- Page 1 USER MANUAL Elo Touch Solutions 1915L Touchmonitors SW600066 Rev G ...
- Page 2 Elo Touch Solutions, Inc. Disclaimer The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Afffiliates (collectively "Elo") makes no representations or warranties with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
-
Page 3: Table Of Contents
Chapter 3: Operation ................15 Chapter 3: Technical Support ..............26 Chapter 4: Safety & Maintenance ............28 Chapter 5: Regulatory Information ............30 Chapter 6: Warranty Information ............34 User Manual: 1915L SW600066 Rev G, Page 3 of 35 ... -
Page 4: Chapter 1: Introduction
This manual contains information that is important for the proper setup and maintenance of the unit. Before setting up and powering on your new touchmonitor, read through this manual, especially the Installation and Operation chapters. User Manual: 1915L SW600066 Rev G, Page 4 of 35 ... -
Page 5: About The Product
Power management system conforms to VESA DPMS standard. • Supports DDC2B for Plug & Play compatibility. • Advanced OSD control for picture quality adjustment. • Detachable stand for wall-mounting application. • Integrated touch screen function. User Manual: 1915L SW600066 Rev G, Page 5 of 35 ... -
Page 6: Chapter 2: Installation
Serial cable (excluded in APR and Intellitouch Plus models) Power cable o Japanese power cable and adapter/terminal, o China, Taiwan, and/or Korean power cable, or US and/or European power cable User Manual: 1915L SW600066 Rev G, Page 6 of 35 ... -
Page 7: Touch Interface Connection
3. Connect one end of the video cable to the rear side of computer and the other to the LCD monitor. Tighten by turning the two thumb screws clockwise to ensure proper grounding. 4. Press the power button on the front panel to turn the monitor power on. User Manual: 1915L SW600066 Rev G, Page 7 of 35 ... -
Page 8: Product Overview
Product Overview Main Unit Rear View User Manual: 1915L SW600066 Rev G, Page 8 of 35 ... - Page 9 Some software installation is required for your iTouch Plus touchmonitor to work with your computer. No additional drivers are required for your projected-capacitive touchmonitor, it uses Windows HID drivers. The drivers for the Windows 7 and XP systems are available on the Elo Touch Solutions website. Visit www.elotouch.com for: ...
- Page 10 Select the applicable driver from the Elo Touch Solutions website and download: For Windows 7 installations, double-click on EloSetup Installer User Manual: 1915L SW600066 Rev G, Page 10 of 35 ...
- Page 11 To complete setup, reboot system by clicking on “Reboot Now” button. Click on “One More Minute” if more time is needed with increments of 1 minute. Note: System will automatically reboot when “Time left” counter reaches “0”. User Manual: 1915L SW600066 Rev G, Page 11 of 35 ...
- Page 12 For Windows XP installations, double-click on the icon from the desktop Click on “Unzip” button to unzip files. User Manual: 1915L SW600066 Rev G, Page 12 of 35 ...
- Page 13 Select one or more of the drivers to install. Click on “Next” User Manual: 1915L SW600066 Rev G, Page 13 of 35 ...
- Page 14 After accepting the end-user license agreement, the drivers will finish installing. Reboot your computer after the installation is complete. User Manual: 1915L SW600066 Rev G, Page 14 of 35 ...
-
Page 15: Chapter 3: Operation
If there is a power failure, your touchmonitor settings will not default to the factory specifications. User Manual: 1915L SW600066 Rev G, Page 15 of 35 ... - Page 16 Increase value of selected parameter / Display OSD Contrast submenu select next menu item Select parameter for adjustment / Select Auto Adjust select submenu to enter User Manual: 1915L SW600066 Rev G, Page 16 of 35 ...
- Page 17 Temperature temperature by changing individual R, G, and B gains on a scale from 0 to 100. Default: User Defined with R, G, and B all set to 100 User Manual: 1915L SW600066 Rev G, Page 17 of 35 ...
- Page 18 Press and hold the “Menu” and “Down” buttons for two seconds to enable/disable the Power Locking feature. When the Power Locking is enabled, pressing the power switch will have no effect on the system. User Manual: 1915L SW600066 Rev G, Page 18 of 35 ...
