Page 1 DAB+/FM Radio...
Page 2: Table Of Contents
Contents Where to put your radio �� 3 Tune to an FM preset station �� 11 Setting up ��...
Page 3: Where To Put Your Radio
Product Set Up Where to put your radio Step 3: When switching on for the first time, slide the power switch on the back of the radio, to ‘On’ �� ‘Welcome to Digital It is important that you consider carefully in advance where Radio’...
Page 4: Using Headphones
If used continuously on battery power, your radio has an • CAUTION: Danger of explosion if batteries are incorrectly approximate battery life of 10 hours when using good quality replaced�� Replace only with the same or equivalent type�� batteries�� When the battery power is low, ‘Battery Low’ will •...
Page 5: Your Dab+/Fm Radio
Your DAB+ / FM Radio Telescopic aerial Backlit display Carry handle Speaker Standby Sleep/Snooze DAB+/FM Mode Back Menu Scroll forward Scroll back Alarm Scan Vol + Enter Preset - Vol Info. Volume Mute Mains power socket Stereo headphone socket (at rear) (at rear) On/off switch Battery compartment...
Page 6: Using Your Dab+ Radio
Using your DAB+ Radio Mute the volume Switch on Press the ‘Mute’ button to temporarily mute the radio Press the ‘Standby’ button on the front of the radio�� The volume�� Press the ‘Mute’ button again to listen to the radio�� display will switch on and your radio will return to the mode that it was last used in (DAB+ or FM)��...
Page 7: Prune Dab+ Stations
Storing a DAB+ station preset 1�� If you are not already in DAB+ mode, briefly press the ‘Mode’ button to go to DAB+ mode�� Your radio can store up to 10 DAB+ stations in its preset memories for instant access to your favourite stations�� ...
Page 8: Dab+ Display Information
Multiplex Name - displays the broadcasting area and �� Use the button on the front of the radio to scroll to collection of radio stations on this frequency e��g��: the Preset location and station that you would like to listen to BBC National DAB+, Digital 1 Network��...
Page 9: Dynamic Range Control
Dynamic range control (DRC) 1�� Press the ‘Menu’ button�� Use the button to scroll to ‘DRC’ and press the ‘Enter’ In DAB+ mode: button�� The current DRC setting will have an ‘*’ next to it�� The dynamic range for each radio programme is set by the 3��...
Page 10: Fm Radio Mode
Using the FM Radio FM Radio Mode �� Press and release the ‘Scan’ button on the front of your radio to scan up the frequency band�� Press and hold ‘Scan’ to scan When your radio is in FM mode it can receive Radio Data down the frequency band��...
Page 11: Tune To An Fm Preset Station
�� Use the button on the front of the radio to scroll to �� Use the button to scroll to Strong Stations or All the Preset location and station that you would like to listen to Stations and press the ‘Enter’ button to select�� (1 - 10)��...
Page 12: Fm Display Information
FM display information When listening to an FM station you can change the information that will appear on the second line of the display�� There are several different types of information that are sent by the broadcaster�� RDS Radio text - this is scrolling text information supplied by the broadcaster��...
Page 13: Set The Time And Date
Set the Time and Date Setting the time and date When you confirm the correct date, ‘Time Saved’ is displayed and the display returns to ‘Set Time/Date’ �� The first time you listen to DAB+ radio, the time and date You can now use the same method as you did to set the time of your product will be synchronised automatically to that and date to change the settings for:...
Page 14: Stop The Alarm
Turn off the Alarm 5�� Use the button to scroll to the duration for the alarm�� You can choose from 15, 30, 45, 60 and 90 minutes�� Press In Standby mode: ‘Enter’ to confirm�� Briefly press the ‘Alarm’ button repeatedly to turn Alarm 1 6��...
Page 15: Menu Options
‘Restarting�� ’ is displayed�� After a few seconds the display will You can change the display language of your radio, there are change to ‘Welcome to Digital Radio’ and then ‘Scanning�� ’ 4 options available, English, French, German and Italian��...
Page 16: Software Version
Software version 1�� Press the ‘Menu’ button on the front of the radio�� Use the button to scroll to ‘System’ and press ‘Enter’ �� ‘Time’ is displayed�� Use the button to scroll to ‘SW version’ and press ‘Enter’ �� The software version will be displayed��...
Page 17: Technical Information
Technical Information Specification Power adaptor: Output DC 5V 1A�� Input AC 100-40V Batteries: 4 x AA (Optional, not supplied) Output: 1 x 1W RMS Frequency range: DAB+ Band III, 174 MHz to 40 MHz 87��5 MHz to 108 MHz...
Page 18: Simple Solutions
Simple Solutions If you are experiencing problems with your radio there You may need to re-scan if the station you last listened to is are some quick and easy checks that you can do, which no longer available�� See page 6�� may help to solve the problem.
Page 19: Care And Maintenance
General Information Care and Maintenance Only use the power supply that came with the product�� Using an unauthorised power supply will invalidate your Your radio is of superior design and manufacture and should guarantee and may irrecoverably damage the radio�� be treated with care��...
Page 20: Consumer Product Warranty
Consumer Product Warranty (Warranty against Defects) purchased by you in Australia or New Zealand from a The purchase of a Magicbox product (hereinafter referred to Magicbox Authorised Dealer when the good does not in this Standard Warranty as “good(s)”) includes coverage by perform in accordance with the manufacturer’s specifications...
Page 21 Consumer Product Warranty 1��7 The cost of repair or replacement of the good shall be at (d)�� To damage arising out of or during transportation, Canohm’s cost but Canohm and its Authorised Service installation or while moving the good, or to any Centres may seek reimbursement of any costs incurred by transportation costs of the good or any parts thereof to them when the good is found to be in proper working order��...
Page 22 In order to assist with this process you (II)�� where the receivers are being used in areas which may visit the Support section located on the Magicbox are “not covered” by DAB+ broadcasts�� (In Australia website�� refer to Commercial Radio Australia’s website (b)��...
Page 23 Consumer Product Warranty For further details or to find your nearest Magicbox Authorised Service Centre please contact: Toll Free on 1800 636 026 Australia Web: www.magicboxaudio.com.au or email service@canohm.com.au Toll Free on 0800 486 435 New Zealand Web: www.magicboxaudio.co.nz or email: info@mayogroup.co.nz...
Page 24 Issue 1/Dec12...
