Toa WD-4800 Specifications

P S
®
ASSWORD
U H F W
I R E L E S S
M
I C R O P H O N E
S
Y S T E M S
TOA PASSWORD® SERIES
WIRELESS MICROPHONE SYSTEMS
combine cutting edge wireless technology with
user benefits such as fast setup, simple opera-
tion, and reliable performance.The systems are
frequency-agile with sixty-four user-selectable
channels in the uncrowded UHF band (692 - 722
MHz) with simultaneous operation of up to
sixteen systems.
The WT-4800 True Diversity Receiver has an
on-board scanner and three squelch types,
carrier, noise and tone-key, to ensure quiet,
interference-free operation. Other receiver
features include Antenna Loop outputs for anten-
na distribution for up to two additional receivers
and a convenient Mix-In jack for
connecting the audio output of a second
WT-4800 or other source. Receiver options
include the MB-WT3 and MB-WT4 Rack-Mount
Kits for single or dual WT-4800 mounting in only
one 19" rack space, the WD-4800 Antenna
Distributor and the YW-4500 Remote Antenna.
Password® transmitter options include the
WM-4200 Handheld Microphone and the
WM-4300 Lapel Microphone with Bodypack.
Both offer ten hours of operation from one nine
volt battery,low battery indication and adjustable
sensitivity.The WM-4300 bodypack also has a
recessed on/off switch to prevent accidental
shut-off,a mini-XLR jack for alternative mic
elements and rotatable lapel and bodypack clips
for versatile mounting.
Password® Series wireless systems are FCC and UL
listed and are backed by a five year warranty.
ERIES
H
I G H L I G H T S
Applications
A/V Rentals
Bingo Halls
Boardrooms
Community Centers
Fitness Clubs
Hotels
Houses of Worship
Presenters
Restaurants
Schools
Theatres
P
A S S W O R D
Password-H
Password-L
Password-HL
P
A S S W O R D
MB-WT3
MB-WT4
WD-4800
YW-4500
* Each receiver supports one transmitter at a time.
S
®
Y S T E M S
Handheld Mic, Receiver and Rack-Mount Kit
Lapel Mic and Bodypack, Receiver and Rack-Mount Kit
Handheld/Lapel Combo, One Receiver and Rack-Mount Kit*
O
®
P T I O N A L
Rack-Mount Kit for One WT-4800 (1 RU)
Rack-Mount Kit for Two WT-4800 (1RU)
Antenna Distributor for up to Four WT-4800 (1RU)
Remote Antenna
Features
Professional Wireless
Microphone Systems
Frequency-Agile —
Sixty-Four Channels
UHF Band (692 - 722 MHz)
Up To Sixteen Simultaneous
Systems
On-Board Scanner
True Diversity Reception
Handheld And Lapel
Microphone Systems
Ten Hours Continuous
Transmitter Operation from
One Nine Volt Battery
FCC and UL Listed
Five Year Warranty
A
C C E S S O R I E S
