cables before relevant location (e.g. airplane, disassembling the computer. If hospital, etc.) when using a there is a modem, disconnect wireless communication device the phone line.
  • Page 12 This may cause an injury, fire or computer to malfunction or halt. explosion. There is a danger of explosion or fire. Do not place a heavy object Use only a battery authorized by over the product. Samsung Electronics. This may cause a problem with Failing to do so may cause an the computer. In addition, the explosion. object may fall and cause injury, or damage the computer. Avoid contact with metal objects such as car keys or clips when keeping or carrying a battery.
  • Page 13 If your computer product. Do not press the Eject Button is a note-book computer, make while the Floppy Disk/CD-ROM Authorised Samsung Repair sure to remove the battery. drive is in operation. Centers will carry out safety checks There is a danger of fire. after a repair. Using a repaired...
  • Page 14 To connect a device that is not motion. Make sure to use the computer part or device. manufactured or authorized by emergency disk eject method Samsung Electronics, enquire This may cause injury or damage only when the Optical Disk at your service center before to the product.
  • Page 15 Custody and Cautions on Preventing Data Loss (Hard Disk Movement Related Management) When moving the product, Take care not to damage the Causes that may damage the turn the power off and data on a hard disk drive. data of a hard disk drive and the separate all connected cables hard disk drive itself.

  • Page 16: Proper Posture During Computer Use

    Proper Posture During Computer Use Maintaining a proper posture during computer use is very important to prevent physical harm. The following instructions are about maintaining a proper posture during computer use developed through human engineering. Please read and follow them carefully when using the computer. Otherwise, the probability of (RSI: Repetitive Strain Injury) from repeated operations may increase and serious physical harm may be caused. The instructions in this manual have been prepared so that they can be applied within the coverage of general users. If the user is not included in the coverage, the recommendation is to be applied according to the user’s needs. Since this is commonly applied to Samsung Computers, some figures may differ from actual ones. Note Proper Posture Adjust the heights of desks and chairs appropriate to your height. The heights are to be adjusted so that your arm forms a right angle when you place your hand over the keyboard while sitting down on a chair. ■ Adjust the height of chair so that your heel is comfortably placed on the floor. ■ Do not use the computer while you are lying down, but only while you are sitting down. ■ Do not use the computer on your lap. If the computer temperature increases, there is a danger of burning yourself.
  • Page 17 Eye Position Hand Position Keep the monitor or LCD away from your eyes by at Keep your arm at a right angle as shown by the figure. least 50cm. ■ Keep the line from your elbow to your hand straight. ■ Adjust the height of the monitor and the LCD screen so that its top height is equal to or lower than your eyes. ■ Do not place your palm over the keyboard while typing. ■ Avoid setting the monitor and LCD excessively bright. ■ Do not hold the mouse with excessive force. ■ Keep the monitor and LCD screen clean.
  • Page 18 Volume Control (Headphones and Illumination Speakers) ■ Do not use the computer in dark locations. The Check your volume first to listen to music. illumination level for computer use must be as bright so for reading a book. ■ Indirect illumination is recommended. Use a curtain to prevent reflection on the LCD screen. Click your volume!! Operation Condition ■ Do not use the computer in hot and humid locations. ■ Check if the volume is too loud before using headphones. ■ Use the computer within the allowed temperature and humidity range specified in the User Guide. ■ It is not recommended using headphones for long periods of time. Use Time (Break Time) ■ Take a break for 10 minutes or more after a 50-minute period when working for more than one hour.

  • Page 19: Important Safety Information

    Important Safety Information Safety instructions Your system is designed and tested to meet the latest ■ Openings in the computer case are provided for standards for safety of information technology equipment. ventilation. Do not block or cover these openings. However, to ensure safe use of this product, it is important Make sure you provide adequate space, at least 6 that the safety instructions marked on the product and in inches (15 cm), around the system for ventilation when the documentation are followed. you set up your work area. Never insert objects of any kind into the computer ventilation openings. ■ Ensure that the fan vents on the bottom of the casing Always follow these instructions to help guard are clear at all times. Do not place the computer on a against personal injury and damage to your system. soft surface, doing so will block the bottom vents. Caution ■ If you use an extension cord with this system, make sure that the total power rating on the products Setting Up your System plugged into the extension cord does not exceed the extension cord power rating.
  • Page 20 Care During Use The Instruction On Safety Operation of NotePC ■ Do not walk on the power cord or allow anything to rest When installing and operating devices please refer to on it. safety requirements in the user guide. ■ Do not spill anything on the system. The best way to avoid spills is to not eat or drink near your system. ■ Some products have a replaceable CMOS battery on Devices can be used only with the equipment the system board. There is a danger of explosion if specified in the technical specifications of the the CMOS battery is replaced incorrectly. Replace the devices. battery with the same or equivalent type recommended by the manufacturer. ■ When the computer is turned off, a small amount of If any smell of burning or smoke from the computer electrical current still flows through the computer. To the unit should be switched off and battery removed. avoid electrical shock, always unplug all power cables, remove the battery and modem cables from the wall The unit should be checked by a qualified technician outlets before cleaning the system. before reuse. ■ Unplug the system from the wall outlet and refer servicing to qualified personnel if: – The power cord or plug is damaged.

  • Page 21: Replacement Parts And Accessories

    Replacement Parts and Accessories Use only replacement parts and accessories recommended by manufacturer. To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line cord. Caution Do not use this product in areas classified as hazardous. Such areas include patient care areas of medical and dental facilities, oxygen rich environments, or industrial areas. Note Battery Disposal Laser Safety All systems equipped with CD or DVD drives comply with the appropriate safety standards, including IEC 60825- To reduce the risk of fire, use only No. 26 AWG or 1. The laser devices in these components are classified larger telecommunications line cord. Caution as “Class 1 Laser Products” under a US Department of Health and Human Services (DHHS) Radiation Contact the Samsung Helpline for information on how to Performance Standard. Should the unit ever need dispose of batteries that you cannot use or recharge any servicing, contact an authorized service location. longer. Follow all local regulations when disposing of old Laser Safety Note: ■ batteries. Use of controls or adjustments or performance of procedures other than those specified in Caution this manual may result in hazardous radiation THERE IS A RISK OF EXPLOSION IF BATTERY IS exposure. To prevent exposure to laser beams, REPLACED BY AN INCORRECT TYPE. DISPOSE do not try to open the enclosure of a CD or DVD...

  • Page 22: General Requirements

    General Requirements Connect and Disconnect the AC adapter The requirements listed below are applicable to all countries: The socket-outlet shall be installed near the equipment ■ The length of the power cord set must be at least 6.00 and shall be easily accessible. feet (1.8m) and a maximum of 9.75 feet (3.0m). Do not unplug the power cord out by pulling the cable ■ All power cord sets must be approved by an only. acceptable accredited agency responsible for evaluation in the country where the power cord set will be used. ■ The power cord set must have a minimum current capacity of 7 A and a nominal voltage rating of 125 Power Cord Requirements or 250 volts AC, as required by each country’s power...

