Smart Weather Sensor Please Read Before Use This manual is valid for devices of the Lufft WS family with device version 31 or higher(7/2012).Some functions or features specified in this manual may not be available or may not be valid with older device versions. The device version is indicated as the last number of the serial number, e.g.: the device with SN: 063.1010.0701.021has the...
Compass WS501-UMB 8375.U01 WS502-UMB 8375.U10 WS503-UMB 8375.U11 WS504-UMB 8375.U12 WS510-UMB 8375.U13 Wind Direction Wind Speed Air Temperature Relative Humidity Air Pressure Compass Global Radiation G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 8
Global Radiation WS800-UMB 8381.U01 (Europe, USA, Canada) Precipitation Radar Wind Direction Wind Speed Air Temperature Relative Humidity Air Pressure Compass Global Radiation Lightning Sensor G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
8160.WT1 Passive Road Surface Temperature Sensor WST1 8160.WST1 Spare Parts Connection cable 10m On enquiry Additional Documents and Software You can download the following documents and software via the Internet at www.lufft.com. Operating Manual This document ® UMB-Config-Tool...
Absolute air pressure is measured by way of a built-in sensor (MEMS). The relative air pressure referenced to sea level is calculated using the barometric formula with the aid of the local altitude, which is user-configurable on the equipment. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
The type of NTC is the same as used for the internal air temperature sensor. External temperature sensor and external rain gauge can not be connected at the same time. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
4.14 External Rain Gauge Models without integrated precipitation acquisition can be equipped with an external rain gauge. External rain gauge and external temperature sensor can not be connected at the same time. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Air pressure sensor in device Air temperature and relative humidity with fan on underside of device Connector Mounting bracket with springs and self-locking nuts Notch for attaching connection cable Figure 1: Sensor Technology G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
The function will be activated with the first request to any of the standard deviation channels. To get standard deviation values of the first integration period after power on a dummy request to any one of the standard deviation channels should be inserted. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Note: For the correct calculation of relative air pressure, the altitude of the sensor must be entered in the device configuration (see Figure 11 on page 32). The factory setting for altitude is 0m; in this way both measurement variables deliver the same values. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Measuring Range Measurement Variable (float32) unit Specific Enthalpy -100.0 1000.0 kJ/kg Air Density Sampling rate 1 minute Unit kg/m³ Request channels: UMB Channel Measuring Range Measurement Variable (float32) unit Air Density kg/m³ G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
*) Note: The evaluation of the standard deviation values will be activated after the first request of a standard deviation channel. Please see p. 11. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Note: When the device is operated in Power Saving Mode 1 or 2 the compass measurement is performed only once after power on. Later changes of the orientation of the device will not be recognized. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
(WS401-UMB and WS601-UMB), as well as the external rain gauge, use the accumulated precipitation of the last 60 minutes prior to the current measurement for intensity calculation. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
*) Note: The average, maximum and minimum values are evaluated from the 1 minute averages of the 10 second spot value. When operated in Power Saving Mode 1 (see page 37) the WS700-UMB will measure the global radiation only once per minute. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Service channels are available for the surveillance of the operation of the Smart Weather Sensor. Request Channels: UMB Channel Measuring Range Measurement Variable (float32) unit 10000 Supply Voltage V 50.0 11000 Rain Drop Volume µ 500.0 µl G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Tighten the nuts evenly until contact is made with the springs but the sensor can still be moved easily Align the sensor to the North (for wind meters) Tighten both nuts with 3 revolutions G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Depending on the location, the variation can be more than 15° (in North America for example). In Central Europe the variation can be largely ignored at present (< 3°). You can find further helpful information on this subject on the Internet. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Otherwise cross effects and system malfunctions may occur. In the final analysis, the distance to other measuring systems also depends on their range of coverage and signal strength. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 25
