- Page 1 TD-E552 TD-E652 Owner’s Record The model number and serial number are on the back of your TV. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV. 08/15 Model...
-
Page 2: Important Safety Instructions
Dear Customer, 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in Thank you for purchasing this Toshiba LCD Display accordance with the manufacturer’s instructions. monitor. This manual will help you use the many exciting features of your new LCD Display monitor. -
Page 3: Installation, Care, And Service
14) CAUTION: 23) WARNING: NEVER expose batteries to excessive heat such as sunshine, fire or • To reduce the risk of electric shock, do not use the the like. polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted 24) ALWAYS plug the product into an outlet that is completely to prevent blade exposure. - Page 4 If these sounds become frequent or continuous, unplug the 35) For optimum performance, allow 20 minutes for power cord and contact a Toshiba Authorized Service warm-up. Provider. 36) Rest your eyes periodically by focusing on an object 49) Handle with care when transporting.
- Page 5 (Registration, Evaluation, Authorization and Restriction of Chemicals), entered into force on 1 June 2007, with phased deadlines up to 2018. Toshiba will meet all REACH requirements and is committed to provide our customers with information about the presence in our...
- Page 6 Note: ENERGY STAR certification does not apply reproduced in any form without the prior written to TD-E652. permission of Toshiba. No patent liability is assumed, however, with respect to the use of the information contained herein.© 2015 by Toshiba Lifestyle Products Important notes about your monitor &...
-
Page 7: Table Of Contents
Contents Important Safety Instructions ..................2 Installation, Care, and Service ..................3 Chapter 1: Introduction ....................9 Safety Icons..............................9 Features of your new LCD Display ........................ 10 Package Contents ............................11 Parts Name and Functions..........................12 Connectors and Terminals..........................14 Infrared Remote Control .......................... - Page 8 Contents How to set up a schedule..........................45 Viewing media from USB storage ......................... 47 Setting up a playlist..........................49 Playing background music ........................51 Slideshow settings ..........................51 Playing a playlist ............................ 52 Remote control............................. 55 LAN remote control ..........................58 Configuration and basic operation of the OSD screen ..................
-
Page 9: Chapter 1 Introduction
Chapter 1 Introduction Safety Icons This manual contains safety instructions that must be observed to avoid potential hazards that could result in personal injuries, damage to your equipment, or loss of data. These safety cautions have been classified according to the seriousness of the risk, and icons highlight these instructions as follows: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 10: Features Of Your New Lcd Display
High-quality LCD panel providing a wide variety of content and messages clearly Full HD panel — The TD-E432 , TD-E502 , TD-E552 and TD-E652 panels reproduce images from video and computer signals with precision and clarity, delivering full 1920 x 1080 high- definition resolution. -
Page 11: Package Contents
Chapter 1 Introduction Package Contents Contents Item Unit Remark LCD display Wireless remote control Batteries AAA size AC power cable 1.8m 3.5mm jack Composite/component conversion cable Logo cover sheet User manual Warranty Sheet Except for EU models QSG (Quick Setup Guide) For EU models only Cable Clamps The supplied power cord varies depending on destination. -
Page 12: Parts Name And Functions
POWER button—Switches the power on/off. This button does not work when the power indicator is off. In such cases, turn on the main power switch. (See page 13). Logo Cover Sheet: If the user wants to hide the TOSHIBA logo while using the LCD Display N O T E monitor in portrait mode, use the Logo cover sheet provided in the package contents and place it on top of the logo (see page 11). - Page 13 Chapter 1 Introduction Back Underside Handle screw holes —Used to mount handles (optional), for carrying the LCD display. Main Power Switch —Switches the main power on/off and is used as the disconnect device. Cable clamp holes — Used to clamp cables to the system. Within 2 seconds after turning off the power by the POWER button on the infrared remote con- N O T E trol or the display or by a communication command, don’t turn off the main power switch,...