  • Page 23: Regulatory Compliance Statements

    Regulatory Compliance Statements Wireless Guidance Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook system. The following section is a general overview of considerations while operating a wireless device. Additional limitations, cautions, and concerns for specific countries are listed in the specific country sections (or country group sections). The wireless devices in your system are only qualified for use in the countries identified by the Radio Approval Marks on the system rating label. If the country you will be using the wireless device in, is not listed, please contact your local Radio Approval agency for requirements. Wireless devices are closely regulated and use may not be allowed. The RF field strength of the wireless device or devices that may be embedded in your notebook are well below all international RF exposure limits as known at this time. Because the wireless devices (which may be embedded into your notebook) emit less energy than is allowed in radio frequency safety standards and recommendations, manufacturer believes these devices are safe for use. Regardless of the power levels, care should be taken to minimize human contact during normal operation. As a general guideline, a separation of 20 cm (8 inches) between the wireless device and the body, for use of a wireless device near the body (this does not include extremities) is typical. This device should be used more than 20 cm (8 inches) from the body when wireless devices are on and transmitting. (This Statement is not applicable to UMPC(Ultra Mobile PC) such as PDA, Portable PC.) This transmitter must not be collocated or operate in conjunction with any other antenna or transmitter except the installed Bluetooth transmitter. Some circumstances require restrictions on wireless devices. Examples of common restrictions are listed below:...
  • Page 24 Radio frequency wireless communication can interfere with equipment on commercial aircraft. Current aviation regulations ■ require wireless devices to be turned off while traveling in an airplane. 802.11B (also known as wireless Ethernet or Wifi) and Bluetooth communication devices are examples of devices that Caution provide wireless communication. In environments where the risk of interference to other devices or services is harmful or perceived as harmful, the ■ option to use a wireless device may be restricted or eliminated. Airports, Hospitals, and Oxygen or flammable gas laden atmospheres are limited examples where use of wireless devices may be restricted or eliminated. When in environments where you are uncertain of the sanction to use wireless devices, ask the applicable authority for authorization prior to use or turning on the wireless device. Every country has different restrictions on the use of wireless devices. Since your system is equipped with a wireless ■ device, when traveling between countries with your system, check with the local Radio Approval authorities prior to any move or trip for any restrictions on the use of a wireless device in the destination country. If your system came equipped with an internal embedded wireless device, do not operate the wireless device unless all ■ covers and shields are in place and the system is fully assembled. Wireless devices are not user serviceable. Do not modify them in any way. Modification to a wireless device will void the ■ authorization to use it. Please contact manufacturer for service. Only use drivers approved for the country in which the device will be used. See the manufacturer System Restoration Kit, or ■ contact manufacturer Technical Support for additional information.
  • Page 25 United States of America USA and Canada Safety Requirements Other Wireless Devices and Notices Safety Notices for Other Devices in the Wireless Network: Refer to the documentation supplied with wireless Ethernet adapters or other devices in the Do not touch or move antenna while the unit is wireless network. transmitting or receiving. Do not hold any component containing the radio such that The Part 15 radio device operates on a non- the antenna is very close or touching any exposed parts interference basis with other devices operating at this frequency. Any changes or modification to said of the body, especially the face or eyes, while transmitting. Caution product not expressly approved by Intel could void Do not operate the radio or attempt to transmit data the user’s authority to operate this device. unless the antenna is connected; if not, the radio may be damaged.
  • Page 26 Intentional emitter per FCC Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits Low power, Radio LAN type devices (radio frequency (RF) Caution are designed to provide reasonable protection wireless communication devices), operating in the 2.4 against harmful interference in a residential GHz Band, may be present (embedded) in your notebook installation. This equipment generate uses and can system. This section is only applicable if these devices are radiate radio frequency energy and if not installed present. Refer to the system label to verify the presence and used in accordance with the instructions may cause harmful interference will not occur in a of wireless devices. particular installation. If this equipment does cause Wireless devices that may be in your system are only harmful interference to radio or television reception, qualified for use in the United States of America if an FCC which can be determined by turning the equipment off and on, the user is encouraged to try to correct ID number is on the system label. the interference by one or more of the following The FCC has set a general guideline of 20 cm (8 inches) measures: separation between the device and the body, for use of Reorient or relocate the receiving antenna. ■ a wireless device near the body (this does not include Increase the separation between the equipment ■ extremities). This device should be used more than 20 and receiver. cm (8 inches) from the body when wireless devices are Connect the equipment into an outlet on a ■...
  • Page 27 The REN is used to determine the quantity of devices Wireless devices are not user serviceable. Do not which may be connected to telephone line. Excessive modify them in any way. Modification to a wireless RENs on the telephone line may result in the devices device will void the authorization to use it. Contact Caution manufacturer for service. not ringing in response to an incoming call. In most, but not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be FCC Statement for Wireless LAN use: connected to a line, as determined by total RENs, contact “While installing and operating this transmitter and antenna combination the radio frequency exposure the local telephone company to determine the maximum Caution REN for the calling area. limit of 1mW/cm2 may be exceeded at distances close to the antenna installed. Therefore, If the terminal equipment causes harm to the telephone the user must maintain a minimum distance of network, the Telephone Company will notify you in 20cm from the antenna at all times. This device advance that temporary discontinuance of service may can not be colocated with another transmitter be required. But if advance notice is not practical, the and transmitting antenna.” (This Statement is not applicable to UMPC(Ultra Mobile PC) such as PDA,...
  • Page 28 Canada Unintentional Emitter per ICES-003 This equipment cannot be used on public coin phone service provided by the telephone company. Connection to party line service is subject to state tariffs. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out The Telephone Consumer Protection Act of 1991 makes in the radio interference regulations of Industry Canada. it unlawful for any person to use a computer or other electronic device, including fax machines, to send any Le présent appareil numérique n’émet pas de bruits message unless such message clearly contains in a radioélectriques dépassant les limitesapplicables aux margin at the top or bottom of each transmitted page or appareils numériques de Classe B prescrites dans le on the first page of the transmission, règlement sur le brouillage radioélectrique édicté par Industrie Canada. the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending machine or such business, other entity, or individual. (The Intentional Emitter per RSS 210 telephone number provided may not be any number for which charges exceed local or long-distance transmission Low power, Radio LAN type devices (radio frequency (RF) charges.) wireless communication devices), operating in the 2.4 In order to program this information into your fax machine, GHz Band, may be present (embedded) in your notebook refer to your communications software user manual. system. This section is only applicable if these devices are present. Refer to the system label to verify the presence of wireless devices.
  • Page 29 This transmitter must not be collocated or operate in with a single-line individual service may be extended by conjunction with any other antenna or transmitter except means of a certified connector assembly. The customer the installed Bluetooth transmitter. should be aware that compliance with the above conditions may not prevent degradation of service in Operation of this device is subject to the following two some situations. conditions: (1) This device may not cause harmful interference, and (2) this device must accept any Repairs to certified equipment should be made by an interference received, including interference that may authorized Canadian maintenance facility designated cause undesired operation of the device. by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may To prevent radio interference to licensed service, give the telecommunications company cause to request this device is intended to be operated indoors and away from windows to provide maximum shielding. the user to disconnect the equipment. Caution Equipment (or its transmit antenna) that is installed Users should make sure, for their own protection, that outdoors is subject to licensing. the electrical ground connections of the power utility, telephone lines, and internal metallic water pipe system, if Wireless devices are not user serviceable. Do not present, are connected together. This precaution may be modify them in any way. Modification to a wireless particularly important in rural areas.
  • Page 30 European Union European Union CE Marking and European Radio Approval Information Compliance Notices (for products fitted with EU-approved radio devices) Products intended for sale within the European Union are marked with the Conformité Européene (CE) Marking, This Product is a Notebook computer; low power, which indicates compliance with the applicable Directives Radio LAN type devices (radio frequency (RF) wireless and European standards and amendments identified communication devices), operating in the 2.4 GHz band, below. This equipment also carries the Class 2 identifier. may be present (embedded) in your notebook system The following information is only applicable to systems which is intended for home or office use. This section is labeled with the CE mark. only applicable if these devices are present. Refer to the system label to verify the presence of wireless devices. Wireless devices that may be in your system are only European Directives qualified for use in the European Union or associated areas if a CE mark with a Notified Body Registration This Information Technology Equipment has been Number and the Alert Symbol is on the system label.
  • Page 31 Translated Statements of Compliance [Spanish] Este producto cumple con las normas del Directivo Eu- [English] ropeo 1999/5/EC. This product follows the provisions of the European Direc- [Swedish] tive 1999/5/EC. Denna produkt har tillverkats i enlighet med EG-direktiv [Danish] 1999/5/EC. Dette produkt er i overensstemmelse med det europæiske direktiv 1999/5/EC Translated Statements of Compliance [Dutch] Local Restriction of 802.11b/802.11g Radio Usage Dit product is in navolging van de bepalingen van Europ- ees Directief 1999/5/EC. [Note to integrator: The following statements on [Finnish] local restrictions must be published in all end-user Tämä tuote noudattaa EU-direktiivin 1999/5/EC määräyk- documentation provided with the system or product siä. incorporating the Intel PRO/Wireless 2200BG Network [French] Connection product.] Ce produit est conforme aux exigences de la Directive Due to the fact that the frequencies used by Européenne 1999/5/EC.
  • Page 32 European Telecommunication General Information (for products fitted with EU- European standards dictate maximum radiated trans- approved modems) mit power of 100 mW effective isotropic radiated power (EIRP) and the frequency range 2400 – 2483.5 MHz. Marking by the symbol indicates compliance of this Belgium equipment to the Radio and Telecom Terminal Equipment The product may be used outdoors, but for outdoor trans- Directive 1999/5/EC. Such marking is indicative that missions over a distance of 300m or more, a license from this equipment meets or exceeds the following technical the BIPT is required. standards: This restriction should be indicated in the manual as fol- CTR 21 – Attachment requirements for pan-European lows: approval for connection to the analogue Public Switched Telephone Networks (PSTNs) of TE (excluding TE Dans le cas d’une utilisation privée, à l’extérieur d’un supporting voice telephony services) in which network bâtiment, au-dessus d’un espace public, aucun enregis- addressing, if provided, is by means of Dual Tone Multi- trement n’est nécessaire pour une distance de moins de Frequency (DTMF) signaling. 300m. Pour une distance supérieure à 300m un enregis- trement auprès de l’IBPT est requise. Pour une utilisation Although this equipment can use either loop publique à l’extérieur de bâtiments, une licence de l’IBPT disconnect (pulse) or DTMF (tone) signaling, only est requise. Pour les enregistrements et licences, veuillez the performance of the DTMF signaling is subject to Caution contacter l’IBPT.

  • Page 33: Weee Symbol Information

    Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. USA ONLY This Perchlorate warning applies only to primary CR (Maganese Dioxide) Lithium coin cells in the product sold or distributed ONLY in California USA. “Perchlorate Material- special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.” LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. For details see lamprecycle.org, eise.org, or call 1-800-Samsung.

  • Page 34: Overview

    Overview Before You Start! ■ The items marked with this symbol are optional items which may be changed or may not be provided depending on the computer model. ■ The actual color and appearance of the computer may differ from the pictures used in this guide. Front View LCD Latch This latch is used to open and close the LCD panel. To open the LCD panel, slide the latch to the right and then lift the LCD panel up. The screen images are displayed here. Speaker AV Button A device used to generate Launches AVStation Viewer. sound. p. 11 Power Button Turns the computer on and off. Keyboard p. 9 A device to enter data by pressing the keys. p. 1 Status Indicators Shows the operating status of the computer.

  • Page 35: Status Indicators

    Status Indicators Num Lock This turns on when the Num Lock key is pressed and numeric keypad is activated. p.  Caps Lock This turns on when the Caps Lock key is pressed allowing capital letters to be typed without holding the Shift button down. Power This shows the computer operating status. On : When the computer is operating Blinks: When the computer is in Sleep mode. Charge Status This shows the power source and the battery charge status. Green: When the battery is fully charged or the battery is not installed. Amber: When the battery is being charged. Off: When the computer is running on battery power without being connected to AC adapter. Wireless LAN This turns on when the wireless LAN is operating.

  • Page 36: Right View

    Right View CD Drive (ODD) Security Lock Port Plays CD or DVD titles. You can connect a Kensington lock to the Since an ODD drive is optional, the installed drive Security Lock Port to prevent the computer depends on the computer model. p. 7 from being stolen.

  • Page 37: Left View 6

    Left View Monitor Port A port used to connect a monitor, TV or projector supporting a 15pin D-SUB interface. p.  USB Port You can connect USB devices to the USB port such as a keyboard/mouse, digital camera, etc. PCI ExpressCard Slot Install the PCI Express card into this Fan Vents slot. The internal heat of the computer is emitted through these holes. If the vents are blocked the computer may overheat. Headphone Jack Avoid blocking the vents as this may be dangerous. Caution A jack used to connect the headphones. Microphone Jack A jack used to connect the microphone.

  • Page 38: Back View 7

    Back View DC Jack A jack to connect the AC adapter that supplies power to the computer. Wired LAN Port Connect the Ethernet cable to this port. p. 68 USB Port You can connect USB devices to the USB port such as a keyboard/mouse, digital camera, etc. Battery This is a Lithium-Ion rechargeable battery that supplies power to the computer. p. 1 Modem Port A port to which a telephone cable is connected to in order to dial up to the Internet.

  • Page 39: Bottom View 8

    Bottom View Battery Latches The latch used to remove or install the battery. p. 1 Hard Disk Drive Compartment Cover Memory Compartment Cover The hard disk drive is installed inside the cover. The main memory is installed inside the cover. p. 10...

  • Page 40: Turning The Computer On And Off

    Turning the Computer On and Off Turning the computer on Turning the computer off Install the battery and connect the AC adapter. Click the start button ( ) on the taskbar. (Refer to the Installation Guide.). Slide the LCD Latch to the right and then lift up the Click Turn Off Computer. LCD panel. Press the Power button to turn the computer on. Click Turn Off.

  • Page 41: Chapter 2. Using The Computer

    Chapter 2. Using the computer Keyboard Touchpad CD Drive (ODD) Inserting and Ejecting a CD Burning a CD Multi Card Slot PCI ExpressCard Slot Connecting a Monitor Connecting a Monitor Viewing Through a Monitor Adjusting the Volume Using Recorders...

  • Page 42: Keyboard

    Keyboard The keyboard is supplied according to the corresponding country. Refer to the keyboard figure for the corresponding country. United Kingdom United States...

  • Page 43: Shortcut Keys

    You can only use this function when the Easy Display Manager program is installed. Enters the Euro monetary unit symbol. Euro This key may not be provided depending on the keyboard type. Switches the screen output to the LCD or external monitor when an external monitor (or TV) is CRT/LCD connected to the computer. Backlit Turns the LCD backlight on or off. Mute Mutes or cancels mute. Samsung Magic System diagnosis, recovery and Internet consultation program, Samsung Magic Doctor, will be Doctor launched. You can select operation mode when you need maximum system performance or low-noise/low power consumption with one-click. ■ Silent: Low-noise and low power consumption mode Easy SpeedUp ■ Normal: Normal Mode Manager ■ Speed: Maximum performance mode. The system operates in its maximum performance, and system resources are allocated to the currently active program with priority for maximum performance.

  • Page 44: Other Function Keys

    Screen Brightness Control Other Function Keys To adjust the LCD brightness press the Fn + ( ) key combination or the Fn + ( ) key combination. The ■ Application Key ( changed screen brightness is displayed at the center of Performs the right-click mouse function (touchpad). the screen for a moment. ■ Internet Explorer Quick Launch Key : (Fn+) Launches Internet Explorer. Volume Control To control the volume, press the Fn + ( ) key combination or the Fn + ( ) key combination.

  • Page 45: Touchpad

    Touchpad The touchpad provides the same function as a mouse and the left and right buttons of the touchpad plays the role of the left and right buttons of a mouse. Before You Start! Use the Touchpad with your fingers. Using a sharp object may damage the Touchpad. ■ If you touch the Touchpad or press the Touchpad buttons while booting up, the Windows boot time may be extended. ■ Touchpad Scroll Area Use to move the cursor. Plays the role of the mouse wheel. You can scroll up and down using the Scroll Area. Touchpad Left Button Touchpad Right Button You can select or run a program Plays the role of the right mouse using this button. button.
  • Page 46 Moving the cursor on the screen Double-Click Function Place your finger on the touchpad slightly and move your Put your finger on the touchpad and quickly tap twice with finger. The mouse cursor will move accordingly. Move your finger on an item you want. your finger in the direction you wish to move the cursor. Alternatively, press the left touchpad button twice quickly. TapTap ClickClick Click Function Right Button Function Place your finger on the touchpad and tap your finger This corresponds to clicking the right mouse button. once over an item you want. Press the right touchpad button once. The corresponding Alternatively, press the left touchpad button once. pop-up menu appears. Click Click...
  • Page 47 Drag Function Touchpad On/Off Function If you want to use the mouse only without using the Dragging refers to moving an item to another place after touchpad, you can turn the touchpad off. selecting it. To lock the touchpad function, press the Fn + ( ) keys. Press and hold down the left touchpad button over an item you want to drag and move the item to the new location. Move Holding down the left touchpad button Touchpad Scroll Function The touchpad scroll area provides the mouse wheel function (scroll function). Place your finger on the touchpad’s right edge for vertical scrolling or the bottom edge for horizontal scrolling and then move your finger along the edge to scroll the screen vertically or horizontally.

