Chapter 1

1.3.5 Routing Busses To Outputs ...............................................

The Master, Sub Group and Auxiliary busses may be routed to output sockets as part of the initial configuration.
This is achieved by using the buss output routing panel in the Master Screen:
1) Touch the Buss Outputs button at the top of the master screen.
2) Touch the on screen meter of the relevant buss to expand the view.
3) Touch the Route button at the bottom of the panel.
4) Touch the name of the Socket Group that contains the output you require eg. Loc op 1-8.
5) Touch the Output Socket button(s) that you require eg. Loc op 1, Loc op 2 etc
6) Touch the Route button at the bottom of the panel to close the routing.
7) Touch the area around the on screen meter to return to the standard view.
8) Press the Master Fader Bank button for the relevant row of outputs to adjust the output level with the worksurface master faders.
NOTE: For a stereo buss, select the output for the left hand signal and the next consecutive output is used automatically for the right hand
signal.
1
2
5
4
7
6
3
1-12