Distance to shadow casting objects (trees, buildings) at least 10 times of the object height relative to the sensor. 7.3.6 Installation Sketch Example WS600-UMB: WS600-UMB min. 5 m Tree, bush etc. Mast min. 4.5 m min. 1 m Road carriageway Figure 5: Installation Sketch G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Starting with device version 037 the Smart Weather Sensor has an extended supply voltage range of 4 … 32V DC. Operation with a supply voltage of 24V is recommended. Limitations apply in case of supply voltages lower than 12V (see below). G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
RS485 Interface The equipment has an electrically isolated, half-duplex, 2 wire RS485 interface for configuration, measurement polling and the firmware update. See page 43 for technical details. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
The temperature sensors as well as the external rain gauge are unipolar, so any connection sequence can be chosen. The type of external sensor has to be set using the UMB Config Tool. For details please refer to Chapter18. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
If several Smart Weather Sensors are operated on a UMB network, a unique device ID must be assigned to each device (see page 31). There is no protective cover to remove on the sensor itself. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Note: You do require the current version of the UMB-Config-Tool to configure the Smart Weather Sensor. Note: All other devices which are used in the polling process, e.g. modems, LCOM etc., must be disconnected from the UMB network during configuration. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 31
Note: In order to calculate dew point, absolute humidity and mixing ratio, the temperature and humidity measurement always requires the same interval. For this reason different intervals cannot be set. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 32
Note: The offset is not used for the wind meter at present because on-site calibration is not possible in this case. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 33
Then the resolution is set in the sensor configuration using the UMB Config Tool. Figure 14: Precipitation Sensor Settings (Rain Gauge) Caution: If mechanical setting and configuration setting do not conform, the sensor will deliver wrong precipitation values! G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 34
The different settings are described in the following chapters: operating modes of Smart Weather Sensor from page 37 operating modes of the heating from page 39 G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 35
Precipitation Quantity Confirm the reset with ‘Yes’ Note: The precipitation quantities are reset in ALL Smart Weather Sensors on the respective UMB network. The devices reboots after this function has been used. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Note: The UMB Config Tool is provided for test and configuration purposes only. It is not suitable for the permanent acquisition of measurement data. We recommend the use of professional software solutions for this purpose, e.g. Lufft SmartView3. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Compared with normal operation the power consumption of a WS600-UMB can be reduced to 10% even neglecting the heating. (during precipitation events the consumption is slightly higher, due to the rain sensor then permanently switched on, about 20% compared to normal operation). G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 38
The minimum interval length must be hold up under consideration of the telegrams with other addresses. Mixed operation of devices in power saving mode 2 with devices in normal operation and fast request rates within the same UMB network is not possible. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