  • Page 48: Cd Drive (Odd)

    CD Drive (ODD) An optical disk drive is optional and may differ depending on your computer model. For detailed specifications, refer to the catalogue. Before You Start! One of the following optical disk drives is installed on this computer. Drive Type Function DVD-ROM Reads CD/DVD. RW-Combo You can read CDs and DVDs, and burn a CD. You can read CDs and DVDs, and burn CDs and DVDs. DVD Super Multi Supported DVD recording types include DVD±R, DVD±RW, DVD-RAM. Do not insert a cracked or scratched CD. ■ Otherwise, the CD may break and damage the optical disk drive when the CD rotates at a high speed. When you clean a CD or DVD title, wipe with a soft cloth from inside to outside. ■ Caution Do not eject a CD when the CD operating LED is on. ■ Inserting and Ejecting a CD Click the Eject button of the optical disk drive at the side of the computer. Emergency Status Indicator Hole Eject Button...

  • Page 49: Burning A Cd

    When the CD tray pops out, insert a CD or DVD until Burning a CD it clicks. If your computer has a writable CD drive, you can write data onto a CD or DVD or burn an audio CD. Cyberlink DVD Solution is supplied with the System Software Media (or an additional CD) so that you can burn a CD using the program. Install the provided software and use the software functions referring to the software help. Push the CD tray inward until it clicks. The CD drive status indicator is turned on. A CD drive’s reading and writing speed may ■ differ depending on the condition and type of the media. Note To eject a CD when the CD drive does not work ■ or the computer is off, place the end of a paper clip ( ) into the Emergency Hole until the CD tray is ejected.

  • Page 50: Multi Card Slot

    Multi Card Slot Using the multi card slot, you can read and write data to SD card and MMC. You can use a card as a removable disk and conveniently exchange data with digital devices such as a digital camera, digital camcorder, MP3, etc. Before You Start! A multi card slot is optional and is provided for some models only. ■ You have to additionally purchase a multi card with the necessary capacity depending on your requirements. ■ You can use a multi card just like any data storage device. A copyright protection function is not supported. ■ Since you can lose a card when moving the computer, keep the card separately. ■ Supported Cards SD Card...
  • Page 51 To Insert and Use a Memory Card You can save, move and delete data by double- clicking the corresponding drive. Insert a card into the slot according to the directions printed on the slot. Example) SD Card Click Start > My Computer. The inserted memory card is displayed. Since you can only use the card after formatting it, if it is not formatted, format the card referring to the descriptions of “To format a memory card”. Using a Mini SD and RS-MMC Since the above cards are too small, you cannot insert the cards into the slot directly. Note Insert the card into a dedicated adapter (available from most electronic retailers) and then insert the...
  • Page 52 To remove a memory card To use a card to exchange data with a digital ■ device such as a digital camera, formatting the data using the digital device is recommended. Push the tip of the card lightly. Caution When you try to use a card, which is formatted in ■ the computer, in another digital device, you may have to format the card again in the device. You cannot format, write or delete data from a ■ Memory Stick, Memory Stick Pro, SD, or SMC If the card pops up with a clicking sound, remove the card with a write protection tab when it is in the card. Lock position. Inserting and removing a memory card ■ repeatedly may damage the memory card. If you remove the multi memory card using the ■ Safely Remove Hardware icon ( ) in the Taskbar, you will not be able to use the multi To format a memory card...

  • Page 53: Pci Expresscard Slot

    PCI ExpressCard Slot You can use PCI Express cards using this slot. The PCI ExpressCard slot can be regarded as the next generation PCMCIA card specification and supports LAN, TV Tuner and Sound cards. This computer’s slot supports the Express Card/34 and Express Card/54 specifications. Before You Start! Remove the dummy card installed to protect the slot first. Lightly push the dummy card of the slot. The dummy card pops up. ■ Eject the dummy card. This slot is a PCI ExpressCard slot. You cannot connect a PCMCIA card here. ■ To insert a card To remove a card Insert a card into the slot on the side of the Double-click the Safely Remove Hardware icon ( on the taskbar. computer. Select the PC card to be removed and click Stop. If the Stop a Hardware device window appears, click the OK button. Push the Eject button of the PC card slot lightly. PCI ExpressCard Slot Then the Eject button pops up.

  • Page 54: Connecting A Monitor

    Connecting a Monitor Using an external display device is useful when you are giving a presentation or watching a video or movie through your monitor. Before You Start! You have to buy a connection cable additionally. Connecting a Monitor Viewing Through a Monitor Connect the monitor to the Monitor port. You can switch the display device using the shortcut key. Switching the Display Device using the Shortcut Key Press the Fn + ( ) key combination once. Then the Easy Display Manager screen appears in which you can select a display device. Whenever you press the ( ) key while holding down the Fn key, the selected option is changed. Example) Selecting LCD+CRT Clone You can also connect a TV or projector supporting a monitor port (15-pin, D-Sub).

  • Page 55: Adjusting The Volume

    Using EDS Adjusting the Volume using the Volume Enables listening to surround sound using stereo Adjustment Program speakers. To listen to more stereophonic sound, click Start > All Click the Volume icon ( ) on the taskbar and slide the Programs > Samsung > Samsung EDS > Samsung volume control bar to adjust the volume. EDS or double-click the EDS icon ( ) on the Taskbar and select a surround mode from the pop-up menu. To disable EDS, select Enhanced Digital Sound OFF from the pop-up menu. To disable EDS, select Enhanced Digital Sound Mute OFF from the pop-up menu.

  • Page 56: Using Recorders

    Using Recorders This section describes how to perform recording on a Select Recording Control and Mic in Volume from computer by using Windows Recorder. Show the following volume controls and click OK. Connect a microphone to the microphone jack. When Recording Control window appears, make sure all the Mute boxes are unchecked. Increase the recording volume to increase the recording Click Start > Control Panel > Sounds, Speech, and sensitivity and close the window. Audio Devices > Sounds and Audio Devices. Click Start >...

  • Page 57: Chapter 3. Using Microsoft Windows Xp

    Chapter 3. Using Microsoft Windows XP About Microsoft Windows XP Tour Windows XP Help and Support Windows XP Screen Layout Desktop Start Menu Window Control Panel Running Control Panel User Account Changing Resolution and Color The screen shots used in this chapter may differ from actual screens depending on the Windows XP version and model.

  • Page 58: About Microsoft Windows Xp

    About Microsoft Windows XP Microsoft Windows XP (hereinafter referred to as Windows) is the basic operating system for computers. You should know how to use Windows in order to use your computer properly. Use Tour Windows XP as well as Help and Support to learn about how to use Windows. Tour Windows XP Tour Windows XP introduces the basic features and characteristics of Windows. Click Start > Tour Windows XP. Or, click Start > All Programs > Accessories > Tour Windows XP. Click the title at the right to view the description of the Windows features. The screen layout may differ depending on the computer model and the operating system. Note Click the title.

  • Page 59: Help And Support

    Help and Support Help and Support allows you to view the features and usage of Windows. Also, it allows you to search the information you want by entering a search keyword. Click Start > Help and Support. Search: Enter a search keyword to view the Help. Fixing a problem: If a problem occurs, you can get help. How to Change Desktop (Background Picture) What's new in Windows XP > Windows XP articles : Walkthrough ways to use your PC. After clicking Walkthrough : Personalize your PC, you can view the way to change the background picture on Customize Desktop.

  • Page 60: Windows Xp Screen Layout

    Windows XP Screen Layout Desktop If you turn on the computer, the Desktop will appear. The Desktop is the work space (screen) of a computer and is configured as follows: The screen layout may differ depending on the computer model and the operating system. Note Shortcut Icons You can launch programs by clicking the shortcut icons on the Desktop. Start Menu The menu from which you can launch Recycle Bin programs. You can drop useless files and folders here. Language Bar Switches text input language. Start button Taskbar System Tray with Clock Press the start button.

  • Page 61: Start Menu

    Start Menu The menu from which you can launch programs. Click Start. The Start menu appears. Alternatively, press the Windows key ( ) on the keyboard. Items that are pined to the Start menu. My Documents folder User account name My Computer Control Panel Frequently used programs Help and Support Search All Programs Displays the contents of the hard disk, the CD-ROM drive, the network drive(s), and floppy disks. My Computer It can also be used to search and open files and folders. Control Panel Enables users to configure settings on the computer.

  • Page 62: Window

    Window A window is a basic foundation for operating your computer. For instance, a window of your computer is configured as follows: Click Start > My Computer. Displayed menus and names may be varied. Double-click the Local Disk, which is a hard disk drive, to view the folders and files saved in your computer. If any folder or file is not shown, click Show Folder Contents. Minimize button Menu Bar Close button Title Bar Maximize button Toolbar Folder Icon Fast Operation Window Drive Icon (Memory) What is a Drive? A drive is a storage device that can read or write data such as folders and files. What is a Folder? A folder is just like a cabinet that keeps files or folders. You can keep files or folders of similar kinds in a folder.

  • Page 63: Control Panel

    Control Panel The Control Panel has a group of tools that enable to configure the Windows-related settings. Running Control Panel Click Start > Control Panel. Appearance Change the appearance of desktop items, apply a theme or screen saver to your computer, and Themes or customize the Start menu and Taskbar. Network Connect to the Internet, create a home or small office network, configure network settings to and Internet work from home, or change modem, phone, and Internet settings. Connections Add or Remove Install or remove programs and Windows components. Programs Sounds, Change the entire sound scheme or individual sounds made by your computer, or configures Speech, and the settings for your speakers and recording devices. Audio Devices Performance Schedule regular maintenance checks, increase space on your hard disk, or configure...
  • Page 64 Click Start > Control Panel. Printers and Other Change the settings for your printer, keyboard, mouse, camera, and other hardware. Hardware User Change user account settings, passwords, and pictures. Accounts Date, Time, Language, Change the date, time, and time zone for your computer, the language to use, and the way and Regional numbers, currencies, dates, and times are displayed. Options Accessibility Adjust your computer settings for vision, hearing, and mobility. Options Security View your current security status and access important settings to help protect your PC. Center...

  • Page 65: User Account

    User Account Windows XP allows to set multiple users with accounts. Enter your name and click Next. This section describes how to add a user account and to switch a it. Select an account type and click the Create How to Add a User Account Account button. Then, check the created account from the User Account window. Click Start > Control Panel. Click the target account and change the user account information. Click User Accounts and Create a new Account in You can change the account name, password, sequence. account type, and picture.
  • Page 66 To Delete User Account How to Switch a User Click Start > Control Panel > User Account. Click Start > Logoff. Select the user account to be deleted and click Click Switch User. Delete Account. The administrator account cannot be deleted. It can only be renamed or disabled. Click the user name to be switched from the Welcome screen. Then you can log on with a new user name.

