Summary of Contents for Hama DR1510
- Page 1 00054826 (DR1510) Digital Radio Digitalradio Operating Instructions...
- Page 2 Technical Data DAB+ Internet Spotify Radio Receiver ü ü ü Connectivity Bluetooth v. 3.0 (A2DP, AVRCP) Display 2.8“ 2x16 Icon LCD Speaker 6W RMS (2 x 3W) Impedance 4 ohm 3“ Speaker Power input 110-240 V ~ 50-60 Hz DAB/DAB+: Frequency range 174-240 MHz 87.5-108 MHz...
- Page 3 11 12...
-
Page 4: Operating Instructions
G Operating Instructions Controls and Displays A: Front Rotate: Volume control [volume / Press: On/off switch [info] Display additional information Direct access to the menu / [menu] Back one menu level Changing operating mode [mode] (Bluetooth, DAB, FM, Aux in) [pair] Direct access to pairing mode Direct access to alarm clock... -
Page 5: Table Of Contents
Content 1. Explanation of Warning Symbols and Notes ... 5 12.1 Equalizer ........14 12.2 Time/ Date. -
Page 6: Menu Structure
Menu structure Station list Full scan Manual tune DRC on DRC high DRC low Clear System Scan setting Strong stations only? All stations Audio setting Stereo allowed Forced mono System Bluetooth System Auxiliary input System System Sleep 15 Minutes 30 Minutes 45 Minutes 60 Minutes 90 Minutes... - Page 7 Power on High Standby Medium High Language Factory Reset Software-Upgrade SW-Version...
-
Page 8: Explanation Of Warning Symbols And Notes
Thank you for choosing a Hama product. Take your time 3. Safety Notes and read the following instructions and information • The product is intended for private, non-commercial use completely. Please keep these instructions in a safe place only. for future reference. If you sell the device, please pass •... -
Page 9: Informations And Notes Before Getting Started
AC power grid. Please note Selection (navigate) Confirmation (enter) that a country-specific adapter may be necessary. You can find an appropriate selection of Hama products at www.hama.com. Note • Only connect the product to a socket that has been approved for the device. -
Page 10: Initial Setup
Additional information 5.3 Initial setup Press [info] to display context-dependent additional A station search in DAB operating mode is automatically information. The information shown depends on the started when you switch the radio on for the first time. operating mode as well as the current selection of radio English is the default language for the radio’s menu station. -
Page 11: Station List
Proceed as follows, choosing a frequency range between 6.3 Station list 5A and 13F: You can access the station list in DAB mode at any time via two methods: a) If a station is already playing, simply turn [enter/ [menu] navigate]. -
Page 12: Presets
6.5 Presets 6.6 DRC (Dynamic Range Control) You can save up to 30 of your favourite stations for quick Some radio stations in the DAB network support an audio and direct access. level control that is activated at varying volumes during playback. -
Page 13: Scan Setting
7. FM 7.2 Automatic station search After pressing [mode] repeatedly, activate operating mode • Press and hold [enter/navigate] until the automatic station search starts. • The radio stops the search and starts playback when it finds a station. [mode] • Press [enter/navigate] to continue the search until the next station is found. -
Page 14: Access Favourites
7.4.2 Access favourites 8. Auxiliary Input Press [memory] to open the overview window with the list Via the analogue audio input (AUX IN socket) you can of saved stations. connect mobile devices (for example smartphone, tablet PC, M3 player etc.) to the radio and play the audio files using the radio´s speakers. -
Page 15: Biuetooth Pairing
• Check the Bluetooth settings of your terminal device to see whether DR1510 is connected. If not, repeat the steps listed under Bluetooth pairing. [pair] • Check whether your terminal device and the radio are Press and hold less than 10 metres apart. -
Page 16: Alarms
11. Alarms Date: If you selected Once, enter the date for the one-off alarm. The Radio has two individually adjustable alarm times. Volume: 11.1 Alarm settings You can set the volume at which the alarm sound should Alarm 1 and alarm 2 are configured identically. Select be played. -
Page 17: System Settings
12. System settings 12.2 Time/ Date You can modify all settings and access important To access the time settings, proceed as follows: information about the radio in the System settings. [menu] 12.1 Equalizer The equaliser allows you to adjust the sound of the radio to suit your preferences by amplifying or reducing the amount of bass or treble in the audio . -
Page 18: Language
We recommend that you keep your radio’s software up to [menu] date. You can find information on performing an update separately on the enclosed sheet and/ or you can System download it as a PDF at www.hama.com. Language 12.6 Info Wished Language •... -
Page 19: Aux: Auto-Standby
14. Warranty Disclaimer Hama GmbH & Co. KG assumes no liability and provides no 17. Declaration of Conformity warranty for damage resulting from improper installation/ Hama GmbH & Co. KG hereby declares that the... - Page 20 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Hama GmbH & Co KG is under license. Other trademarks and trade names are those of their respective owners.