The heating controls at this temperature (in °C) Heating mode1 Temp.: Threshold temperature (in °C) with effect from which air temperature heating is enabled The ‘Eco Mode1 follow-up time’ setting is not relevant. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 40
Threshold temperature (in °C) with effect from which heating is enabled Eco mode1 follow-up time: Follow-up time (in minutes) Examples: Outside temperature constantly below 5°C; no precipitation for more than 24h Outside temperature constantly below 5°C; with precipitation G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
The length of the interval should be adapted to the local degree of pollution. A check and, if necessary, adjustment of the “Wet” threshold is recommended to include into the maintenance procedure. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Caution: each movement of the bucket generates a counting pulse and thus may cause faulty precipitation amounts Check water drain, clean if necessary Put funnel back in place and lock it by turning it to the right G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 44
1200, 2400, 4800, 9600, 14400, 19200 , 28800, 57600 (In SDI-12 mode, the interface is changed to meet the requirements of the standard.) Housing: Plastic (PC) Factory setting; baud rate for operation with ISOCON-UMB and firmware update. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
< 3° (> 1m/s) RMSE Response threshold: 0.3 m/s Internal sampling frequency: 15Hz Instantaneous value: 1 sec / 10sec Output rate for average and 1min – 10min (peak calculated from 1sec values) peak gust values: G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 46
Non-linearity (0 to 1000 W/m²) <0.2% Directional error (at 80° with 1000 W/m²) <10 W/m² Temperature dependence of sensitivity <1% (-10 to +40°C) Tilt error (at 1000 W/m²) <0.2% Spectral range (50% points) 285 ... 2800nm G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 47
1 minute In principle, all rain sensors with bounce-free reed contact (normally open or normally closed) and with a resolution of 0.1 mm, 0.2 mm, 0.5 mm or 1.0 mm can be used. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
EN 61000-6-3:2007Part 6-4: Generic Standards - Emission Standard for Industrial Environments EN 55011:2009 + A1:2010 (2011-04) Line-conducted disturbances IEC / CISPR 11:2009 and changes 1:2010 Class B prEN 50147-3:2000 Radiated emission Fellbach, 20.09.2013 Axel Schmitz-Hübsch G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
50% this may mean that there is a fault. This may be due to a number of reasons contact Device transmits an error value not the manufacturer’s technical support department. listed here G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
17.1 Technical Support Our Hotline is available for technical questions via the following e-mail address: hotline@lufft.de You can also consult frequently asked questions at http://www.lufft.com/ (menu header: SUPPORT / FAQs). G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Check that the tipping bucket is free to move; if necessary pull the cable back to the appropriate length Put funnel back in place and lock it by turning it to the right Figure 35: Connection of the Leaf Wetness Sensor G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 63
Threshold Note: We recommend to check the threshold during maintenance and to adjust it if necessary. For the dry leaf measurement the sensor should be cleaned with clear water and carefully dried. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
UMB Config Tool. Figure 37: Setting type of external sensor If the data from the channels of the sensor type currently not selected are requested, the device will respond with “invalid channel”. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 65
The WS601/401-UMB’s advices for installation (Chap.7.3.4) and maintenance (Chap.12.1) are as well valid for the external rain gauge. Example with WS501-UMB and WTB100 without reduction ring: Figure 38: Example WS501-UMB and WTB100 G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
359.9 ° wind direction fast 359.9 ° wind direction corr. 359,9 ° wind direction standard deviation 359.0 ° wind value quality 100.0 wind value quality (fast) 100.0 Compass compass heading ° G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 67