  • Page 67: Changing Resolution And Color

    Changing Resolution and Color A resolution is the number of pixels displayed on the Click Settings and change the resolution and color screen. If you set the resolution to a higher value, items quality. Then, click OK. on the screen will be displayed smaller and the screen looks wider than the pervious. As color quality gets higher, more colors can be represented. Click Start > Control Panel > Appearance and Themes > Change the screen resolution. You can select a graphic chip set. Move the slider bar to set the resolution. Click the pull-down menu button to select the number of colors you want. It is recommended to set the resolution and color quality depending on the LCD type of your computer as the following: LCD Type Resolution Color Quality WXGA 1280 x 800 Very high (32-bit)

  • Page 68: Chapter 4. Using The Network

    Chapter 4. Using the Network Wired Network Wireless Network Connecting to Wireless LAN Connecting to computer-to-computer networks (peer-to-peer or ad hoc) Wireless Network Setup Using the Wireless LAN Setup Program Using Samsung Network Manager Perform Network Settings Using the network after moving location Sharing Internet Access Checking Network Status Connecting with a Modem Bluetooth Bluetooth Functions Bluetooth Software Setup Using Bluetooth...

  • Page 69: Wired Network

    Wired Network A wired network is a network environment used for a company network or broadband internet connection at home. Before You Start! You can also configure the network settings using the Samsung Network Manager. p. 77 Connect a LAN cable to the computer’s LAN port. Select Local Area Connection and click the right button of the touch pad and select Properties. Click Start > Control Panel > Network and Internet Connections > Network Connection. Click Manage Network Connections from the left pane.
  • Page 70 Click General tab and select a LAN driver from Configure IP settings. Connect using:. Select Internet Protocol(TCP/IP) Select Obtain an IP address automatically when and click Properties. using DHCP. If you use a static IP, select Use the following IP address and enter the values. The displayed LAN driver may vary depending on the LAN device type. Click Install to add a network component as shown in the figure below: You can add a client, a service, or a protocol. If the IP of your computer is not automatically assigned, contact the network administrator. If all settings are made, click OK. Now the network configuration is finished.
  • Page 71 Using both DHCP and a fixed IP simultaneously Using the Alternate Configuration providing by Windows XP, you can set both automatic and fixed IP addresses and then you can select to use either of them to connect to the Internet. Click Start > Control Panel > Network and Internet Connections > Network Connection > Local Area Connection by using the right button of the touch pad and click Properties. Select Internet Protocol (TCP/IP) and click Properties. Select the Alternate Configuration tab, select User configured and fill in the fields.

  • Page 72: Wireless Network

    Wireless Network A wireless network allows computers to share resources or an internet connection without using LAN cables between them. Before Use! This description is applied only to the models equipped with wireless LAN cards or devices. You can set a wireless network by using ■ Samsung Network Manager as well. p. 77 A wireless LAN device is optional when purchasing. Click a symbol, +, from Start > Control Panel > Performance and Maintenance > System > Hardware Tab > Device Manager > Network Adapter to check the device type. Some of the pictures shown in this description may vary depending on the wireless LAN device. Press the Fn + ( ) key and enable the wireless LAN features to use wireless LAN. Once the wireless LAN is enabled, the wirelss LED ■ ) turns on. Types of Wireless LAN Connections Small Office Network ■...

  • Page 73: Connecting To Wireless Lan

    Connecting to Wireless LAN If an AP exists near your location, you can easily connect to wireless LAN in the method provided by Windows XP. For a network key, contact the network administrator. If you use the program provided by a wireless LAN card provider, connect to wireless LAN after seeing page 76 of this document. The following description is based on Windows XP Once Connected to AP is displayed, you can use a Service Pack 2; thus, the pictures may vary. wireless network. Click the Wireless Network Connection icon ( ) from the Taskbar using the right button of the touch pad. Then, click View Available Wireless Networks. To check the network connections Place the mouse on the Wireless Network Connection icon ( ) from the Taskbar. Then, the status will appear. Select an AP to be connected and click Connect.

  • Page 74: Connecting To Computer-To-Computer Networks (Peer-To-Peer Or Ad Hoc)

    Connecting to computer-to-computer networks (peer-to-peer or ad hoc) In computer-to-computer wireless networks, you can Click Change the order of Preferred Networks. wirelessly connect 2 or more computers that have wireless LAN modules. Using this method, a computer that is not connected to the Internet can share the Internet by accessing another computer connected to the Internet. (Refer to “Sharing Internet Access” on page 81.) You can connect by completing the following steps: Step 1. Set up a computer-to-computer network on a ■ computer. Step 2. Connect to the configured computer from other ■ computers. Step 1. Setting up a computer-to- On the Wireless Network tab, click Advanced. computer network Right-click on the Wireless Network Connection ) icon on the taskbar, and select View...
  • Page 75 Enter the network name (e.g. samsung), and Check that the configured network name (e.g. unselect ‘The key is provided for meautomatically’. samsung) is in the ’Preferred networks’item, and Enter the encryption key in the Network key field, click OK. and click OK. To prevent a network connection from an unauthorized user, it would be better to configure a network key (encryption key). A network key consists of 5 ~ 13 alphanumeric characters (e.g. magic), or of 10 ~ 26 hexadecimal numbers (ahexadecimal number is represented by numbers ‘0’ to ‘9’ or letters ‘a’ to ‘f’).
  • Page 76 Step 2. Connecting to the configured Enter a cryptographic key in the network key box and computer click Connect. Right-click on the Wireless Network Connection ) icon on the taskbar, and select View Available Wireless Networks. Select the wireless network name (e.g. samsung) specified in ”Connecting to computer-to-computer If the network key is not configured in ”Connecting to networks (peer-to-peer or ad hoc)” on page 7, computer-to-computer networks (peer-to-peer or ad and click Connect. hoc)” on page 73, just click Connect, without any keystrokes. When connected to the wireless network, the system displays Connected in the selected network of the Network Connection window. Checking the connection status Move the mouse pointer over the Wireless Network Connection ) icon on the taskbar, and the connection status is displayed.

  • Page 77: Wireless Network Setup Using The Wireless Lan Setup Program

    Wireless Network Setup Using the Wireless LAN Setup Program The procedures to connect to an access point using a Enter a profile name to be used for the connection wireless LAN configuration program are described. Since and select the security settings of the AP to be the wireless LAN configuration program is included in the connected to in the Security tab. System Software Media, the user has to install the program. The network authentication, encryption type and Atheros Wireless Network Adapter Device password of an access point are configured through the access point management program. For the security information, check the security settings of an access Insert the System Software Media into the CD drive point or ask your wireless network administrator.

  • Page 78: Using Samsung Network Manager

    ■ Easy Internet configuration. p. 81 Enables the feature that allows two computers to share an Internet using one Internet line. Sets one computer as the sharing server and the other computer as the client to use the Internet in both computers. ■ Easy check-up for the network connection status. p. 8 Perform Network Settings You can set up a wired network or wireless network. Click Start > All Programs > Samsung > Samsung When different networks are used in different places, you Network Manager > Samsung Network Manager. must set up the network environment for each place. The progress of configuration is displayed while the network is being set up. Click Add. If you use a wired LAN, connect the LAN cable to the wired LAN port. Press the <Fn>...
  • Page 79 Select an icon to choose the network location and Select a device and configure IP settings. Then, click enter the location name (for example, “Home”) and Next. click Next. Select Internet Direct Connection and click Next. Choose Device Select between wired LAN and wireless LAN. IP Settings Contact the network administrator and enter the IP information if the IP is not an automatic IP. Get IP Automatically Select this option and perform automatic IP settings if you use DHCP.
  • Page 80 When the Printer Setting window appears, click When the network setting is complete, an icon for the added location is created within Finish. To add a printer, click Add Printer. The Add the Saved Locations window. Now you can use the Printer Wizard appears. Set up theprinter according Internet or add a new network location. to the instructions displayed on the screen. When the printer has been added, click the Show printer button, select the newlyadded printer and then click the Finish button. To not add a printer, select No Default Printer and then click the Finish button. When the network setting is complete, the ’Do you want to move to newly added location now?’ message appears. If you select ’Yes’, the network settings for the added location are applied. When the network settings for the added location are applied, the added place and the corresponding network connection information is...

  • Page 81: Using The Network After Moving Location

    1. Right-click over the Wireless Network access the network without performing the network setting Connection ( ) icon on the Taskbar and click procedures regardless of your location. View Available Wireless Networks. 2. Click Search AP from the Wireless menu to search for wireless LAN APs. Select an available wireless network (e.g. SAMSUNG) and click the Run Samsung Network Manager when connected to Connect button. For information on available the Internet. wireless LAN APs, ask your network administrator. Available AP Select an icon that represents the corresponding location from the Saved Locations window and then click Move. Connect 3. The network key (security key) input window appears.

  • Page 82: Sharing Internet Access

    Sharing Internet Access Set one computer as the sharing server and another computer as the client for two computers to share an Internet using one Internet line. Once the configuration is complete, you can use the Internet immediately. If you perform Internet sharing setup by using Samsung Network Manager, the program must be installed into both computers. There are three methods for setting each computer as a sharing server and a client as shown in the table. This document describes how to do so by giving an example to the typical connection method 1 (Wire+Wireless). Sharing Server (Hereinafter referred to as server) Computer that is equipped with two LANS and is directly connected to an Internet. Sharing Client (Hereinafter referred to as client) Computer that is not directly connected to the Internet and is able to use the Internet through the sharing server. How to Connect the Client to the Server Network Device of the Server Network Device Connection Check the connections before connecting to the Connection Connects to Type Internet.
  • Page 83 How to Set up Sharing Server Set up the network device to be connected to the external Internet as shown in the figure below and Check if the LAN cable is properly connected before click Next. setting up the sharing server. Determining whether to use a firewall Run Samsung Network Manager on the computer that will be used as the sharing server. Click Add. Select the icon that shows the network location and enter the location name (for example, Home-Sharing Server) and click Next. IP address setting Select a network device Select the sharing server and click Next.

  • Page 84: How To Set Up The Sharing Client

    How to Set up the Sharing Client Set up the device to be connected to the client as shown in the figure below and click Next. This description is discussed based on the wireless connection to the sharing server. The sharing server has to be turned on and the wireless LANs in both computers Because the wireless connection name and network have to be active. key entered in the sharing server must be entered in the client as well, remember them. Run Samsung Network Manager on a computer that will function as the sharing client. Check the settings and click Next. Click Add. Click Add Printer and set up a printer following the instructions in the wizard. Once printer addition is complete, click Refresh. Select the icon that shows the network location and Select the added printer and click Complete. enter the location name. Click Next.
  • Page 85 Select a printer and click Complete. Check if the sharing server turns on because this is mandatory. If you connect to the sharing server through a wireless LAN, the wireless LAN of the If you don’t want to add a printer, just click Complete server must be turned on. without following the instructions in the wizard. Run Samsung Network Manager on the sharing If the “Do you want to move to the added location client computer. now?” window appears, click No. If the icon for the added location appear, it means that the client configuration is complete. Click the icon for the location that has been set as If you click Yes, the computer connects to the the sharing client in the Shared Location window and sharing server and you can immediately use the click Go.

  • Page 86: Checking Network Status

    Checking Network Status If the network connection is not available, you can easily When the diagnosis is complete, out of order devices find the causes by checking the network status. are marked by the exclamation mark icon. For detailed device status, read the description in the Run Samsung Network Manager. lower part of the window. Reconnect and set up the device according to the diagnosis result. Click Diagnose Status on the Mngmnt menu. The Network Connection Picture window appears. If you click Start, checking the network will start. XXXXXXXX XXXXXXXX...

  • Page 87: Connecting With A Modem

    Connecting with a Modem The procedures to connect to the Internet via a phone connection are described below. Before You Start! To connect to the Internet, you have to subscribe to an Internet connection service of an Internet service provider (ISP). ■ A modem port is optional and provided for some models only. ■ Connect the phone Cable to the Modem port. Take care to not connect a digital phone line to the modem port. Connect to the Internet according to the instructions of your Internet service provider (ISP). If the Internet connection is terminated abnormally, the connection is not released and the corresponding cost can be accrued. Note...

