Thank you for purchasing TOA's Chairman Unit and Delegate Unit.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

1. SaFeTY PreCaUTiOnS

• Before installation or use, be sure to carefully read all the instructions in this section for
correct and safe operation.
• Be sure to follow all the precautionary instructions in this section, which contain important
warnings and/or cautions regarding safety.
• After reading, keep this manual handy for future reference.
Warning
CaUTiOn
Warning
• Do not expose the unit to rain or an
environment where it may be splashed by
water or other liquids, as doing so may
result in fire or electric shock.
• Avoid installing or mounting the unit in
unstable locations, such as on a rickety
table or a slanted surface. Doing so may
result in the unit falling down and causing
personal injury and/or property damage.
• Should the following irregularity be found
during use, immediately stop supplying
the power and contact your nearest TOA
dealer. Make no further attempt to operate
the unit in this condition as this may cause
Indicates a potentially hazardous situation which, if mishandled,
could result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
inSTrUCTiOn manUal
TS-811, TS-911
TS-812, TS-912
fire or electric shock.
· If you detect smoke or a strange smell
coming from the unit.
· If water or any metallic object gets into the
unit
· If the unit falls, or the unit case breaks
· If it is malfunctioning (no tone sounds.)
• To prevent a fire or electric shock, never
open nor remove the unit case as there
are high voltage components inside the
unit. Refer all servicing to qualified service
personnel.
• Do not place cups, bowls, or other
containers of liquid or metallic objects on
top of the unit. If they accidentally spill into
the unit, this may cause a fire or electric
shock.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-811 and is the answer not in the manual?

Questions and answers

Related Manuals for Toa TS-811

Summary of Contents for Toa TS-811

  • Page 1: Safety Precautions

    TS-811, TS-911 DelegaTe UniTS TS-812, TS-912 Thank you for purchasing TOA’s Chairman Unit and Delegate Unit. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment. 1. SaFeTY PreCaUTiOnS • Before installation or use, be sure to carefully read all the instructions in this section for correct and safe operation.

  • Page 2: General Description

    * Collectively referred to as a Conference unit. 3. FeaTUreS • The TS-911/912 unit features a voting function and base language/translation language selection function, while the TS-811/812 unit is equipped only with speaking and monitoring functions. • Chairman units feature a Speech priority function that allows speech made by the Chairman unit to take precedence over that by the Delegate units with the simple press of the Priority speech key. • DIP switch settings determine the following operations: Conference unit operating status after priority speech completion, Priority chime ON/OFF, and Priority speech key operation mode.

  • Page 3: Specifications

    4. SPeCiFiCaTiOnS 4.1. TS-811 Chairman Unit, TS-812 Delegate Unit Model Number TS-811 TS-812 Power Source 24 V DC (supplied from the optional TS-918 Expansion unit) Current Consumption Max. 60 mA Modulation Method Frequency modulation Carrier Frequency Transmission: Audio channel 1 7.35 MHz Audio channel 2 8.10 MHz Audio channel 3 8.55 MHz Audio channel 4 9.15 MHz Control channel 6.45 MHz Reception: Audio channel 1.95 MHz Input Microphone terminal: X LR-4-31 type (dedicated for connecting the...
  • Page 4 Headphone volume control, Priority speech function, Voting function, Voting function, Monitor selector switch (MAIN/SUB) Monitor selector switch (MAIN/SUB) Operating Temperature 0 to 40 ºC (32 to 104 ºF) Operating Humidity 90 %RH or less (no condensation) Finish Top panel: ABS resin, gray metallic, paint, semi-gloss Dimensions 210 (w) x 68.6 (h) x 152 (d) mm (8.27" x 2.7" x 5.98") Weight 570 g (1.26 lb) note: The design and specifications are subject to change without notice for improvement. • Optional products Microphone: TS-903, TS-904 (Select either one.) Traceability Information for Europe Manufacturer: Authorized representative: TOA Corporation TOA Electronics Europe GmbH 7-2-1, Minatojima-Nakamachi, Chuo-ku, Kobe, Hyogo, Suederstrasse 282, 20537 Hamburg, Japan Germany URL: http://www.toa.jp/ 133-02-00131-01...