1 = wet Service Channels 10000 Supply Voltage V 50.0 11000 Rain Drop Volume µl 500.0 µl Note: The channels which are actually available are dependent on the WSxxx-UMB type in use. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Note: The channels which are actually available are dependent on the WSxxx-UMB type in use. The previous channels 1153 and 1253 are no longer supported. Channels 840 and 860 can be used in their place. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Only one example of an online data request is described in this operating manual. Please refer to the current version of the UMB Protocol for all commands and the exact mode of operation of the protocol (available for download at www.lufft.com). Note: Communication with the sensor takes place in accordance with the master-slave principle, i.e.
Page 70
The correct data transmission can be checked with the aid of the check sum (22C6h). Note: Little Endian (Intel, low byte first) applies when transmitting word and float variables of addresses or the CRC, for example. This means first the LowByte and then the HighByte. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 71
Command Data Request (0x23), Channel 100 No response Wait 1 sec Command Data Request (0x23), Channel 100 Discard data Wait 2 sec CommandMultiData Request (0x2F), Ch. 100, 200, 300, 620, 605, 700 Store data G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
This channel outputs a temperature from –50 to +60°C, which is calculated as follows: corresponds to -50°C 65520d corresponds to +60°C corresponds to [+60°C – (-50°C)] / 65520 * 34785 +(-50°C) = 8.4°C 36789d Note: TLS channels are not available in ASCII protocol. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 74
Value Underflow 65525d Error in measurement data or no valid data available 65526d Device / sensor is unable to execute valid measurement due to ambient conditions 65534d Invalid Calibration 65535d Unknown Error G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
An invalid terminal command is acknowledged with ‘FAILED’. Control commands are acknowledged with ‘OK’. The command to which the response relates is given at the beginning of each response. Note: No response times are specified in the terminal mode. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 76
Displays the same values as Ex<CR>, but without additional information such as the Mx<CR> measurement variable and unit I0<CR> Serial number; date of manufacture; project number; parts list version; SPLAN version; hardware version; firmware version; E2 version; device version I1<CR> Outputs the device description G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 77
Resets the accumulated rain quantity and executes a device reset X0<CR> Temporarily switches to UMB binary protocol Examples: E0<CR> E0;Ta+024.9C;Tp+012.2C;Tw+026.8C;Hr+045.0P;Pa+0980.6H; Sa+005.1M;Da+156.6D;Ra+00042.24M;Rt+060N;Ri+002.6M; M0<CR> M0;+024.9;+012.2;+026.8;+045.0;+0980.6; +005.1;+156.6;+00042.24;+060;+002.6; E2<CR> E2;Sa+005.1M;Sn+001.1M;Sx+007.1M;Sg+005.1M;Sv+005.0M; Da+156.6D;Dn+166.6D;Dx+176.6D;Dv+156.6D; M2<CR> M2;+005.1;+001.1;+007.1;+005.1;+005.0; +156.6;+166.6;+176.6;+156.6; I0<CR> I0;001;0109;0701;004;005;001;016;011;00002;<CR><LF> R0<CR> R0;OK;<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
UMB Config Tool. Figure 40: Sensor Configuration SDI-12 Units Metric units US units Note: Please observe drawings on next page and notes on page 26 when connecting a SDI12 data logger! G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 79
Figure. 42: Connecting to a logger and a separate power supply up to device version Figure. 43: Connecting to a logger and a separate power supply device version 42 and newer G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 80
Command verification: Evaluate sensor status and heating temperatures, data request with aD0!, aD1! aXU<m/u>! Change the unit system for SDI data aXH+nnnn! Set local altitude of the device for calculation of rel. air pressure G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 81
For the reduced data set in power saving mode 2 a unified data buffer structure for all device models has been defined. Depending on the individual model unused channels will be set to the “invalid” marker 999.9. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 82
Air temperature 13.5°C, rel. humidity 85.7%, rel. air pressure 1017hPa avg. wind speed 2.5m/s, max wind speed 3.7m/s. 0D1! 0+43.7+9.8+60+4.4<CR><LF> Wind direction 43.7° wet bulb temperature 9.8°C, type of precipitation 60 (rain), precipitation intensity 4.4mm/h G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 83