  • Page 88: Bluetooth

    Bluetooth Bluetooth is a wireless communication technology that allows access to devices nearby such as a computer, mobile phone, printer, keyboard or mouse without a cable connection. Bluetooth enables file transmissions, Internet access, a private area network function, and access to a keyboard, mouse and printer between devices supporting the Bluetooth function without a cable connection. Before Use! The Bluetooth function is only available between devices supporting Bluetooth (computers, mobile phones, PDAs, printers, etc.), and the ■ function may be restricted depending on the device profile. The Bluetooth function is optional and may not be supported depending on your model. ■ Compatibility with a Bluetooth device not certified by a Bluetooth certification or logo is not guaranteed. ■ Bluetooth Functions You can exchange files between 2 Bluetooth devices. You can exchange files with other File Transmission computers, mobile phones, PDAs, etc. You can connect to another computer with the Bluetooth function as you access a Network Access wireless LAN in Ad-Hoc mode or connect to the Internet through an AP or Internet Connecting Sharing Server. Network Access through a Phone You can connect to the Internet through a Bluetooth mobile phone. Connection Data Sync You can synchronize the PIMS data (Outlook E-mail address data) with mobile phones, (Synchronization) PDAs, notebook computers, etc. supporting Bluetooth. Electronic Business You can exchange electronic business cards with mobile phones, PDAs, notebook Card (Vcard) computers, etc. supporting Bluetooth.

  • Page 89: Bluetooth Software Setup

    Bluetooth Software Setup Bluetooth software is installed on computers supporting In the setting up steps, enter a device name to be ■ Bluetooth. displayed in t he Bluetooth Manager program. Enter For first time use, set up the Bluetooth software as a name in the Computer Name field and select follows. Laptop for the Computer Type field. Also, a step appears for selecting the services to be ■ provided by your Bluetooth device for other Bluetooth devices. At this point, the program automatically Double-click My Bluetooth Places icon( detects available services and displays them as selected. It is recommended not to change the on the desktop. default selection. Click the Next button to start setting up. If you change the service settings, the driver necessary for the additionally selected services are installed. At this point, a warning message may appear informing you that there is no Microsoft logo.
  • Page 90 If the driver installation is complete, the next step If the settings are complete, the My Bluetooth proceeds which searches for nearby Bluetooth Environment window appears. devices. Since you do not have to search while setting up, click Skip and finish the settings.

  • Page 91: Using Bluetooth

    Using Bluetooth Exchanging Files between Bluetooth Describes how to exchange files between computers supporting Bluetooth and how to use other Bluetooth computers devices. The procedures to exchange files and folders between Bluetooth computers are described below. Bluetooth Help Bluetooth Help provides detailed procedures on using On the computer that is sending a file (hereafter Bluetooth functions. Computer A), right-click the Bluetooth icon ( ) in Double-click My Bluetooth Settings on the Desktop and the notification area and select Quick Connection > press the <F1> key (Help). File Transmission > Search for Device. Select Start >...
  • Page 92 In the Select Device window, click a computer to be When the Bluetooth Security Setting window connected (hereafter Computer B). appears, enter the Bluetooth security code (or Bluetooth PIN) and click Start Pairing. The Bluetooth PIN Code is a password used for the connection between two Bluetooth devices, the user just enter the same PIN Code (for example, same numbers) on both Bluetooth devices to make a connection. After a short while, the Bluetooth PIN Code required dialog box appears on Computer B, enter the code that you have input in Step 3 above.
  • Page 93 Connecting Keyboard, Mouse, Joystick If the FTP File Access Privilege Request window and Headset devices appears on Computer B, click the window. If the Select Access Permission window appears, click OK. The procedures to use Bluetooth HID devices (keyboard, mouse, joystick, etc.) or a headset, etc. on the computer are described below. The file transmission window appears on computer A. Drag files or folders to send onto the window, and The Bluetooth PIN Code is a password used for the the files or folders are automatically transmitted. connection between two Bluetooth devices, the user just enter the same PIN Code on both Bluetooth devices to make a connection. Turn on the Bluetooth function on the device to connect to (mouse, keyboard, joystick or headset). Some devices have a button to turn on the Bluetooth function, so see the corresponding device manual. Double-click the My Bluetooth Settings icon ( on the Desktop. If the file transmission is complete, close the File Transmission window. The received files are saved in the C:\Documents and Settings\[user name]\My...
  • Page 94 If the My Bluetooth Settings window appears, click If the Bluetooth PIN Code input window appears, View devices in range. enter a PIN code referring to the manual of the corresponding device. The PIN code for an HID If the device to connect to appears, click the device. device is generally printed in the manual of the (for example, mouse) corresponding device. If you enter the PIN code, you can immediately use the device. A Bluetooth keyboard and mouse work only in Windows. They will not work in MS-DOS mode or in Hibernation mode. If the device does not appear, click View devices in range. If the device has not appeared yet, since this menu changes to Search devices in range, click Search devices in range to show the device.
  • Page 95 To use a Bluetooth device after stopping it, select Start Bluetooth device like above. ■ Using the network connection or file transmission function, multiple Bluetooth devices can be connected. However, since connecting with multiple devices may slow down the data rate or make the connection unstable, connecting with one device at a time is recommended. ■ The Bluetooth function of a Bluetooth PDA, mobile phone, mouse or keyboard may be turned off. To use them in connection with a Samsung computer supporting Bluetooth, you must check if the Bluetooth function of the device to connect to is turned on. For the procedures on turning on the Bluetooth function of a device, see the manual of the device. ■ The services provided by Bluetooth devices may vary depending on their capability. For the services provided by Bluetooth devices, see the manual of the device.

  • Page 96: Chapter 5. Using Applications

    Chapter 5. Using Applications Introducing Programs CyberLink PowerDVD (Optional) Samsung Update Plus (Optional) Using AVStation premium (Optional) Getting Started and Screen Layout MUSIC Station PHOTO Station MOVIE Station AVStation Viewer (Optional) Start / Exit AVStation Viewer Screen Layout MUSIC Station PHOTO Station MOVIE Station...

  • Page 97: Introducing Programs

    Introducing Programs Using the software supplied with the Samsung computer, you can easily use functions and troubleshoot problems. Try to use the software after learning about the basic use of the software. For detailed information, refer to the help section of the corresponding software. Before You Start! Every software program may not be provided depending on your computer model. In addition, the screen capture images may differ from actual ones depending on the computer model and software version.
  • Page 98 Multi Media Functions Management Functions  Samsung Update Plus ( ) (Optional)  CyberLink PowerDVD ( ) (Optional) Samsung Update Plus is a software function that To use this program, you have to install the program examines and updates the Samsung software and manually using the additionally supplied System drivers installed on your Samsung computer to the Software Media. p. 99 most recent versions. p. 100  AVStation premium ( ) (Optional)  Samsung Network Manager (...
  • Page 99 Troubleshooting Functions  Easy Display Manager (Optional) Easy Display Manager is a program that displays the changed setting on the screen when a setting is changed by pressing the shortcut keys, and enables  SAMSUNG Magic Doctor ( ) (Optional) changing the display mode through the Display SAMSUNG Magic Doctor is troubleshooting software Settings window. provided by Samsung Computer for system diagnosis, and restoring the system. The system diagnosis function enables users to diagnose system problems without assistance from others. Example) T he icon that appears when pressing the Fn + ( ) keys to change the screen brightness.

  • Page 100: Cyberlink Powerdvd (Optional)

    CyberLink PowerDVD (Optional) You can enjoy audio and video playback of your DVD movies using the Cyberlink PowerDVD program. Before You Start! CyberLink PowerDVD is optional but not offered for some models. Insert a DVD title into the DVD drive. Click Play from the CyberLink skin menu. The DVD movie starts to play. Select Play DVD Video and click OK. DVD movie starts to play in a moment. Play Configuration Detailed Instruction: ■ For detailed instruction, click Start > All Programs > CyberLink PowerDVD > CyberLink PowerDVD help. DVD region code information: ■ Each DVD-Video disc contains one or more region codes, denoting the areas of the world in which distribution and playback are intended. The commercial DVD player specification dictates that a player must only...

  • Page 101: Samsung Update Plus (Optional)

    Samsung Update Plus does not provide updates for applications installed after purchasing the computer. Note To update the software and drivers Click Search for and Install Updates and click Search for New Updates. Select Start > All Programs > Samsung > Samsung Update Plus > Samsung Update Plus. If this is the first time you are running the program, a window will appear asking you if you agree to the agreement in the window. Click Agree to use this software.
  • Page 102 If there are available software or driver updates for Automatic update items display your computer, the available updates will be listed. By default, your computer is configured to automatically Select the required updates from the list and click search for updates. If there is a new update available, Install Update to start the update. (The update list this is notified in the notification area. Click the balloon help icon in the notification area. Here you will be able to on the screen may differ depending on the computer find the latest available updates. model.) Updates that must be installed separately. If you select Install as an update item that must be installed separately, a message appears informing you of this. Follow the instruction message to correctly install...

  • Page 103: Using Avstation Premium (Optional)

    Before You Start! AVStation premium is optional and may not be provided depending on the model. ■ The screens used in this manual may differ from actual screens according to the program version. ■ TV Station is only available for systems supporting the TV function. ■ For detailed usage, see the program help. ■ Getting Started and Screen Layout To launch the program, select Start > All Programs > Samsung > AVStation premium > AVStation premium. Alternatively double-click the AVStation premium icon ( ) on the Desktop. Exit Menu Bar Click the Exit button to exit the program. Library Station Bar MUSIC You can play a music file or an audio CD.

  • Page 104: Music Station

    Launch AVStation premium and click MUSIC on the Station Bar. Station Bar MUSIC Menu Bar MUSIC Library Playlist Playlist Control Buttons Register a File EDS Setting Button Play Control Buttons Play Options Volume Control What is EDS (Enhanced Digital Sound)? EDS (Enhanced Digital Sound) is a sound quality enhancement technology developed by Samsung Electronics. You can listen to clearer sound if you enable the EDS function when playing music or video on AVStation premium. If the Samsung EDS program is installed, the EDS function of AVStation will not work.

  • Page 105: Playing An Audio Cd

    Playing an Audio CD The tracks on the audio CD are displayed in the Playlist and the first track is automatically played. The procedures to play an audio CD are described below. Launch AVStation premium and insert an audio CD into the CD drive. In the Audio CD window, select Play Audio CD using Samsung AVStation and click OK. If an audio CD is already in the CD drive, double-click the album title in the Audio CD folder of the Library and add the tracks to the Playlist. The tracks added to the Playlist are played.
  • Page 106 Playing a Music File Play a Track not registered to the Library Click File > Open, select a music file to be played and If a music file is registered to the MUSIC Library, you can click . The selected track is registered to the Library and easily play the music file. played. For the procedures to register tracks to the Library, see Creating My Playlist page 106. My Playlist is a personal album with which you can collect, manage and play your favorite music files. For the procedures to create My Playlist, see the descriptions of MUSIC Station in Help. Move to MUSIC Station and double-click All Music. Double-click a music file. The file is added to the playlist and played.

  • Page 107: Adding Music Files To The Library

    Adding Music Files to the Library Select a folder which included music files and click OK. The music files in the folder are added to the MUSIC Library is a library holding music files used by Library. MUSIC Station. The procedures to add music files saved on the computer to the Library are described below. You can add files and folders or, search and add files. As an example, the procedures to add a folder are described below. Click the Register a File ( ) button below the Library and click Add by Folders. The tracks used in AVStation are automatically added to the Library.

