Daikin VRV III Technical Data Manual page 22

4 Capacity tables
4 - 2 Heating Capacity Tables
REYAQ14P
Combination Capacity index
(%) (kW)
90% 315
(36.00)
80% 280
(32.00)
70% 245
(28.00)
60% 210
(24.00)
50% 175
(20.00)
20
• Outdoor Unit • VRV
Outdoor
16.0
air temp.
TC PI
°CDB °CWB kW kW
-19.8 -20.0 26.5 9.21
-18.8 -19.0 27.0 9.34
-16.7 -17.0 28.0 9.60
-13.7 -15.0 29.2 9.87
-11.8 -13.0 30.5 10.1
-9.8 -11.0 31.9 10.4
-9.5 -10.0 32.7 10.5
-8.5 -9.1 33.4 10.7
-7.0 -7.6 34.6 10.9
-5.0 -5.6 36.3 11.1
-3.0 -3.7 38.1 11.3
0.0 -0.7 41.1 11.7
3.0 2.2 44.3 12.0
5.0 4.1 45.7 11.9
7.0 6.0 45.7 11.2
9.0 7.9 45.7 10.6
11.0 9.8 45.7 9.97
13.0 11.8 45.7 9.39
15.0 13.7 45.7 8.89
-19.8 -20.0 26.3 9.95
-18.8 -19.0 26.8 10.1
-16.7 -17.0 27.9 10.3
-13.7 -15.0 29.1 10.5
-11.8 -13.0 30.4 10.8
-9.8 -11.0 31.8 11.0
-9.5 -10.0 32.5 11.1
-8.5 -9.1 33.2 11.2
-7.0 -7.6 34.5 11.4
-5.0 -5.6 36.2 11.6
-3.0 -3.7 38.0 11.9
0.0 -0.7 40.6 12.0
3.0 2.2 40.6 11.0
5.0 4.1 40.6 10.3
7.0 6.0 40.6 9.75
9.0 7.9 40.6 9.21
11.0 9.8 40.6 8.70
13.0 11.8 40.6 8.21
15.0 13.7 40.6 7.78
-19.8 -20.0 26.2 10.7
-18.8 -19.0 26.7 10.8
-16.7 -17.0 27.7 11.0
-13.7 -15.0 28.9 11.2
-11.8 -13.0 30.2 11.4
-9.8 -11.0 31.6 11.6
-9.5 -10.0 32.4 11.7
-8.5 -9.1 33.1 11.8
-7.0 -7.6 34.3 12.0
-5.0 -5.6 35.5 11.9
-3.0 -3.7 35.5 11.2
0.0 -0.7 35.5 10.2
3.0 2.2 35.5 9.37
5.0 4.1 35.5 8.85
7.0 6.0 35.5 8.37
9.0 7.9 35.5 7.92
11.0 9.8 35.5 7.50
13.0 11.8 35.5 7.09
15.0 13.7 35.5 6.73
-19.8 -20.0 26.1 11.4
-18.8 -19.0 26.5 11.5
-16.7 -17.0 27.6 11.7
-13.7 -15.0 28.8 11.9
-11.8 -13.0 30.1 12.1
-9.8 -11.0 30.5 11.6
-9.5 -10.0 30.5 11.3
-8.5 -9.1 30.5 11.0
-7.0 -7.6 30.5 10.5
-5.0 -5.6 30.5 9.91
-3.0 -3.7 30.5 9.37
0.0 -0.7 30.5 8.57
3.0 2.2 30.5 7.87
5.0 4.1 30.5 7.45
7.0 6.0 30.5 7.06
9.0 7.9 30.5 6.69
11.0 9.8 30.5 6.35
13.0 11.8 30.5 6.02
15.0 13.7 30.5 5.73
-19.8 -20.0 25.4 11.8
-18.8 -19.0 25.4 11.5
-16.7 -17.0 25.4 11.0
-13.7 -15.0 25.4 10.4
-11.8 -13.0 25.4 9.90
-9.8 -11.0 25.4 9.37
-9.5 -10.0 25.4 9.12
-8.5 -9.1 25.4 8.89
-7.0 -7.6 25.4 8.52
-5.0 -5.6 25.4 8.05
-3.0 -3.7 25.4 7.63
0.0 -0.7 25.4 7.00
3.0 2.2 25.4 6.46
5.0 4.1 25.4 6.13
7.0 6.0 25.4 5.82
9.0 7.9 25.4 5.54
11.0 9.8 25.4 5.27
13.0 11.8 25.4 5.01
15.0 13.7 25.4 4.78
®
• VRV Systems • Outdoor Unit
®
III heat recovery, with connection to heating only hydrobox • REYAQ-P
TC: Total Capacity: kW ; PI: Power Input: kW (compressor + outdoor fan motor)
Indoor air temperature: °CDB
18.0 20.0
