Icom FP-561 Service Manual page 5

' VIDEO SOUNDER
• Transmission freq.
• Output power
• Water depth range
• Water temp. range
• Speed range
• Bottom lock expansion range
• Phase shift variable range
• Type of display screen
• Picture sweep speed
• Alarm
*selectable in each unit
1-2 RD-200
' GENERAL
• Frequency coverage
• Type of emmision
• Antenna impedance
• Intermediate frequency
• Usable temperature range
• Power supply requirement
• Current drain (at 12 V DC)
• Dimensions (projections not included) : 140(d)×157.2(H) mm; 5
• Weight
' RECEIVER
• Intermediate frequency
• Sensitivity
• Sprious response
• Intermodulation
All stated specifications are subject to change without notice or obligation.
fineline6
: 50 kHz, 200 kHz
: 500 W RMS
: 5–640 m* in 8-color indication
: 0˚C to +40˚C; +32˚F to +104˚F
: 0.0–99.9 KT*
: 5 m*, 10 m*, 20 m*, 40 m*
: 1–640 m*
: Standard, A-scope, dual frequencies, bottom and marker zoom
: 6 levels including pause
: Shallow, depth and fish school
: 283.5 kHz to 325.0 kHz
: 1K0F2B
: 50 Ω nominal
: 455 kHz
: –20˚C to +70˚C; –4˚F to +158˚F
: 12 V DC nominal negative ground
: Less than 0.2 A
1
⁄ (d)×6
2
: 1.0 kg; 2 lb 3 oz
: 455 kHz
: 0.2 µV at 12 dB SINAD
: 60 dB
: 50 dB
1 - 2
3
⁄ (H) in
16