-
Page 14: Connectors And Terminals
RS-232C OUT—Connects with the RS-232C IN connector of other connected TD-E432/TD-E502/TD-E552/TD- E652. RS-232C IN—Connects with the RS-232C OUT connector of a computer or other connected TD-E432/TD-E502/ TD-E552/TD-E652. DVI-D OUT—Outputs the signal that is supplied to the DVI-D IN connector (7). - Page 15 Chapter 1 Introduction LINE OUT— Outputs the signal that is supplied to the LINE IN connector (13). Connects with an external audio amplifier, etc. Headphones and earphones are not supported. LINE IN—Connects with the audio visual output connector of external equipment such as a computer, VCR, and DVD player VGA IN—Connects with the analog video output of a computer.
-
Page 16: Infrared Remote Control
Chapter 1 Introduction Infrared Remote Control POWER button—Switches the power on/off. When the Power indicator is not glowing red, no controls will work. 11 11 NUMBER buttons—Used to input numbers when inputting remote ID setting and programming schedules. SET ID button—Set Remote Control ID. Use in IR Daisy Chain Mode. -
Page 17: How To Use The Infrared Remote Control
Chapter 1 Introduction How to Use the Infrared Remote Control Setting Up the Infrared Remote Control Sensor Before using the infrared remote control, the LCD display’s remote control sensor must be positioned. The remote control sensor is a small black box located on the back of left of the LCD display. - Page 18 Chapter 1 Introduction Handling the infrared remote control • Do not subject to a strong shock. • Do not allow water or other liquid to splash on the infrared remote control. If the infrared remote control gets wet, wipe it dry immediately. •...
- Page 19 Chapter 1 Introduction How to remove the batteries Unlock and pull up the cover. Remove the batteries. Incorrect use of batteries can result in leaks or explosion. Be especially careful of the follow- ing points. • Place “AAA” batteries matching the (+) and (-). •...
-
Page 20: Chapter 2 Preparation For Use
Chapter 2 Preparation for use Preparation for installation Determine the installation location DO NOT ATTEMPT TO INSTALL THE LCD DISPLAY BY YOURSELF. C A U T I O N Installing your LCD display must be done by a qualified technician. Contact your dealer for more information. - Page 21 Chapter 2 Preparation for use Don’t block the ventilation vents (1) Screw holes for handles 100 mm 100 mm 100 mm 100 mm...
-
Page 22: Using The Wall Mount Or Ceiling Mount Or Handles
Secure handles (optional parts), using M6 screws with a length less than the thickness of the handle plus the allowable depth of the screw holes (5mm for the 43” display, 9mm for the 50”/55” displays, and 6mm for the 65” display). Toshiba recommends using a mounting interface that complies with VESA Requirements, TUV-GS or for North America UL1678. - Page 23 Chapter 2 Preparation for use 150.00 mm 150.00 mm 43” 200.00 mm 200.00 mm 50”/55”/65”...
- Page 24 Chapter 2 Preparation for use To prevent the display from falling: • Install the display with metal brackets for wall or ceiling installation (commercially avail- able) in your own responsibility. For detailed procedures of installation, refer to the instructions of the metal brackets. •...
-
Page 25: Installation In Portrait Or Landscape Orientation
Chapter 2 Preparation for use Installation in portrait or landscape orientation The display can be installed in portrait or landscape orientation. Ensure that the display is oriented as shown in the images in this section. • The operating environmental condition (temperature) when the display is in portrait orien- N O T E tation is 0°C to 40°C (32°... -
Page 26: Avoiding Image Retention
Chapter 2 Preparation for use Operation environment for portrait and face down (between 0° and 15°) installation 0~15° 0~15° Logo Logo The following operation environment details apply when the display is installed in portrait and face up orientations. • Temperature 0 - 40°C / 32 - 104°F •... -
Page 27: Connection Procedure
Chapter 2 Preparation for use Connection procedure Before making connections: • First turn off the power of all the connected equipment before making connections. • Refer to the user manual of each piece of equipment. Please use a low resistance audio cable when the audio output terminal of the audio device N O T E and PC is a stereo mini-jack. -
Page 28: Connecting With An Analog Video Source
Chapter 2 Preparation for use Connecting with an analog video source Analog connection: Connect a signal cable (VGA or YPbPr cable), to the VGA or AV IN connector. Select AV, Component, or VGA using the SOURCE button on the LCD display, or the SOURCE button on the infrared remote control. -
Page 29: Connecting With A Digital Video Source
Chapter 2 Preparation for use Connecting with a digital video source Digital connection: • Connection via the HDMI IN connector (1) Connect an HDMI cable (commercially available) to the HDMI1 IN or HDMI2 IN connector. (2) Select [HDMI1] or [HDMI2] according to the connected connector by pressing the SOURCE button on the LCD display or the HDMI1 or HDMI2 button on the infrared remote control. - Page 30 Chapter 2 Preparation for use In this image the dashed lines around ports indicate connections OUT, and the small screen N O T E at front indicates the second display.
