STEP 3: Alarm Notification Setup
Notification Setup
At least one email address or one phone number must be provided to receive notification messages.
IP Address: 10.4.150.148
MAC Address: A1:B5:C3:D2:E7:C2
Battery Status: None (Hit F5 to refresh)
Network Name (SSID)
WPA2 Security Key
No Security
Device Name
Email Address 1
Email Address 2
Example: 123-456-7890
Text Message Phone Number 1
Example: 123-456-7890
Text Message Phone Number 2
Submit Submit
c. Device Name: Enter a unique device name for each CS1200 WiFi Alarm being installed.
EXAMPLE: "Cabin Sump Alarm". Maximum 30 characters including spaces.
d. Email Address(es): Fill in the email address(es) which will be receiving notifications from the
CS1200 WiFi Alarm.
e. Enter the phone number of the device (or devices) that will receive the text messages.
Note: A minimum of one email address or text message phone number must be entered to
receive alarm notifications.
2. Click Submit button to save your notification data.
3. If connecting to a wireless network that does not support WPS connection, enter the router's
Network Name (SSID) and WPA2 Security Key, then disconnect the ethernet cable. Remove the
backup battery and disconnect the power cord from the power receptacle. Once the green power
light is no longer illuminated, plug the power cord back into the power receptacle.
WiFi
120 VAC
Replace battery yearly
1. On the CS1200 WiFi Alarm setup
page, fill in the appropriate data:
Note: Steps a. and b. are only required
if connecting to a wireless network that
does not support WPS connection.
a. Network Name (SSID): Enter the
b. WPA2 Security Key: Enter the
The blue network status light will illuminate steadily when
the CS1200 WiFi Alarm is successfully connected to the
wireless network.
4
wireless router's network name,
also called SSID, as it appears on the
WiFi connection for your Smart Phone,
Tablet, Laptop, or Desktop Device.
wireless router's security key
(password).
Or
Check the "No Security" box if the
wireless network does not require a
password.