TC PI TC PI
kW kW kW kW
26.4 9.59 26.3 9.97
26.9 9.71 26.8 10.1
28.0 9.96 27.9 10.3
29.1 10.2 29.1 10.6
30.4 10.5 30.4 10.8
31.8 10.7 31.8 11.0
32.6 10.8 32.5 11.2
33.3 11.0 33.2 11.3
34.5 11.1 34.5 11.4
36.3 11.4 36.2 11.7
38.0 11.6 38.0 11.9
41.0 11.9 40.5 12.0
43.1 11.8 40.5 10.9
43.1 11.1 40.5 10.3
43.1 10.5 40.5 9.71
43.1 9.86 40.5 9.17
43.1 9.31 40.5 8.67
43.1 8.78 40.5 8.19
43.1 8.31 40.5 7.76
26.3 10.3 26.2 10.6
26.8 10.4 26.7 10.7
27.8 10.6 27.8 10.9
29.0 10.8 28.9 11.2
30.3 11.1 30.2 11.4
31.7 11.3 31.7 11.6
32.5 11.4 32.4 11.7
33.2 11.5 33.1 11.8
34.4 11.7 34.3 11.9
36.1 11.9 36.0 12.1
37.9 12.1 36.0 11.4
38.3 11.2 36.0 10.4
38.3 10.2 36.0 9.51
38.3 9.65 36.0 8.98
38.3 9.11 36.0 8.49
38.3 8.61 36.0 8.03
38.3 8.15 36.0 7.60
38.3 7.70 36.0 7.19
38.3 7.30 36.0 6.82
26.1 11.0 26.1 11.3
26.6 11.1 26.6 11.4
27.7 11.3 27.6 11.6
28.9 11.5 28.8 11.7
30.2 11.7 30.1 11.9
31.6 11.9 31.5 12.1
32.3 12.0 31.5 11.8
33.0 12.1 31.5 11.4
33.5 11.8 31.5 10.9
33.5 11.1 31.5 10.3
33.5 10.5 31.5 9.74
33.5 9.56 31.5 8.90
33.5 8.76 31.5 8.17
33.5 8.28 31.5 7.73
33.5 7.84 31.5 7.32
33.5 7.42 31.5 6.94
33.5 7.04 31.5 6.58
33.5 6.66 31.5 6.23
33.5 6.33 31.5 5.93
26.0 11.7 26.0 12.0
26.5 11.8 26.5 12.0
27.6 11.9 27.0 11.8
28.7 12.1 27.0 11.2
28.7 11.5 27.0 10.6
28.7 10.8 27.0 10.1
28.7 10.5 27.0 9.79
28.7 10.3 27.0 9.54
28.7 9.82 27.0 9.14
28.7 9.26 27.0 8.63
28.7 8.76 27.0 8.16
28.7 8.02 27.0 7.49
28.7 7.38 27.0 6.90
28.7 6.99 27.0 6.54
28.7 6.63 27.0 6.21
28.7 6.29 27.0 5.90
28.7 5.98 27.0 5.61
28.7 5.67 27.0 5.32
28.7 5.40 27.0 5.07
23.9 11.0 22.5 10.2
23.9 10.7 22.5 9.99
23.9 10.2 22.5 9.53
23.9 9.75 22.5 9.07
23.9 9.25 22.5 8.61
23.9 8.76 22.5 8.17
23.9 8.53 22.5 7.95
23.9 8.32 22.5 7.76
23.9 7.98 22.5 7.45
23.9 7.54 22.5 7.05
23.9 7.15 22.5 6.69
23.9 6.58 22.5 6.16
23.9 6.07 22.5 5.70
23.9 5.77 22.5 5.42
23.9 5.49 22.5 5.15
23.9 5.22 22.5 4.91
23.9 4.97 22.5 4.68
23.9 4.73 22.5 4.46
23.9 4.52 22.5 4.26
21.0 22.0
TC PI TC PI
kW kW kW kW
26.3 10.2 26.3 10.4
26.8 10.3 26.8 10.5
27.8 10.5 27.8 10.7
29.0 10.7 29.0 10.9
30.3 11.0 30.3 11.1
31.7 11.2 31.7 11.4
32.5 11.3 32.5 11.5
33.2 11.4 33.2 11.6
34.4 11.6 34.4 11.7
36.2 11.8 36.1 11.9
37.9 12.0 37.9 12.1
39.2 11.5 37.9 11.0
39.2 10.5 37.9 10.1
39.2 9.91 37.9 9.53
39.2 9.35 37.9 9.00
39.2 8.84 37.9 8.51
39.2 8.36 37.9 8.05
39.2 7.89 37.9 7.60
39.2 7.48 37.9 7.21
26.2 10.8 26.2 11.0
26.7 10.9 26.6 11.1
27.7 11.1 27.7 11.3
28.9 11.3 28.9 11.5
