Before You Begin
Mount and wire your alarm according to installation instructions.
NOTE:
•
Cellular WiFi hotspots are not recommended for use with
this WiFi alarm, as intermittent or unreliable notification
service can result.
•
WPA2 Security must be enabled on the wireless router for
WiFi connections.
This setup manual covers setup using a WPS connection to your
wireless network, a wired ethernet connection and setup on a
wireless network that does not have the WPS function. Refer to the appropriate section for the type of
setup required.
Requirements:
WiFi Setup using WPS (WiFi Protected Setup)
•
CS1200 WiFi Alarm
•
Wireless Router With WPS Functionality
Note: WPA2 Security must be enabled on the wireless router
•
Smart Phone, Tablet, Laptop, or Desktop Device
WiFi Setup Without WPS (WiFi Protected Setup) Functionality
•
CS1200 WiFi Alarm
•
Wireless Router With An Unused LAN Port
Note: Wireless Router SSID and Security Key Required to Complete WiFi Setup
Note: WPA2 Security must be enabled on the wireless router
•
Ethernet Cable (must reach from router to alarm)
•
Ethernet Cable (must reach from router to alarm)
•
Smart Phone, Tablet, Laptop, or Desktop Device
Wired Ethernet Setup
•
CS1200 WiFi Alarm
•
Internet Modem, Router, or Ethernet Switch With An Unused LAN Port
•
Ethernet Cable (must reach from router to alarm)
•
Smart Phone, Tablet, Laptop, or Desktop Device
CS1200 WiFi Alarm
Setup Manual
1
CS1200
WiFi
INDOOR ALARM SYSTEM
120 VAC
Replace battery yearly
Advertisement
Table of Contents
Related Manuals for CSI Controls CS1200
Summary of Contents for CSI Controls CS1200
- Page 1 CS1200 WiFi Alarm Setup Manual Before You Begin Mount and wire your alarm according to installation instructions. CS1200 NOTE: WiFi • Cellular WiFi hotspots are not recommended for use with this WiFi alarm, as intermittent or unreliable notification INDOOR ALARM SYSTEM 120 VAC Replace battery yearly service can result.
- Page 2 WiFi router (often on the back side of router). INDOOR ALARM SYSTEM 120 VAC Replace battery yearly 3. Press the WPS button on the CS1200 WiFi Alarm (the blue network status light will flash continuously). CS1200 The blue network status light will illuminate steadily when the CS1200 WiFi Alarm is successfully connected to the wireless network.
- Page 3 QR Code. 4. Follow the registration link. 5. After reading and accepting the terms of the CS1200 WiFi Alarm, enter your alarm’s Unit ID# located on the back of the battery compartment cover. (DO NOT ENTER THE COLONS).
- Page 4 Once the green power light is no longer illuminated, plug the power cord back into the power receptacle. S1200 The blue network status light will illuminate steadily when the CS1200 WiFi Alarm is successfully connected to the wireless network. WiFi INDOOR ALARM SYSTEM...
- Page 5 STEP 4: Setup Testing 1. Press and release the “TEST” button on the CS1200 WiFi Alarm. The alarm horn will sound and the alarm light will activate while the “TEST” button is being held. 2. Verify that an alarm notification is received via all entered email or text numbers. Note: It may take several minutes for the message to appear in your email inbox or message folder, depending upon email server traffic or other circumstances. If you have not received a notification...
- Page 6 • Internet access is not functioning. Repair the internet connection. • Notification email has been blocked. Unblock or allow emails from mywifialarm@mywifialarm.com in your email account. • The CS1200 WiFi Alarm terms and conditions have not been accepted and/or a verification email has not been sent. Follow steps in the “Verification” section. Congratulations! Your CS1200 WiFi Alarm is now configured and ready to be used. (Remember to test your alarm on a regular basis to ensure proper operation)
