ELECTRONICS
USB/Audio Jack (AUX)/Bluetooth Operation
USB/AUX
The USB/AUX Jack is located in the cen-
ter of the gear shift zone, below the HVAC
controls.
• USB/iPod Mode is entered by either
inserting a USB Jump Drive or an iPod
cable into the USB port or by pushing
the MEDIA button on the faceplate lo-
cated below the display. Once in Media
Mode, press the "Source" button on the
touchscreen and select USB/iPod.
NOTE:
The USB source will say "iPod" only when an apple product is connected to the USB
port.
• Push the MEDIA button on the faceplate, press the "Source" button on the
touchscreen then select USB/iPod to change the mode to the USB device. If the
device is connected, music from your portable device will play through the
vehicle's speakers.
Audio Jack (AUX)
The AUX jack allows a portable device, such as an MP3 player or an iPod, to be
plugged into the radio and utilize the vehicle's audio system, using a 3.5 mm audio
cable, to amplify the source and play through the vehicle speakers.
• Push the MEDIA button on the faceplate, press the "Source" button on the
touchscreen then select AUX to change the mode to AUX.
• The functions of the portable device are controlled using the device. However, the
volume may be controlled using the radio or portable device.
Bluetooth
If using a Bluetooth - equipped device, you may also be able to stream music to your
vehicle's sound system.
Push the MEDIA button on the faceplate, press the "Source" button on the
touchscreen then select Bluetooth to change the mode to Bluetooth. If the device is
paired, music from your portable device will play through the vehicle's speakers.
Uconnect 5.0 Available Media Hubs
Uconnect 5.0
S = Standard Equipment
N/A = Not Available
98
Media Hub
(USB, AUX Ports)
S
USB Port And Audio Jack (AUX)
1 — USB Port
2 — AUX/Audio Jack
Remote USB Port
(Fully Functional)
N/A
Remote USB Port
(Charging Only)
S
