6. Place removable finger lift with saw guard assembly (Part No. A211) on the saw guide bar (Part No. 116-22) and
fasten in place with finger lift fastener knob (Part No. 211A-291Q).
7. Placing blade on cutter: Hang upper wheel assembly (Part No. A16003U335-6) on the hinge bracket (Part No.
71-1). lift the nylon filler (Part No. 177). Hang blade on the upper wheel and hold with right hand. With left hand
force the back of the blade between the front blade cleaners (Part No. 131), located below the nylon filler. Lower
the nylon filler and insert the back of the blade in the upper saw guide (Part No. 602B). The blade has already
dropped over the lower wheel. With right hand force the back of the blade between the rear blade cleaners (Part
No. 131). The blade is now ready to be tightened. Press down on the ratchet arm (Part No. 10-1) located at the
rear of the base structure. Turn the upper wheel slowly by hand to ensure proper tracking of the saw blade on
the wheels. Tighten to proper tension. When the tension gauge (Part No. 16197), located at the bottom rear of
the head becomes tight laterally the blade is at proper tension.
8. The side platter bracket (Part No. S12214B) is packed loose in the machine and must be installed on the left side
of the base structure with the supplied hardware and checked for proper adjustment. Stationary platter must be
flat.
9. The stationary platter (Part No. A16163-1) is placed on top of the base structure and held in place by two
push-pull hold down catches (Part No. 16212), located on the base structure.
10. The sliding meat carriage assembly (Part No. A16155) is installed by turning the movable stop assembly (Part No.
A16200) clockwise.
counterclockwise to lock.
11. Post SAFETY TIPS wall chart within easy view of operator. Keep Manual available to operator.
12. Machine MUST be properly grounded. Use qualified electrician to install according to building codes.
WIRING MOTOR
(1) Interchange of current is made in motor outlet box. Leads are properly marked. Changing instructions are
on motor plate or motor outlet box.
(2) All cutters are wired 220 volts unless otherwise specified. Be sure motor specifications (voltage, cycle, phase)
match power supply line. Be sure line voltage is up to specification.
(3) Connect leads to machine in a manner that will be approved by local electrical inspectors.
(4) We recommend no less than No. 12 wire. If the leads are too light, machine may not have sufficient cutting
power and/or speed.
(5) The drive belt is packed loose in machine to prevent deformation, and must be installed on pulleys at time of
wiring motor.
(6) The BIRO Manufacturing Company is not responsible for permanent wiring, connection or installation.
SHARP SAW BLADE. HANDLE WITH EXTREME CAUTION
After the carriage assembly is in the channel for operation, turn the movable stop
NOTE TO OWNER AND ELECTRICIAN: IF THIS MACHINE IS NOT CORD
AND PLUG CONNECTED TO THE ELECTRICAL SUPPLY SOURCE, THEN IT
SHOULD BE EQUIPPED WITH, OR CONNECTED TO, A LOCKABLE,
MANUALLY OPERATED DISCONNECT SWITCH (OSHA 1010.147).
KEEP HANDS CLEAR OF SHARP MOVING BAND TYPE SAW BLADE