-
Page 19: Preset Modes
The monitor is equipped with the power management function which automatically reduces the power consumption when not in use. Mode Power Consumption < 50 Watts Sleep < 3 Watts User Manual: 1915L SW600066 Rev G, Page 19 of 35 ... -
Page 20: Display Angle
For viewing clarity, you can tilt the LCD forward (up to -5 degrees) or backward (up to 90 degrees.) CAUTION: In order to protect the LCD, be sure to hold the base when adjusting the LCD, and take care not to touch the screen. User Manual: 1915L SW600066 Rev G, Page 20 of 35 ... -
Page 21: Intellitouch Plus Touch Technology
To use multiple IntelliTouch Plus monitors, plug in monitors to calibrate, double-click on the EloConfig desktop shortcut to run Elo Touchscreen Configuration screen. Click on “Calibrate Touch Screens…” to calibrate multiple monitors. User Manual: 1915L SW600066 Rev G, Page 21 of 35 ... - Page 22 User Manual: 1915L SW600066 Rev G, Page 22 of 35 ...
- Page 23 Tap monitor screen to identify monitor’s identity as shown below. Identity of the monitor will display. Click on “OK” to proceed to calibration. User Manual: 1915L SW600066 Rev G, Page 23 of 35 ...
- Page 24 Calibrate touch as targets appear on corners of the screen. Follow instructions on screen. Test touch/drag performance to verify calibration accuracy, “Accept” or “Retry” to redo calibration process. Run touch calibration on each monitor that is plugged in. User Manual: 1915L SW600066 Rev G, Page 24 of 35 ...
-
Page 25: Gesture Support
The IntelliTouch Plus and Projected Capacitive touch technologies enable several gestures that support single and multiple contacts. Refer to the Microsoft Website http://msdn.microsoft.com/en-us/library/dd940543 on the various gestures that are supported in Windows 7. User Manual: 1915L SW600066 Rev G, Page 25 of 35 ... -
Page 26: Chapter 3: Technical Support
Perform the calibration routine provided with the latest Elo drivers The OSD buttons or power button does not Check to see if the OSD lock or power lock respond when pressed functions are on User Manual: 1915L SW600066 Rev G, Page 26 of 35 ... -
Page 27: Technical Assistance
Visit www.elotouch.com/products for technical specifications for this device Visit www.elotouch.com/go/websupport for online self-help. Visit www.elotouch.com/go/contactsupport for technical support. See this user manual’s last page for worldwide technical support phone numbers. User Manual: 1915L SW600066 Rev G, Page 27 of 35 ... -
Page 28: Chapter 4: Safety & Maintenance
To clean the touchscreen, use window or glass cleaner applied to a clean cloth or sponge. Never apply the cleaner directly to the touchscreen. Do not use alcohol (methyl, ethyl or isopropyl), thinner, benzene, or other abrasive cleaners. User Manual: 1915L SW600066 Rev G, Page 28 of 35 ... - Page 29 Elo has put in place recycling arrangements in certain parts of the world. For information on how you can access these arrangements, please visit http://www.elotouch.com/AboutElo/ewaste-program/. User Manual: 1915L SW600066 Rev G, Page 29 of 35 ...
-
Page 30: Chapter 5: Regulatory Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may User Manual: 1915L SW600066 Rev G, Page 30 of 35 ... - Page 31 2) If this equipment appears to cause interference with radio or television reception, or any other device: User Manual: 1915L SW600066 Rev G, Page 31 of 35 ...
- Page 32 In accordance to Chinese law (Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products), the section below lists out the name and amount of the toxic and/or hazardous materials that this product may contain. User Manual: 1915L SW600066 Rev G, Page 32 of 35 ...
- Page 33 液晶显示面板 X O O O O O 触摸屏面板 X O O O O O PCBA X O O O O O 本表格依据SJ/T 11364的规定编制。 O：表示该有害物质在该部件所有均质材料中的含量均在GB/T 26572规定的限量要求以下。 X：表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572规定的限量要求。 上表中打“X”的部件中，应功能需要，部分有害物质含量超出GB/T 26572规定的限量要求，但是符合欧盟RoHS法规要求(属于豁免部分)。 User Manual: 1915L SW600066 Rev G, Page 33 of 35 ...
-
Page 34: Chapter 6: Warranty Information
Chapter 6: Warranty Information http://www.elotouch.com/Support/warranty.asp for more information User Manual: 1915L SW600066 Rev G, Page 34 of 35 ... - Page 35 Press releases Software drivers Getting in Touch with us To find out more about the extensive range of Elo touch solutions, visit our website at www.elotouch.com, or simply call the office nearest you: North America Tel 800-ELO-TOUCH Europe...