  • Page 108: Photo Station

    PHOTO Station Launch AVStation premium and click PHOTO on the Station Bar. PHOTO Menu Bar Station Bar PHOTO Library Preview/Zoom-in Image Editor Tab Image Viewer Tab Register a File Move to a Higher- Level Folder...
  • Page 109 Viewing an Image The procedures to view images registered to the PHOTO Library are described below. For the procedures to register image files to the Library, see page 111. Move to PHOTO Station and double-click All Images. Click a folder which includes images, and the images in the folder are displayed in the Image Viewer window. Image Viewer Window Image...
  • Page 110 Double-click an image. The selected image is zoomed in. ■ Viewing an Image not registered to the Library Click File > Open, select an image file to view and click Open. The selected image file is registered to the Library and displayed in the Image Viewer window. ■ Viewing an Image in full screen or through a Slide Show Click the Full Screen ( ) button or SlideShow ( ) button below the Image Viewer window. To return to the Image Viewer window, press the <Esc> key or double-click the screen. ■ Watching a Slide Show while listening to Music To watch a slide show while listening to music, play music from MUSIC Station and run SlideShow.
  • Page 111 Editing an Image Edit the image using the Shape, Edit, and Effect tools. You can change the shape of an image, edit an image or apply special effects to an image. The image editor functions are described below. Shape tool: Change the shape of an image through cut, resize. Edit tool: Draw a line, add some clip art or enter letters. Select an image to edit in the Image Viewer window, Effect tool: Apply various effects to an image. and select the Image Editor tab. The Image Editor screen appears. When finishing editing an image, click the Save Edited Image ( ) button below the Image Editor...
  • Page 112 Adding Images to the Library The PHOTO Library is a library holding image files to be used by PHOTO Station. The procedures to add image files saved on the computer to the Library are described below. You can add files, add folders or search and add files. As an example, the procedures to add folders are described below. Click the Register a File ( ) button below the Library and click Add by Folders. Select a folder which includes image files and click OK. The image files in the folder are added to the Library. The image files used in AVStation are automatically added to the Library.

  • Page 113: Movie Station

    MOVIE Menu Bar Station Bar MOVIE Library Video Play window Register a File Capture Button EDI Setting Button Play Control Buttons EDS Setting Button Volume Control ( p. 103) What is Enhanced Digital Image (EDI)? EDI (Enhanced Digital Image) is a visual quality enhancement technology developed by Samsung Electronics. You can view a clearer and sharper picture by enabling the EDI function when watching TV or playing a video on AVStation premium. However, some TV tuners and graphics cards are not supported by EDI. For information on EDS (Enhanced Digital Sound), see page p.10...
  • Page 114 Move to MOVIE Station and double-click All Movies. to show the Play Control bar. To play at the default screen size, press the <Esc> key or double-click the screen. Double-click a video file. The file is played. ■ Capturing the Video Screen Click Capture Current Screen ( ) below the Play window when the desired image appears on the screen and click OK. Captured images are saved in the C:\Program Files\ Samsung\AVStation Premium xx\Data\Captured Images folder. In addition, you can view captured images in the PHOTO Station > Captured Images folder.
  • Page 115 Adding Videos to the Library The video files used in AVStation are automatically added to the Library. The MOVIE Library is a library holding video files to be used by MOVIE Station. The procedures to add video files saved on the computer to the Library are described below. You can add files, add folders or search and add files. As an example, the procedures to add folders are described below. Click the Register a File ( ) button below the Library and click Add by Folders. Select a folder which includes video files and click OK. The video files in the folder are added to the Library.

  • Page 116: Avstation Viewer (Optional)

    TV Station is only available for systems supporting the TV function. ■ Start / Exit AVStation Viewer To start AVStation Viewer ■ Select Start > All Programs > Samsung > AVStation premium > AVStation Viewer from Windows. ■ Press the AV ( ) button when the computer is on or off to launch AVStation Viewer. To exit from AVStation Viewer Move the mouse pointer to the top of the screen and click the Exit ( ) button.

  • Page 117: Screen Layout

    Screen Layout MUSIC You can play a music file or audio CD. PHOTO You can view a photograph or image file one by one or in a SlideShow. MOVIE You can play a video(movie) file. Settings You can set the Music, Photo and Movie settings. To move to the start screen while using the program, press the AV( ) button or <ESC> key. ■ Or, move the mouse pointer to the top left in the current screen and click the AVStation icon ( ■...

  • Page 118: Music Station

    MUSIC Station The procedures to play a music file or and audio CD are described below. Playing a Music File The procedures to play a music file registered to the MUSIC Library are described below. (For the procedures to register files, see page 106. Launch AVStation Viewer and click Music. Click All Music and double-click a file in the right pane. The music file is played. Playlist Window Music File All Music...
  • Page 119 Playing an Audio CD Launch AVStation Viewer and insert an audio CD into the CD drive. In the AVStation Viewer start screen, click Music. Double-click the Audio CD in the left pane and double-click an album or music file in the right pane. The selected music file is played.

  • Page 120: Photo Station

    PHOTO Station The procedures to view images registered to the PHOTO The selected image is zoomed in on. Library are described below. (For the procedures to register image files to the Library, see page 111.) Launch AVStation Viewer and click Photo. Click All Images and double-click an image file in the right pane. To view an image in full sreen or through a SlideShow. Click the SlideShow or Full Screen button below the zoomed in image. To return to the previous status in SlideShow or full screen, press the <Esc> key or double-click the screen. All Images Image File...

  • Page 121: Movie Station

    MOVIE Station The procedures to play a video(movie) file are described below. Playing a Movie File The procedures to play a video file registered to the MOVIE Library are described below. p. 11 Launch AVStation Viewer and click Movie. Click All Movies and double-click a movie file in the right pane. The movie file starts to play. All movies movie File Showing the Play Control window Press the Spacebar key or move the mouse pointer. The Play Control window appears at the bottom.

  • Page 122: Chapter 6. Settings And Upgrade

    Chapter 6. Settings and Upgrade LCD Brightness Control BIOS Setup Entering the BIOS Setup The BIOS Setup Screen Setting a Boot Password Changing the Boot Priority Upgrading Memory Battery Installing/Removing the Battery Charging Battery Checking Battery Residual Amount Using Battery Longer Using the Security Lock Port...

  • Page 123: Lcd Brightness Control

    The LCD brightness has eight levels of degree. your computer reboots. By pressing the Fn+ , the LCD gets brighter by one Only the LCD brightness setting in the user settings level of degree. mode is maintained once you reboot the computer. For information on the other features of Samsung Battery Manager, see the description on batteries. p. 1 Adjusting LCD Brightness Using Samsung Battery Manager To Maintain the Changed LCD Brightness After Reboot Appropriate LCD brightness is set for each mode in Configure the following settings to maintain the LCD Samsung Battery Manager. In user settings mode, you brightness set using the screen adjustment key or can select the brightness level.

  • Page 124: Bios Setup

    BIOS Setup The BIOS Setup enables you to configure your computer hardware according to your needs. Before You Start! Use the BIOS setup to define a boot password, change the booting priority, or add a new device. ■ Since incorrect settings may cause your system to malfunction or crash, take care when configuring the BIOS. The functions of the BIOS setup are subject to change for product function enhancement purposes. ■ The BIOS Setup menus and items may differ depending on your computer model. Note Entering the BIOS Setup Turn the computer on. When the booting screen (SAMSUNG logo) appears, press the F2 key to enter the BIOS Setup.
  • Page 125 After a moment, the BIOS setup screen appears. The items in the BIOS setup may differ depending on the product. Setup Menu Help Help for the selected item appears automatically. Setup Items...

  • Page 126: The Bios Setup Screen

    The BIOS Setup Screen Menu Description Main Used to change the basic system and environment settings. Advanced Used to configure advanced functions on your computer around devices and chipsets. Security Used to configure security functions, including passwords. Boot Used to set the boot priority and other boot options Exit Used to exit the Setup either saving the changes or not.
  • Page 127 System Setup Keys In the Setup, you have to use the keyboard. Press to view the Setup Help. Up & Down Keys Press to move up and down. F5/F6 Press to change the item value. Press to load the default Setup settings. Press to return to a higher level menu or to move to the Exit menu. Left & Right Keys Press to move to another menu. Enter Press to select an item or to enter a sub menu. Press to save the changes and exit Setup.

  • Page 128: Setting A Boot Password

    Setting a Boot Password When setting a password, you have to enter a password to use the computer or enter the BIOS Setup. By configuring a password, you can restrict system access to authorized users only and protect data and files saved on the computer. Before You Start! Do not lose or forget your password. If you have forgotten your password, contact a Samsung service center. In this case, a service fee will be charged. Setting a Supervisor Password Enter a password, press <Enter>, re-enter the password for confirmation, and press <Enter> again. A Supervisor Password is required to turn the computer The password can be up to 8 alphanumeric on or to start the System Setup. characters. Special characters are not allowed. When setting a Supervisor Password, users other than a supervisor cannot use the computer. Select the Security menu in the BIOS Setup. In the Set Supervisor Password item, press <Enter>.

  • Page 129: Setting A User Password

    Setting a User Password Changing the hard disk drive password For security purposes, you can only change a hard Users can start the system with a user password, but disk drive password after restarting the computer Caution by pressing the computer Power button. cannot enter the System Setup. By doing this, you can If you cannot change the hard disk drive password prevent other users from entering Setup. or the HDD Password Frozen message appears Before configuring a user password, a supervisor when entering the BIOS Setup and then selecting password must have been configured. Deactivating the Security > HDD 0 Password, press the Power button to turn the computer on again.

  • Page 130: Changing The Boot Priority

    Boot Device Priority Press <Enter> on the Boot Device Priority item. Boot priority order: ▼ IDE CD : xxxxxxxxxxxxxxxxxxx ▼ IDE HDD : SAMSUNG xxxxxxx ▼ USB KEY : Not Installed ▼ USB CDROM : Not Installed ▼ USB FDC : Not Installed ▼...

  • Page 131: Upgrading Memory

    Upgrading Memory One or more memory modules are installed on the computer. There are 2 memory slots and users can replace the installed memory or add new memory. Before You Start! Replace or install new memory only after shutting the computer down completely. Do not replace or install memory when the ■ computer is in Sleep mode. Disconnect mains power and remove the battery before continuing. ■ To utilize the dual channel feature, using memory modules with the same specifications (of the same capacity and from the same ■ manufacturer) is recommended. Only use the same type of memory as specified in the Product Specification ■ Adding a Memory Module Insert a new memory module into the memory slot at an angle of approximately 30 degrees aligning it to the angle of the memory slot. Remove the screw on the memory compartment cover at the bottom of the computer using a screw driver. Fixing Screw...
  • Page 132 Push the memory module down so that it is Close the memory compartment cover and fasten completely fixed. If the memory does not fit easily, the screw. push the memory module down while pulling the memory module latches outward. Removing a memory module Pull the memory module latches outward. Note The memory module will pop up. Remove the memory module out at an angle of 30 degrees.

  • Page 133: Battery

    Battery Please refer to the following instructions when running the computer on battery power without connecting the AC power. A Lithium-Ion smart battery is supplied with this computer. Before You Start! Carefully read and follow the precautions printed on the battery before using the battery. Precautions Use only chargers specified in the User Manual. Caution Never heat the battery pack, put it near or in a fire or use at a temperature higher than 60°C, as this may cause fire. Never cause a short circuit between the battery pack terminals or disassemble the battery pack. Carefully read and follow the precautions printed on the battery and the safety instructions in the User Manual before using the battery. p.16 Please refer to the system operation environment ( ) of this manual and operate and store the battery at room temperature. Installing/Removing the Battery Shutdown the system, close the LCD panel and To install the battery again, slide the battery into the place the computer upside down on a flat surface. system. The battery latches move inwards and fix the battery automatically. Pull the two battery latches outwards ( ), then remove the battery. Check if the battery latch has been moved inwards. Note...

  • Page 134: Charging Battery

    Charging Battery Checking Battery Residual Amount Insert the battery and connect the AC adapter to the This section describes how to check the battery residual amount. power input jack on your computer. Battery charging starts. Using Shortcut keys If you press the Fn + ( ) on the keyboard, the battery When charging is complete, the status indicator residual amount will be displayed on the screen for a short changes to light green. time. It is displayed only if the Easy Display Manager is Status Indicator installed. While being charged Orange When charging is complete Light Green Viewing in Battery When the AC adapter is Turns off disconnected If you separate the battery and press the PUSH button...