-
Page 31: Connecting Lan
Chapter 2 Preparation for use Connecting LAN Display connection using LAN As shown in the illustration below, you can connect this display and a computer in network through a LAN hub. Connect the display and the LAN hub using a straight type LAN cable (commercially available). How to connect •... - Page 32 Chapter 2 Preparation for use...
-
Page 33: Chapter 3: How To Use The Lcd Display Monitor
Chapter 3 How to use the LCD Display Monitor Turning on all the connected devices Turn on all connected devices, such as a computer and DVD player. Set Up the Infrared Remote Control Sensor Before using the infrared remote control, the LCD display’s remote control sensor must be positioned. The remote control sensor is a small black box located on the back of left of the LCD display. - Page 34 Chapter 3 How to use the LCD Display Monitor Turn on the Main Power Switch. The power indicator turns on green and the display turns on. The control buttons on the back, infrared remote control, and schedule setting do not work while then main power switch is off (the power indicator is off). When using them, check that the Main Power Switch is on (the power indicator is on).
- Page 35 Chapter 3 How to use the LCD Display Monitor Turn on the LCD Display. Press the POWER button on the left side of the LCD display, or the POWER button on the top left of the infrared remote control. Within two seconds of turning off the power using the POWER button on the infrared remote N O T E control or the display or by a communication command, don’t turn off the main power switch, don’t disconnect the power cord, and don’t turn off the breaker.
-
Page 36: Power Management Function
Chapter 3 How to use the LCD Display Monitor Power Management Function To reduce power, the display supports three power off methods, for different purposes. • Sleep Timer • The user can set the timer to power off the display, regardless of the current source signal status. Sleep timer options are 5 mins, 15 mins, 30 mins, 60 mins, 90 mins, 120 mins, 180 mins, and off, in OSD menu. -
Page 37: Selecting The Video Input
Chapter 3 How to use the LCD Display Monitor Selecting the video input Select using the SOURCE button on the infrared remote control You can select the desired video input by pressing the SOURCE button on the infrared remote control, and using the UP (▲) and DOWN (▼) buttons to make your selection. Selectable video inputs are [AV], [COMPONENT], [HDMI1], [HDMI2], [DVI-D], [VGA], and [USB]. -
Page 38: Selecting The Osd Language
Chapter 3 How to use the LCD Display Monitor Selecting the OSD language Display the OSD menu by pressing the MENU button on the infrared remote control, or the MENU button on the left side of the LCD display. Using MENU LANGUAGE in the INITIAL SETTINGS menu of the OSD screen function, you can select the OSD language. -
Page 39: Initial Setting
Set the time format. Clock Set the clock time. Logo Display Toshiba logo display option (enable/disable). Remote Operation Remote control option (enable/disable). Note: If Remote operation is disabled, you can press “menu”, “left”, “right”, “up”, ”down” to enable the function. -
Page 40: Selecting The Picture Mode
Chapter 3 How to use the LCD Display Monitor Selecting the picture mode Using the PICTURE button on the infrared remote control, you can select the picture mode suitable for images to be displayed. Picture Mode Setting Details DYNAMIC Maximum brightness. CINEMA Suitable for viewing movies. -
Page 41: Picture Adjustment
Chapter 3 How to use the LCD Display Monitor Picture adjustment Display the OSD menu by pressing the MENU button on the infrared remote control, or the MENU button on the left side of the LCD display. Using the PICTURE menu of the OSD screen function, you can adjust picture settings such as brightness, contrast, and sharpness, to obtain the desired image quality. -
Page 42: Audio Settings
