Controls

▶ To gain access to the controls, pull the flap towards you and swing down.
1
10
9
8
7
Fig. 1 Basic boiler controls
1 Master switch for ON/OFF
2 Power ON and fault indicator (blue)
Boiler
Controls
3 Boiler display
4 Reset button
5 Not used
ErP
Greenstar FS CDi – 6720818078 (2015/12)
3 4
5
2
1 6
max
2 3
reset
eco
6 Not used
7 Central heating temperature control
8 Service Engineer button only
9 Service Engineer button only
10 Burner ON indicator light (green)
Controls
4
5
6