  • Page 135: Using Battery Longer

    Guide to the battery lifecycle Using Battery Longer The battery is an expendable item so its life gets shorter Using Samsung Battery Manager when used for a long time. It is time to replace it when the battery life is less than half of the figure when purchasing. Battery Manager is a management program that If you won’t use the battery for a long time, discharge allows you to use the battery efficiently. You can select it first for keeping. This will guarantee longer life of the the optimized power mode depending on the system battery. environment. Click Start > All Programs > Samsung > Samsung Battery Manager > Samsung Battery Manager. Select Power Mode Power-saving Effect...
  • Page 136 When Using Games or Multimedia General Mode The system may not operate properly in maximum This mode is appropriate for the regular environment and battery mode. It is recommended to connect the AC adapter to the system or to use the system in general it optimizes the performance of the system and battery. mode. Maximum Performance Mode Usage Mode of Samsung Battery Manager This mode is appropriate for the environment that requires The maximum battery mode optimizes the system ■ maximum system performance. The battery life may get operation speed to increase the battery run time, so the program execution time may get longer. shorter in this mode. If you change the power settings, the properties in ■...
  • Page 137 Disabling Unused Devices Turn on the computer again. When the SAMSUNG logo appears, press the F2 key to enter the Setup. If you turn off unused devices, battery lifetime will improve. Select Boot Menu > Smart Battery Calibration and Click Device Manager from Start > Control Panel press the Enter key. > Performance and Maintenance > Systems > Hardware tab. Right-click the devices that you are not using and select Disable. Enabling Battery Calibration If you charge the battery to use that has not been used up, the gap between actual battery capacity and battery residual amount happens to have. Accordingly the battery life may get shorter.

  • Page 138: Using The Security Lock Port

    Using the Security Lock Port You can connect a Kensington lock to the Security Lock port to prevent your computer being stolen when you have to use the computer in a public place. To use this feature, you have to purchase the Kensington lock additionally. To use the Kensington lock, refer to the product manual. Tie the Kensington lock cable to a fixed object and install the other end of the cable to the Security Lock port.
  • Page 139 Chapter 7. Appendix Using McAfee SecurityCenter (Optional) Using Samsung Magic Doctor (Optional) Diagnosing the System Reinstalling Software Running the system software Media Installing drivers and programs Reinstalling Windows XP Reinstalling Windows Reinstalling when Windows does not start Questions and Answers Windows Related Display Related Sound Related Modem Related Wired LAN Related Wireless LAN Related Games and Programs Related Bluetooth Security Center Other Questions Product Specifi cations Glossary Index...

  • Page 140: Using Mcafee Securitycenter (Optional)

    Using McAfee SecurityCenter (Optional) A computer virus is a program that damages computer files and information saved on a computer. A computer is infected by an already infected file or by another computer over the Internet. Let’s learn how to use McAfee SecurityCenter in order to scan and remove viruses and to protect your computer from various threats on the Internet. Before You Start! ■ When McAfee SecurityCenter is run for the first time, the Registration screen appears. Register according to the instructions on the screen. You have to register the software to protect the PC with the latest security information. ■ If you cannot find McAfee Security Center icon on the Taskbar or a shortcut icon on the Desktop, then double click McAfee Web Essentials icon and install the program. ■ If you install McAfee SecurityCenter and another anti-virus program (e.g. Norton Internet Security, Kaspersky, etc) on the same computer, your computer performance may become degraded and your computer may not be protected from threats due to a conflict between the programs. It is highly recommended installing only one security program. Scanning and Curing Viruses If a virus is found, remove the virus according to the instructions on the screen. Click Start > All Programs > McAfee > McAfee SecurityCenter.

  • Page 141: Using Samsung Magic Doctor (Optional)

    Using Samsung Magic Doctor (Optional) Magic Doctor is troubleshooting software provided by Samsung Computer. A user can diagnose system problems via one-click or by selecting diagnostic items. Before You Start! The screens used in this manual may differ from actual screens according to the program version. Diagnosing the System Select Start > All Programs > Samsung > When the system status diagnostics are complete, Samsung Magic Doctor > Samsung Magic the diagnostics result appears. Doctor. Click the Diagnose the System icon. If a problem has been found, click on Cure for Samsung Magic Doctor to cure the problem. The system status diagnostics start.

  • Page 142: Reinstalling Software

    Reinstalling Software If you have reinstalled the Windows operating system, or the system and program do not operate properly, you can re-install the driver and program using the system software Media. Before You Start! This computer is optimized for Microsoft Windows XP, therefore drivers for other operating systems are not included on the System Software Media. Running the system software Media Insert the system software Media into the CD-ROM drive. The initial screen appears automatically. ■ Minimum Installation: This displays the components (driver, Windows programs,etc) that, if not installed, may cause problems with the system performance.You can install only required components.

  • Page 143: Installing Drivers And Programs

    Installing drivers and programs Click Standard Installation in the main window of Click OK. The drivers and programs are the System Software Media. (Standard Installation is automatically installed as factory defaults. recommended) The system is scanned to display the drivers and programs that need to be installed. When done, restart the system.

  • Page 144: Reinstalling Windows Xp

    Reinstalling Windows XP You can reinstall Windows using the System Recovery CD when Windows does not work properly. Before You Start! A System Recovery CD may not be supplied depending on your computer model. ■ To reinstall Windows when Windows does not boot, refer to page 1. ■ Reinstalling Windows may delete data (files and programs) saved on the hard disk drive. Make sure to backup all important data. Samsung Electronics shall not be held liable for any loss of data. Note Reinstalling Windows Explain Standard installation option as a standard. ■ Standard installation: You can change the settings for partitioning, the installation folder, etc. during the Windows installation. However, reinstalling Windows may delete the data on the hard disk drive such as files, Insert the system recovery CD into the CD-ROM programs, etc. In order to minimize damage from data drive. loss, please remember to always back up data. In the initial screen, click Standard Installation. ■ Quick Installation: This re-installs Windows with the user data and the system configuration intact. The user data in the already existing Windows folders may be preserved as the existing Windows folders are overwritten.
  • Page 145 The description for the standard installation appears. After the installation process copies the necessary Click Yes. The installation starts, and the system will folders for the Windows installation, restart the be restarted after a while. system, and the message “Press any key to boot from CD” is displayed. You do not need to enter anything. In a moment, the Windows XP installation When Quick Installation is selected, Setup proceeds with Step 3 before automatically installing Windows. screen will appear to proceed with the installation. Quick Installation overwrites the existing Windows Note version, so that drivers or applications do not need to be reinstalled. When the Regional and Language Options window appears, click Next. After the system has restarted, the message ’Press any key to boot from CD’ appears. Do not press When a window that requires your name and any key at this time. After a while the partition organization pops up, enter your name and the configuration screen appears. To not change the organization and click Next. In the Windows XP partition, press Enter. Professional edition, an additional window that requires the computer name and the administrator password appears. Enter the computer name and What is partition configuration? the administrator password and click Next.

  • Page 146: Reinstalling When Windows Does Not Start

    Reinstalling when Windows does not start When Windows does not start, boot up with the System After the installation process copies the necessary Recovery CD and from there you can reinstall Windows. folders for the Windows installation, restart the system, and the message “Press any key to boot from CD” is displayed. You do not need to enter Insert the system recovery CD into the CD-ROM anything. In a moment, the Windows XP installation drive and start the computer. screen will appear to proceed with the installation. If the following message appears on the screen, Follow the instructions of the Windows XP press any key from the keyboard. installation wizard to continue with the installation. Press any key to boot from CD..When the installation is complete, the computer will restart. When the system has restarted, the Press any key to boot from CD message appears. Do not press any key at this time. After a while the Ignore the message. partition configuration screen appears. To not change the partition, press Enter. The system boots and the Windows and Windows Registration screen appears. Register Windows, following Select the desired file system (format). To maintain...

  • Page 147: Questions And Answers

    Questions and Answers This section provides information on possible problems, solutions and other references for system use. Windows Related Display Related The system does not shutdown properly. The LCD screen is too dark or too bright A When the system does not shutdown normally, press A Turn on the LCD backlight or adjust the screen and hold the Power button until the system manually brightness. Press Fn + ( ) to turn on the LCD shuts off. If the Power-Saving Mode is configured backlight or press Fn + ( ), Fn + ( ) to adjust into the Power button, press and hold for more than the screen brightness.
  • Page 148 When I connect a projector, and change the The shortcut icons are not displayed on the setting to display screen image on both the LCD screen even if I press the shortcut key. and the projector by pressing Fn + ( ) keys, screen is not displayed properly.

  • Page 149: Sound Related

    Installation or Custom Installation, then the  components of the sound driver are To remove the sound driver due to a problem or for automatically installed. an update, follow the procedures below. If you do not follow the sequence below, the sound driver may not be removed or the reinstalled driver, or may not work properly.  Select Start > Control Panel > Add or Remove Programs.  Remove Samsung EDS first.  Remove Realtek High Definition Audio Driver and restart the computer.

  • Page 150: Modem Related

    Modem Related ▶ Installing the Sound Driver after a Windows XP Reinstallation I cannot hear the modem sound. If you install the sound driver after reinstalling A1 Check that the telephone line is properly Windows XP, the Add Hardware Wizard (Modem connected to the modem. Device) window may appear during the sound driver installation. A2 Check that the modem driver is installed This happens because the High Definition Audio — properly. KB888111 Hotfix, which has been installed on your  Click Start > Control Panel > Performance system, has changed the settings to search for both and Maintenance >...
  • Page 151 How do I use my modem when dialing from I cannot make a call using an extension line. overseas? A In general, the dial tone of a PBX or a digital A1 Check that the modem is correctly phone switching system is not a continuous configured according to the current country. one, unlike that of a trunk line. Because the values for communication may differ Therefore, the modem may not make a call because according to the country, you may not be able to the modem mistakes the dial tone from a PBX or a connect via the modem due to an incorrect modem digital phone switching system as a busy tone. In this configuration.

  • Page 152: Wired Lan Related

    Wired LAN Related How do I receive a fax while the system is in power saving mode (Rest mode)? <Wake On LAN> function A To receive a fax in Standby mode, you have A1 <Wake On LAN> is a function that activates to set it up as follows. the system in rest mode when a signal (such as ping or magic packet commands) arrives  The automatic fax reception function of the from network (wired LAN). fax program needs to be activated. (For more information, see the corresponding fax program To use <Wake On LAN> function: manual.)  Select My Network Places >...

  • Page 153: Wireless Lan Related

    Wireless LAN Related  Click My Network Place> View network connections on the Desktop. I cannot find an AP.  Right-click over Wireless Network Connection and select Disable. ▶ Check the Wireless LAN LED. A Check if the Wireless LAN LED is on. If off, press the Wireless LAN On/Off button <Fn>+<F9> to turn it A2 The <Wake On LAN> function is configured so that it is supported in Standby mode (S3). To use this function in Hibernation mode (S4) or in the Turn Off ▶...
  • Page 154  Click Start > Control Panel > Performance and A2 When operating in EEE802.11g mode, if there is Maintenance > Administrative Tools > Computer a IEEE802.11b device operating nearby, you may Management and click Services and Applications experience low data rates or even disconnection as it > Services. In the right pane, double-click Wireless operates in Hybrid mode. Zero Configuration and check if the Startup Type is Automatic and the Status is Started. ▶ Check the authentication type. A A connection may be disconnected after a period of I cannot connect to an AP. (The wireless time if the “Use IEEE 802.1x network authentication”...
  • Page 155 ▶ Check the AP settings. A5 Check the Network Key (Encryption Key) settings again. If the automatic password converting function A1 Check if the surroundings are appropriate for a (passphrase function) is enabled and the wireless wireless LAN. A wireless LAN connection may be connection is normal but you cannot send data limited by the surrounding environment and distance. over the connection, please enter the Network Key Obstacles such as walls and door mats affect the (Encryption Key) manually. quality of the wireless LAN signal. You have to install an AP in a high, open position far away from any A6 Check the AP settings as follows. other radio signal sources. If the AP is excessively far away, or is installed at the end of a building and If there are multiple APs running at the same time, you are attempting to use the wireless LAN from the check the channel setting of each AP. If the interval other end, you may not be able to use the wireless between the channels of the APs is narrow, you may communication normally because the signal is experience electromagnetic interference. Set the blocked by obstacles between you and the AP (such channel numbers of the APs so that the internals as a wall).
  • Page 156 Although a connection has been established, I I have configured both wired and wireless cannot connect to the Internet. connections with the same IP address, but the network connections do not work properly. ▶ Check the TCP/IP settings. A You cannot use the same IP address for wired and A If you cannot connect to the Internet but you are wireless connections. To use only one IP address connected to an AP, check if the TCP/IP settings are...