Chapter 3 How to use the LCD Display Monitor Audio settings Select the built-in speakers or the external stereo speakers in the speaker setting in the OSD menu. Display the OSD menu by pressing the MENU button on the infrared remote control, or the MENU button on the left side of the LCD display. -
Page 43: Treble, Bass, And Balance Adjustment
Chapter 3 How to use the LCD Display Monitor Treble, bass, and balance adjustment You can adjust the speaker treble, bass, and balance, using the SOUND menu on the OSD screen function. For adjustment, display the OSD menu by pressing the MENU button on the infrared remote control or the MENU button on the left side of the LCD display. -
Page 44: Schedule Setting
Chapter 3 How to use the LCD Display Monitor Schedule setting You can program power-on/off and input selection using the QUICK button on the infrared remote control, which enters the SCHEDULER settings in the OSD menu. Alternatively, display the OSD menu by pressing the MENU button on the infrared remote control or the MENU button on the left side of the LCD display. -
Page 45: How To Set Up A Schedule
Chapter 3 How to use the LCD Display Monitor How to set up a schedule Program number selection When the cursor is in any of the check boxes showing the program numbers 1 to 7 on the left side of the screen, press the UP (▲) and DOWN (▼) buttons to move the cursor up or down to select the program number you want to set. - Page 46 Chapter 3 How to use the LCD Display Monitor Schedule confirmation To confirm the schedule, select ENABLE SCHEDULE in the OSD, then press the MENU button on the infrared remote control or the MENU button on the left side of the LCD display to exit the SCHEDULE menu of the OSD screen function.
-
Page 47: Viewing Media From Usb Storage
Chapter 3 How to use the LCD Display Monitor Viewing media from USB storage Insert USB storage medium into the USB port. Use the SOURCE button on the infrared remote control or the LCD display to select USB as the input source. The OSD will display three options, PHOTO, MUSIC, and MOVIE. - Page 48 Chapter 3 How to use the LCD Display Monitor Use the audiovisual control buttons to navigate and open media files; fast reverse (), play (), fast forward (), track backwards (|), stop (3), pause (2), and track forward (|). When media files are being viewed in this way, the colored buttons on the infrared remote control will be active. Their functions are determined by context, and will be shown in the OSD at the bottom of the LCD display.
-
Page 49: Setting Up A Playlist
Chapter 3 How to use the LCD Display Monitor Setting up a playlist Enter one of the media type menus (PHOTO, MUSIC or MOVIE). The USB storage medium will display on the screen as drive C. Open this drive by pressing the OK button on the infrared remote control. - Page 50 Chapter 3 How to use the LCD Display Monitor Use the colored buttons to select options in the playlist menu. • [BLUE]: Save selected files to a playlist. • [RED]: Cancel and return to the previous menu. • [GREEN]: Load an existing playlist. •...
-
Page 51: Playing Background Music
Chapter 3 How to use the LCD Display Monitor Playing background music This is the background music icon. When viewing photos it is possible to play background music simultaneously, if the folder from which the photos are being played also contains music, and the music has been added to a playlist. -
Page 52: Playing A Playlist
Chapter 3 How to use the LCD Display Monitor Slideshow Time: Set the time to wait between presenting each image in the slideshow: • 3 seconds-20 seconds/1 second intervals Transition: Set the transition type when changing from one image in the slideshow to another. •... - Page 53 Chapter 3 How to use the LCD Display Monitor Playguide Functions Remote Key Function Stop playback Play/stop background music (only available in PICTURE mode, and is crossed out if this feature is unavailable) Repeat: play all files repeatedly in sequence Shuffle: play all files randomly Remote Key Functions With Playguide Remote Key...
