MODEL 3334 PARTS NUMBERS AND DESCRIPTIONS (Cont.)
Item No. Description
71-1 Upper wheel hinge bracket SS
708 Saw guard safety decal
710 Decal, "Blade Tension"
7810-G Toggle switch, 3 ph
Item No. Description
AS1120EZ Channel assembly w/center guide
(3334-4003 only)
AS16005 Head & door assembly
AS16006 Head door assembly, SS
AS16120 Channel assembly, SS
AS16217R Hinged base door – old style
AS16217R-3 Hinged base door – new style
AS16273-275 Meat gauge assembly
AS16275
Meat gauge plate with release assembly
AS16290 Cleaning unit stamping assembly, SS
AS239-B30-B Bolt-on base foot & leg assembly w/fasteners
AS415D Stationary bar assembly SS
A116-22AL Saw guide bar assembly 22² – aluminum
A116-22SS Saw guide bar assembly 22² – stainless
A130 Steel cleaner assembly
A16Z Guide brkt saw cleaner assem
A16003U-6 Up wheel assem without hinge plate
A16003U335-6
Up wheel assem with hinge plate
A16005 Head & door assembly
A16006 Head door with hinge assem
A16014L Head door hnge assem, lwr, shrtpn
A16014U Head door hnge assem, upr, lngpn
A16112 Head door latch assembly
A16132 Steel cleaner assembly, rear
A16155 Meat carriage assembly
A16163-1 Stationary platter assembly
A16163-E Stationary platter assembly, England
MODELS EQUIPPED WITH STAINLESS STEEL FABRICATED HEADS
Stainless steel heads became available (as optional equipment) starting with Ser. #23265. From Ser. #23265 to
Ser. #25059 and starting again with Ser. #36272, these stainless steel heads were mated to the base structure in the
same fashion as the aluminum head using the Item #260 slide gib. From Ser. #25060 to Ser. #36251 the machined
blocks were eliminated and the slide gibs redesigned to a dovetail configuration to secure the head.
PARTS EXCLUSIVE TO 3334SS WITH OPTIONAL STAINLESS STEEL HEAD STRUCTURE
Item No. Description
S16005 Head, SS, 1st design, ser. #23265
to Ser. #25059, replaced by
S16005C
S16005B Head, SS, 2nd design, Ser.
#25060 to Ser. #36251, (uses
dovetail slide gibs) replaced by 1
ea. #S16005C and 2 ea. #260
S16005C Head, SS, current design, Ser.
#36272 to present, (uses #260
slide gibs)
(The Factory Does Not Recommend Field Conversions)
*NOTE Stainless steel (S12214) side platter kits available
before Ser. No. 24464 — check with Biro Service
Dept.
Item No. Description
A16163-M Platter assembly, Govt., Size 2
A16196 Tension spring assembly
A16200 Channel stop assem movable
A16220-1 Channel stop assembly fixed
A247-1 Up shaft brg assem without wheel
A16278 Meat gauge plate assembly less release as-
sembly
A16335X Hinge plate assembly
A16360
Lower bearing housing assembly
A16361 Lower shaft bearing assembly
A16547 Lower bearing housing assembly, removable
wheel
A181155EZ Meat carriage assembly w/center guide
(3334-4003 only)
A19-1 Ratchet assembly
A175S Thumb guard assembly
A211-AL Finger lift assembly, removable – aluminum
A211-SS Finger lift assembly, removable – stainless
A227 Up bearing cup/cone assembly
A249R Base door handle assem, right
A260 Aluminum slide gib assembly
A262 Meat gauge release assembly
A295 Wheel cleaner assembly
A363 Lower bearing cup/cone assem
A415D Stationary bar assembly
A602 Saw guide assembly, upper
A661-1 Saw guard on head door assembly
A71-1 Upper wheel hinge bracket assembly
Item No. Description
S16006 Head door, SS, all SS heads
16260ZA Slide gib, dove tail type, Serial
#25060 to Ser. #36251, no
longer available
16662 Saw guard on saw guide bar, SS
all SS heads
