Performance Data Sheet
GXWH20S system using FXUSC (Rev. 2) filter has been tested according
to NSF/ANSI 42 for reduction of the substances listed below. The
concentration of the indicated substances in water entering the system
SUBSTANCE
Particulate, Class V particles 30 to < 50
Replacement Filter Cartridges
Several variables determine how long the cartridge will
last in your Household Water Filtration Housing. These
include:
■ levels of sediment or other undesirable substances in
your water.
■ the amount of water you use.
■ the filter location (filtering all or part of your
household water).
Filter Cartridge Replacement
You should change your filter when the water flow is noticeably reduced or at least every 3 months.
Turn off water to filter. For model GXWH04F, water
1
must be shut off from an upstream valve. For model
GXWH20S, rotate control handle to the BYPASS or
OFF position. (See Control Handle .)
Press the red pressure-release button to release
2
pressure.
Unscrew the filter canister and discard used filter.
3
Wash the filter canister with mild soap and water.
Do not use harsh cleaners or hot water.
Inspect the filter canister O-ring. Make sure it is
4
lightly lubricated with clean food-grade silicone
grease (silicone grease is available through GE Parts
and Service: 1.800.626.2002, part number
WS60S10005). Be sure the O-ring is seated in
the groove. It is recommended that you replace
the O-ring if it is damaged.
Place a new filter cartridge into the canister, making
5
sure it is centered and completely seated on the
bottom seal.
Control Handle (GXWH20S Model Only)
OFF
■ Shuts off water.
support@fridgefilters.com

ABOUT THE FILTER CARTRIDGE

INFLUENT CHALLENGE REDUCTION
CONCENTRATION REQUIREMENT
At least 1,000 particles/mL > + 85%
GE MODEL
FXUSC (Rev. 2)
FXWPC
FXWTC (Rev. 2)
*Above data are based on manufacturer's internal testing.
Reinstall the filter canister to the unit. Tighten filter
6
canister to seal. Use canister wrench if necessary.
Slowly rotate control handle to the FILTER position
7
(model GXWH20S) or slowly turn on the upstream
shut-off valve (model GXWH04F).
Press the red pressure-release button to remove
8
trapped air.
Open any downstream faucet and allow filter system
9
to flush for 30 minutes (model GXWH20S) or
15 minutes (model GXWH04F).
GXWH04F
Timer
Filter
cartridge
FILTER
■ For filtered water. Directs water
flow through filter.
2
800-683-8353
was reduced to a concentration less than or equal to the permissible limit
for water leaving the system, as specified in NSF/ANSI 42. While testing
was performed under standard laboratory conditions, actual performance
may vary.
Rated Service Flow: 4 gpm
Minimum–Maximum Supply Water Pressure: 20–125 psi
Minimum–Maximum Supply Water Temperature: 40–100°F
FUNCTION LIFE
Sediment* 3 month/16,000 gallons*
Sediment* 3 month/16,000 gallons*
Sediment* 3 month/15,000 gallons*
5 Micron
Chlorine
Red pressure-
release button
Head
Head Red pressure-
release button
O-ring seal
Filter canister
■ Permits flow of water to the house without flowing
through the filter. Use this position for filter
changes or if filtered water is not desired.
support@fridgefilters.com
800-683-8353
Rated Service Flow: 4 gpm
CONSTRUCTION
Polypropylene Fiber
Pleated
Carbon Paper
Turn canister wrench
clockwise to remove
Filter canister
GXWH20S
Timer
Control
handle
O-ring seal
Filter
cartridge
Filter canister
BYPASS