- Page 54 Chapter 3 How to use the LCD Display Monitor Remote Key Functions With Playguide Remote Key Pictures Music Movies [GREEN] [INFO]: Show details of [INFO]: Show details of [INFO]: Show details of current file current file current file [YELLOW] [OPTION]: Slide show Not used Not used options...
-
Page 55: Remote Control
Chapter 3 How to use the LCD Display Monitor Remote control RS-232C Remote control In order to control displays remotely, the displays support two communication interfaces: RS-232C and LAN. Computers can communication to the display via the two connections. You can select communication interface in the OSD menu. -
Page 56: Communication Settings
Chapter 3 How to use the LCD Display Monitor Command protocol i. The communication protocol setting is as follows: Communication Settings Protocol RS-232C Baud rate 9600 [bps] Data length 8 [bit] Parity bit None Stop bit 1 [bit] Flow control None ii. - Page 57 Chapter 3 How to use the LCD Display Monitor Two basic commands are shown here as examples. Note that these commands are used when a single computer connects to a single display. Contact your dealer for advanced command specifications if you want to connect multiple displays, or perform complicated controls using other commands than the basic commands.
-
Page 58: Lan Remote Control
Chapter 3 How to use the LCD Display Monitor LAN remote control When you connect the display and the computer using a LAN hub and a LAN cable (see page 31), and then configure the network settings using ETHERNET SETTING in the SETUP menu of the OSD, you can control the LCD display remotely using the same commands as for RS-232C. -
Page 59: Configuration And Basic Operation Of The Osd Screen
Chapter 3 How to use the LCD Display Monitor Configuration and basic operation of the OSD screen This LCD display is equipped with an OSD (On Screen Display) function for easy adjustment of settings. The OSD function allows you to control the menus displayed on the screen, to adjust brightness, and other settings. This table lists the initial OSD functions in the main menu screen. -
Page 60: Basic Operation Of Osd Screen
Chapter 3 How to use the LCD Display Monitor Basic operation of OSD screen Check that the power indicator illuminates green and the LCD display is powered on. Wireless remote Step Monitor button Description control Press the MENU button to display the OSD screen and then press the UP (▲), and DOWN (▼), buttons to... - Page 61 Chapter 3 How to use the LCD Display Monitor Wireless remote Step Monitor button Description control Press the OK button to accept the selected sub menu. Press the SOURCE button to accept the selected sub menu. Press the LEFT (), and RIGHT (), buttons to select the setting and then press the OK button to accept it.
-
Page 62: Picture Menu Screen
Chapter 3 How to use the LCD Display Monitor Picture Menu Screen Picture Menu Screen Picture mode Select picture style, Dynamic, Cinema, Custom, or Standard. See pages 16 and 41. Adjust contrast, brightness, sharpness, tint, and color settings. Backlight Adjust backlight settings. Color Temperature Adjust color temperature and gain. -
Page 63: Aspect Ratio Menu Settings
Chapter 3 How to use the LCD Display Monitor Aspect Ratio Menu Settings Aspect Ratio Menu Settings Source ID OverScan Aspect Ratio HDMI1/2 DVI-D 16:9 YPrPr Dot by Dot Auto 16:9 Zoom Cinema Dot by Dot Auto 16:9 Zoom Cinema Media Movie 16:9 Dot by Dot... -
Page 64: Sound Menu Screen
Chapter 3 How to use the LCD Display Monitor Sound Menu Screen Sound Menu Screen Sound mode Select sound style; Standard, Dynamic, or Custom. Adjust Treble, Bass, and Balance settings. Surround Sound Turn surround sound on or off. Speaker Select internal or external speaker. Audio Only Select audio only, or audio/video. -
Page 65: Setup Menu Screen
Chapter 3 How to use the LCD Display Monitor Setup Menu Screen Setup Menu Screen Scheduler Change schedule settings. Signal Check Priority • Set signal priority 1-5 (priority 1 is the highest). If the current source signal is lost, the display will search for a new signal source according signal priority setting). -
Page 66: Initial Setting Menu Screen
Selects 12 hour or 24 hour time format. Clock Change time and date. Logo Display Select whether or not to display the Toshiba logo on power up. Remote Operation Enable or disable remote operation. Keyboard Operation Enable or disable keyboard operation. -
Page 67: Multi Display Control Menu Screen
Chapter 3 How to use the LCD Display Monitor Multi Display Control Menu Screen Multi Display Control Menu Screen Tiling Enable Multi Display. Up to 25 panels (5 wide x 5 high), can be com- bined to create a single large image (i.e., video wall), or other high- impact signage. - Page 68 Chapter 3 How to use the LCD Display Monitor Multi Display Control Menu Screen Power ON Delay For installations using multiple displays, the power-on delay function can power up the displays sequentially with a delay of 0-30 seconds after the power is applied. Using this function can prevent inrush current problems, and reduce the overall electrical load require- ments when a single power supply is used.