30.2 11.5 30.2 11.7
31.6 11.7 31.6 11.9
32.4 11.8 32.3 12.0
33.1 11.9 33.0 12.0
34.3 12.1 33.7 11.9
34.8 11.6 33.7 11.2
34.8 11.0 33.7 10.5
34.8 10.0 33.7 9.61
34.8 9.16 33.7 8.81
34.8 8.65 33.7 8.33
34.8 8.18 33.7 7.88
34.8 7.74 33.7 7.46
34.8 7.34 33.7 7.07
34.8 6.94 33.7 6.69
34.8 6.59 33.7 6.36
26.1 11.4 26.0 11.6
26.5 11.5 26.5 11.7
27.6 11.7 27.6 11.8
28.8 11.9 28.8 12.0
30.1 12.1 29.5 11.8
30.5 11.6 29.5 11.2
30.5 11.3 29.5 10.9
30.5 11.0 29.5 10.6
30.5 10.5 29.5 10.1
30.5 9.92 29.5 9.54
30.5 9.37 29.5 9.02
30.5 8.57 29.5 8.25
30.5 7.88 29.5 7.59
30.5 7.45 29.5 7.19
30.5 7.06 29.5 6.81
30.5 6.70 29.5 6.46
30.5 6.36 29.5 6.14
30.5 6.03 29.5 5.82
30.5 5.73 29.5 5.54
25.9 12.1 25.3 11.7
26.1 11.9 25.3 11.5
26.1 11.4 25.3 10.9
26.1 10.8 25.3 10.4
26.1 10.2 25.3 9.84
26.1 9.69 25.3 9.32
26.1 9.42 25.3 9.06
26.1 9.19 25.3 8.84
26.1 8.80 25.3 8.47
26.1 8.31 25.3 8.01
26.1 7.87 25.3 7.58
26.1 7.23 25.3 6.97
26.1 6.66 25.3 6.43
26.1 6.32 25.3 6.10
26.1 6.00 25.3 5.79
26.1 5.70 25.3 5.51
26.1 5.42 25.3 5.24
26.1 5.15 25.3 4.98
26.1 4.91 25.3 4.75
21.8 9.83 21.1 9.45
21.8 9.61 21.1 9.24
21.8 9.18 21.1 8.83
21.8 8.74 21.1 8.41
21.8 8.30 21.1 7.99
21.8 7.88 21.1 7.59
21.8 7.67 21.1 7.39
21.8 7.49 21.1 7.21
21.8 7.19 21.1 6.93
21.8 6.81 21.1 6.56
21.8 6.46 21.1 6.24
21.8 5.96 21.1 5.75
21.8 5.51 21.1 5.33
21.8 5.24 21.1 5.07
21.8 4.99 21.1 4.83
21.8 4.76 21.1 4.60
21.8 4.54 21.1 4.39
21.8 4.32 21.1 4.19
21.8 4.13 21.1 4.00
24.0
TC PI
kW kW
26.2 10.7
26.7 10.8
27.7 11.0
28.9 11.2
30.2 11.5
31.6 11.7
32.4 11.8
33.1 11.9
34.3 12.0
35.3 11.8
35.3 11.1
35.3 10.2
35.3 9.29
35.3 8.78
35.3 8.30
35.3 7.85
35.3 7.44
35.3 7.04
35.3 6.68
26.1 11.3
26.6 11.4
27.6 11.6
28.8 11.8
30.1 12.0
31.4 12.0
31.4 11.7
31.4 11.4
31.4 10.9
31.4 10.3
31.4 9.69
31.4 8.86
31.4 8.13
31.4 7.69
31.4 7.29
31.4 6.91
31.4 6.55
31.4 6.21
31.4 5.90
26.0 11.9
26.5 12.0
27.5 12.1
27.5 11.5
27.5 10.9
27.5 10.3
27.5 9.98
27.5 9.73
27.5 9.32
27.5 8.79
27.5 8.32
27.5 7.63
27.5 7.02
27.5 6.66
27.5 6.32
27.5 6.00
27.5 5.70
27.5 5.41
27.5 5.16
23.5 10.8
23.5 10.5
23.5 10.0
23.5 9.55
23.5 9.07
23.5 8.59
23.5 8.36
23.5 8.16
23.5 7.82
23.5 7.40
23.5 7.02
23.5 6.46
23.5 5.96
23.5 5.67
23.5 5.39
23.5 5.13
23.5 4.89
23.5 4.65
23.5 4.44
19.6 8.71
19.6 8.52
19.6 8.15
19.6 7.77
19.6 7.39
19.6 7.02
19.6 6.84
19.6 6.68
19.6 6.42
19.6 6.09
19.6 5.79
19.6 5.35
19.6 4.96
19.6 4.73
19.6 4.51
19.6 4.30
19.6 4.11
19.6 3.92
19.6 3.75