  • Page 157: Games And Programs Related

    (For Intel PROSet) After installing PROSet, I Games and Programs Related cannot manage my wireless network in Windows. 3D game is not executed, or some functions are A When clicking Use Microsoft Client in the Tools not working. menu of the PROSet, you can manage wireless network in Windows.
  • Page 158 While playing a game, pressing the Fn + ( The picture is not displayed properly for some keys does not work or the screen is not properly games. displayed. A Some games may not display the picture properly A Some games and 3D application programs may when the screen resolution is set to 1024 × 768 and change the display device control. Therefore, the color quality is set to 32 bit. pressing the Fn + ( ) keys may terminate the For these games, set the screen resolution to running program or may display an abnormal screen.

  • Page 159: Bluetooth

    Bluetooth I have connected the headset, but I cannot hear I cannot find or connect the headset. sound normally. A1 If the headset is connected to another device and is A1 If the Bluetooth headset is properly connected to currently being used, you will not be able to locate a computer, the Control Pane Sound Playback it. In this case, even if you locate the headset, you Device changes to Bluetooth Audio (for a mono will not be able to connect it. Disconnect the headset...

  • Page 160: Security Center

    A2 Some headsets cause sound to be played Security Center intermittently depending on the Bluetooth driver and the firmware version. Check your Bluetooth To change the popup window display settings driver and firmware versions and download the when connected to the Internet. In the Windows latest versions by connecting to Zaigen (www.
  • Page 161  Enter a URL to want to allow pop-ups into When you see a Windows Security Alert icon Address of Web site to allow and click Add. ) appear on the right part of the Taskbar. With the Security Center feature added, Windows XP  You will find that the entered address is added to SP2 checks the Firewall, the automatic updates the allowed sites list. The next time you connect configuration and installation of virus-checking to the Web site, you will see pop-ups appearing.

  • Page 162: Other Questions

    A2 Set up Windows Automatic Updates. Other Questions This automatically downloads and installs critical updates via the Internet to keep your computer up to 4GB memory is not recognized by Windows date. correctly.  Click Automatic Updates in Start > Control Panel > Security Center > Manage security A This is due to a limitation in 32bit operating settings for. systems that exists in notebook computers of other manufacturers. Although the address space  From general tab of Automatic Updates window, of the 32bit operating system is 2³²= 4294967296 select Automatic (recommended). = 4,096MB = 4GB, all of it cannot be allocated to memory, as some of it needs to be used for A3 Two virus scanning programs on one computer may other purposes by the operating system. Because cause system conflicts. Remove one of the programs approximately 1GB of address space needs to be...

  • Page 163: Product Specifications

    Product Specifications The system specifications may differ depending on the derived models. For detailed system specifications, refer to the product catalogue. NP-R59/R59 plus/R60/R60 plus/P500/R61/R61 plus Intel Core 2 DUO Processor, Intel Core Duo/Solo Processor Intel Pentium Dual Core Processor, Intel Celeron M processor 1M / 2M / 4M Cache Memory 512~4GB. Max 4GB. Memory type : DDR2 SODIMM Main Memory ATI RS600ME(RD600) + SB600 Main Chipset 9.5mmH SATA HDD 2.5" (60G ~ 200G) Hard Disk Drive DVD-ROM, DVD-COMBO, Super Multi(DL) ATI radeon Xpress 1250M (Internal) Graphics ATI Radeon Xpress 2300 (external) Realtek ALC262 Codec Sound Chipset Fax/Modem : V.92 Wired LAN : Marvell 88E8039 10/100 Network Wireless LAN : 802.11BG Bluetooth 2.0+EDR PCI ExpressCard Slot PCI Express Card Support SD Card / MMC Multi Card Slot USB 2.0 Compatible X 3, VGA, RJ45, RJ11...
  • Page 164 Wireless LAN Specifications (802.11BG Card) Atheros AR5007EG Wireless Network Adapter  The Name of the Registered Equipment : Special Low Power Wireless Device for Wireless Data Communication Systems. Item Detailed Specifications Dimensions 30.0 × 50.95mm (Width X Height) Physical Operating Specifications Temperature And Temperature: Between 0°C and 70°C, Maximum Humidity: 85% Humidity Sleep Mode 726mW Power Receive Mode 1.353W Specifications Transmission Mode 2.046W Power .V Compatibility IEEE 802.11b, IEEE 802.11g Operating System Microsoft Windows XP/Vista...
  • Page 165  Radio Specifications RF Band 2.4GHz Supported Channels Channels allowed per country. Device Transceiver Standard Output Power MAX 10mW Modulation Scheme DSSS, CCK, OFDM 11b mode : 11, 5.5, 2, 1 Data Rate (Mbps) 11g mode** : 54, 48, 36, 24, 18, 12, 9, 6 Antenna Type Built-in Antenna * The data rate may differ from the real data transmission rate. ** 11g mode is supported only when you are connected to an IEEE 802.11g device (e.g. An Access Point supporting IEEE 802.11g).
  • Page 166 About the Product Capacity Registered Trademarks Representation Standard Samsung is a registered trademark of Samsung Co., Ltd. SENS is a registered trademark of Samsung Electronics The capacity of the storage device (HDD, SSD) of the Co., Ltd. manufacturer is calculated assuming that 1KB=1,000 Intel, Pentium/Celeron are registered trademarks of the Bytes. Intel Corporation. However, the operating system (Windows) calculates the Microsoft, MS-DOS, and Windows are registered storage device capacity assuming that 1KB=1,024 Bytes, trademarks of the Microsoft Corporation. and therefore the capacity representation of the HDD in “Memory Stick” and are trademarks of the Sony Windows is smaller than the actual capacity due to the Corporation. difference in capacity calculation. (E.g. For a 80GB HDD, All other product or company names mentioned herein are Windows represents the capacity as 74.5GB) registered trademarks of their respective companies. In addition, the capacity representation in Windows may be even smaller because some programs such as Recovery Solution may reside in a hidden area of the HDD. Macrovision Certification This product incorporates copyright protection technology that is protected by method claims of certain U.S.

  • Page 167: Glossary

    Glossary The Glossary lists the terminologies used in this User Guide. For terminologies other than these, look in Windows Help. Backup Direct X A way to save the current data to restore it later if An application interface developed to enable Windows necessary. A backup is a way to restore computer data application programs to access hardware devices when the data or computer is damaged. at a very high speed. Since the operating speed of graphics, memory and sound cards must be very fast Client to provide high quality video and sound for games, Direct X enables faster control and interaction between This refers to a computer that uses a shared network applications and hardware devices. By using Direct resource provided by a server. X, the multimedia performance of Windows has been hugely improved. DDR SDRAM (Double Data Rate Synchronous Dynamic Random Access Memory) Driver DRAM is a memory type whose cells consist of a Software that interacts between the hardware and...
  • Page 168 Firewall LCD (Liquid Crystal Display) A security system used to protect an internal network There are Passive Matrix and Active Matrix LCD types. or intranet from external networks through an This computer uses the Active Matrix type LCD called a authentication procedure. TFT LCD. Since an LCD is implemented by transistors instead of a cathode-ray tube unlike a CRT, its size can be slim. And because it does not blink, it reduces eye Hibernation Mode strain. A power mode that saves all data in memory to the hard disk and turns the CPU and hard disk off. When Network canceling Hibernation Mode, all application programs that were running are restored to their last state. A group of computers and devices, such as printers and scanners, connected by a communications link. A network can be either small or large and can be Icon connected permanently through cables or temporarily This refers to a small image that represents a file that through telephone lines or wireless links. The biggest users can use. network is the Internet, a worldwide network. LAN (Local Area Network) Notification Area A communications network connecting computers, This refers to the right area of the Taskbar including printers and other devices within a local area such as program icons such as the volume control, the power within a building. A LAN enables all connected devices options and the time.
  • Page 169 Quick Launch Sleep Mode This refers to a toolbar that can be configured so that A power mode that enables computers to save power you can launch a program such as Internet Explorer or consumption when they are not being used. When a display the Windows Desktop with one click. You can computer is in Sleep Mode, the data on the computer add any icon to the quick launch area of the Taskbar memory is not saved to the hard disk. If the power is and launch frequently used program by clicking that tuned off, the data in memory will be lost. icon. System File Server System Files refer to files that are read and used by In general, a server refers to a computer that provides the Windows operating system. In general, system files shared resources for network users. must not be deleted or moved. Share This refers to setting a resource of a computer such as a folder or printer so that other users can also use it. Shared Folder A folder that can be used by other users on the network.
  • Page 170 USB (Universal Serial Bus) This refers to a serial interface standard developed to replace the conventional interface standards such as Serial and PS/2. While USB 1.1 supports 12Mbps (12 million bits per second), USB 2.0 supports a data rate that is 40 times (480Mpbs) faster than that of USB 1.1. The data rate of USB 2.0 is equivalent to that of IEEE1394. Therefore USB 2.0 is used for A/V devices supported by IEEE 1394 and a 2nd HDD and CDRW that require a high data rate. Windows The name of an operating system developed by the Microsoft Corporation. Windows XP is installed on this computer. Windows Media Player A multimedia program included with Windows. Using this program, you can play a media file, create an audio CD, listen to a radio broadcast, search and manage media files, and copy files to a portable device, etc.

  • Page 171: Index

    Index Samsung Battery Manager AVStation Viewer LCD Brightness Samsung Network Manager Samsung Update Plus Security Lock Port Safety Precautions Battery Memory Shortcut Keys Battery Calibration Multi Card Slot Status Indicators BIOS Setup Bluetooth Booting Priority Network Network Status Diagnosis Touchpad CD Drive / Recording Charge Password Click User Accounts / Switch User 64 Connect / Output Monitor Phone Connection Playing Music Control Panel Product Specifications CyberLink PowerDVD Program Video Play Volume Control Desktop / Change Recorder Remaining Battery Charge Windows XP...

  • Page 172: Contact Samsung World Wide

    Contact SAMSUNG WORLD WIDE [U.S.A. / U.K. / HONG KONG] Contact SAMSUNG WORLD WIDE If you have any comments or questions regarding a Samsung products, contact the SAMSUNG customer care center. Customer Care Center Web Site U.S.A. 1 800 SAMSUNG (7267864) www.samsung.com U.K. 0870-726-7864 www.samsung.com/uk HONG KONG 8 698 698 www.samsung.com/hk [FRANCE] Comment contacter Samsung dans le monde Si vous avez des suggestions ou des questions concernant les produits Samsung, veuillez contacter le Service Consommateurs Samsung.
  • Page 173 [ITALY] Contatta SAMSUNG Se hai commenti o richieste sui prodotti Samsung contatta il nostro Servizio Clienti. Customer Care Center Web Site ITALY 800.76786 www.samsung.com/it/ [RUSSIA / UKRAINE] Customer Care Center Web Site RUSSIA 8-800-200-0400 www.samsung.ru UKRAINE 8-800-502-0000 www.samsung.com/ur [CHINA] Customer Care Center Web Site CHINA 800-810-5858 / (010) 64751880 www.samsung.com.cn Rev.1.5...

This manual is also suitable for:

R59 plusR61 plusR60R60 plusP500 r61P500 ... Show all

Table of Contents