-
Page 69: System Information Menu Screen
Chapter 3 How to use the LCD Display Monitor System Information Menu Screen System Information Menu Screen Model Name Shows the display’s model name and number. SW Version Shows the display’s current software version. LAN Version Shows the display’s current LAN firmware version. IP Address Shows the display’s current IP address. -
Page 70: Specifications
Appendix A Specifications • These models comply with the specifications listed below. N O T E • Designs and specifications are subject to change without notice. • These models may not be compatible with features and/or specifications that may be added in the future. -
Page 71: Viewable Size (H X V)
Viewable Size (H x V) 43” 940.9 x 529.3mm 50” 1095.8 x 616.4mm 55” 1209.6 x 680.4mm 65” 1428.5 x 803.5mm Power Management VESA DPM Power source 43”/50”/55”/65” Input Voltage AC100-240V ±10% (50/60Hz) Power Consumption in Power Saving mode Power switch off (DC-OFF, standby): <0.5W Main power switch off: 0W Power consumption 43”... -
Page 72: Av Input/Output
Supported Resolutions Analog: 640 x 480, 720 x 400, 800 x 600, 1024 x 768, 1280 x 768, 1280 x 800,1280 x 960, 1280 x 1024, 1360 x 768, 1366 x 768, 1600 x 1200, 1920 x 1080 Digital: 640 x 800, 800 x 600, 1024 x 768, 1280 x 1024, 1280 x 768, 1360 x 768, 1680 x 1050, 1920 x 1080 AV Input/Output Input Connector... -
Page 73: Mass (Weight)
Mass (weight) 43” Net 10.5kg (23.1lb); Gross 14.5kg (31.9lb) 50” Net 14kg (30.8lb); Gross 20.5kg (45.1lb) 55” Net 17kg (37.4lb); Gross 23.5kg (51.8lb) 65” Net 24kg (52.9lb); Gross 33.5kg (73.8lb) Table 1: Media Support Specifications (Video) MPEG1 File Video Maximum Max Bit Container Frame... - Page 74 Table 1: Media Support Specifications (Video) MPEG1 File Video Maximum Max Bit Container Frame (L2& AC3 AAC WMA L-PCM Extension codec Resolution Rate Rate Motion “AVI, MOV” JPEG 640x480 30fps 10Mbit/ JPEG .asf H.264 1080P 30fps 20Mbit/ MPEG2 1080P 30fps 20Mbit/ MPEG4 1080P 30fps...
- Page 75 Table 3: Media Support Specifications (Photos) File Extension Image Photo Resolution non-interlace 9600x6400 .png interlace 1200x800 .bmp 9600x6400 Table 4: Media Support Specifications (Internal Subtitles) File Extension Container Subtitle Codec .dat .mpg DVD Subtitle .mpeg MPEG .vob .trp DVB Subtitle .tp”...
- Page 76 Table 5: Media Support Specifications (External Subtitles) File Extension Container Remark SubViewer MicroDVD .sub SubViewer 1.0 & 2.0 Only DVDSubtitleSystem SubIdx(VobSub) .txt TMPlayer...
- Page 77 © 2015 Toshiba Lifestyle Products & Services Corporation. All rights reserved. Specifications are subjected to change without prior notice.
