VITA VACUMAT 6000 M ® Operating manual VITA Farbkommunikation VITA Farbkommunikation VITA shade determination VITA shade communication VITA shade reproduction VITA shade control Date of issue: 11.15 VITA shade, VITA made.
VITA VACUMAT 6000 M ® Table of contents 1 Introduction 2 Scope of delivery 2.1 Control unit VITA vPad 2.2 Accessories (can be purchased separately) 3 Technical Information 4 Technical Data 4.1 Dimensions/weights 4.2 Electrical data 4.2.1 Furnace 4.2.2 Vacuum pump...
(maintenance, inspection, repairs), either with or on the device. We hope that you will find using the VITA VACUMAT 6000 M to be an enjoyable and successful experience. Copyright These operating instructions must be treated as confidential.
The VITA VACUMAT 6000 M can be equipped with the following control units: • VITA vPad comfort with 7” LED color touch screen, photo viewer, memory for 500 firing programs for control of 1 or 2 VITA VACUMAT 6000 M / VITA VACUMAT 6000 MP and VITA ZYRCOMAT 6000 MS.
• Reduce your energy bills up to 70 % with VITA Energy Efficiency • With the VITA vPad, all your information is stored in one location – program parameters, integrated working instructions for the VITA materials, patient photos, as well as all data related to the firing process •...
VITA VACUMAT 6000 M ® 5 Intended use Basic information on the instrument design The device is designed according to the state of the art and recognized safety standards. However, if it is used inappropriately, hazards for the health and safety of the user or third parties may arise as well as the risk of damaging the device and other material property.
• automatic prevention of condensation in the firing chamber (VITA AntiCon) • automatic temperature adjustment to +/-1 °C every time a program is started (VITA AutoAdjust) • Automatic cleaning function (VITA SpecialClean) • Controlled fast cooling and energy-saving night mode (VITA Energy Efficiency) •...
• Prevent direct sunlight from coming into contact with the device. • Do not place any flammable objects in the vicinity of the device. Do not place the VITA vPad control unit directly in the heat radiation area of the firing chamber.
• Green – device in standby operation • Blue – program active • Red – error Read the corresponding operating manual for the VITA vPad. 9.4 Fuses On the back of the device (see Section 9.2) there are 2 fuses for the device.
Information! For information about the connections, refer to Section 9.2 • Attach the connection cable to the VITA vPad control unit and the furnace. • Plug in the status display • Connect the vacuum pump, electrical connection and tubing connection.
In all cleaning work, you must never use any detergents or flammable liquids. 10.1 Cleaning firing for the firing chamber Consult the operating manual of the VITA vPad for information about the cleaning firing. 10.2 Firing chamber insulation The firing chamber contains ceramic mineral fibers as insulation material (Index No.
Important! Once mains power is supplied again, the time required for the VITA vPad to switch back on again is approx. 20 sec. 14 Warranty and liability The warranty and liability are based on the terms and conditions stipulated in the contract.
Connecting the device to the mains voltage Copyright Technical data Technical information Device connections Dimensions/weights Unauthorized modes of operation Disposal VITA vPad comfort Electrical data VITA vPad excellence Fuses General description Guarantee Identification plates Installation and first use Installation location...
Page 16
Claims for damages based on fault liability (culpa in contrahendo, breach of contract, unlawful acts, etc.) can only be made in the case of intent or gross negligence. The VITA Modulbox is not necessarily a component of the product.