3,2m/s, min. wind speed 0.0 m/s vect. avg. wind speed 3.5m/s, quality of wind values 100% 0D4! 0+43.7+41.3+45.7+29.3<CR><LF> act. wind direction 43,7°, min. wind direction 41,3°, max. wind direction 45,7°, specific enthalpy29,3kJ/kg G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 84
° Wind Direction (max) 359.9 ° Specific Enthalpy (act) -100.0 1000.0 kJ/kg Example: Request Buffer ‘0’ 0D0! 0+13.5+85.7+2.5+3.7<CR><LF> Air Temperature 13.5°C, rel. Humidity 85.7%, average wind speed 2.5m/s, peak wind speed 3.7m/s G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 85
Wind Speed (min) 167.8 Wind Speed (vct) 167.8 Wind Quality 100.0 Buffer ‘4’ Wind Direction(act) 359.9 ° Wind Direction (min) 359.9 ° Wind Direction (max) 359.9 ° Specific Enthalpy (act) -100.0 1000.0 kJ/kg G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 86
° Wind Direction (max) 359.9 ° Specific Enthalpy (act) -100.0 1000.0 kJ/kg Example: Request Buffer ‘0’ 0D0! 0+13.5+85.7+2.5+3.7<CR><LF> Air Temperature 13.5°C, rel. Humidity 85.7%, average wind speed 2.5m/s, peak wind speed 3.7m/s G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 87
Wind Speed (min) 167.8 Wind Speed (vct) 167.8 Wind Quality 100.0 Buffer ‘3’ Wind Direction(act) 359.9 ° Wind Direction (min) 359.9 ° Wind Direction (max) 359.9 ° Specific Enthalpy (act) -100.0 1000.0 kJ/kg G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 88
Wet Bulb Temperature (act) -50.0 60.0 °C Specific Enthalpy (act) -100.0 1000.0 kJ/kg Example: Request Buffer ‘0’ 0D0! 0+13.5+85.7+11.2+1017.0+1001.0 Air temperature 13.5°C, rel. humidity 85.7%, dew point 11.2°C, rel. air pressure 1017.0hPa, abs. pressure 1001.0hPa G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 89
Rel. Humidity (avg) 100.0 Rel. Air Pressure(min) 300.0 1200.0 Rel. Rel. Humidity (max) 300.0 1200.0 Rel. Rel. Humidity (avg) 300.0 1200.0 Wet Bulb Temperature (act) -58.0 140.0 °F Specific Enthalpy -100.0 1000.0 kJ/kg G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 90
Wet Bulb Temperature (act) -50.0 60.0 °C Specific Enthalpy (act) -100.0 1000.0 kJ/kg Example: Request buffer ‘0’ 0D0! 0+13.5+85.7+11.2+1017.0+1001.0 Air temperature 13.5°C, rel. humidity 85.7%, dew point 11.2°C, rel. air pressure 1017.0hPa, abs. pressure 1001.0hPa G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 92
Wind Direction corr. (act) 359.9 ° Example: Request Buffer ‘0’ 0D0! 0+2.5+3.7+45.5+37.8+10.3<CR><LF> Avg. wind speed 2.5m/s, peak wind speed 3.7m/s, avg wind direction (vect.) 45.5°, wind direction (act.) 37.8°, compass heading 10.3° G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 93
Wind Speed (act) 167.8 Wind Speed (min) 167.8 Wind Speed (vct) 167.8 Wind Quality 100.0 Buffer ‘2’ Wind Direction (min) 359.9 ° Wind Direction (max) 359.9 ° Wind Direction corr. (act) 359.9 ° G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 94
*) Until device version .49 / .212 / Firmware v5.6: 1400.0 W/m Example: Request Buffer ‘0’ 0D0! 0+13.5+85.7+2.5+3.7<CR><LF> Air Temperature 13.5°C, rel. Humidity 85.7%, average wind speed 2.5m/s, peak wind speed 3.7m/s G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 95
Buffer ‘4’ Global Radiation (min) 2000.0 *) W/m² W/m² Global Radiation (max) 2000.0 *) W/m² Global Radiation (avg) 2000.0 *) *) Until device version .49 / .212 / Firmware v5.6: 1400.0 W/m G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 96
*) Until device version .49 / .212 / Firmware v5.6: 1400.0 W/m Example: Request buffer ‘0’ 0D0! 0+13.5+85.7+11.2+1017.0+780.0 Air temperature 13.5°C, rel. humidity 85.7%, dew point 11.2°C, rel. air pressure 1017.0hPa, global radiation 780.0W/m² G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 97
Buffer ‘4’ Global Radiation (min) 2000.0 *) W/m² W/m² Global Radiation (max) 2000.0 *) W/m² Global Radiation (avg) 2000.0 *) *) Until device version .49 / .212 / Firmware v5.6: 1400.0 W/m G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 98
° Wind Direction (max) 359.9 ° Specific Enthalpy (act) -100.0 1000.0 kJ/kg Example: Request Buffer ‘0’ 0D0! 0+13.5+85.7+2.5+3.7<CR><LF> Air Temperature 13.5°C, rel. Humidity 85.7%, average wind speed 2.5m/s, peak wind speed 3.7m/s G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 99
Wind Speed (vct) 167.8 Wet Bulb Temperature (act) -58.0 140.0 °F Buffer ‘4’ Wind Direction(act) 359.9 ° Wind Direction (min) 359.9 ° Wind Direction (max) 359.9 ° Specific Enthalpy (act) -100.0 1000.0 kJ/kg G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 100
Wet Bulb Temperature (act) -50.0 60.0 °C Specific Enthalpy (act) -100.0 1000.0 kJ/kg Example: Request Buffer ‘0’ 0D0! 0+13.5+85.7+11.2+1017.0+1001.0 Air temperature 13.5°C, rel. humidity 85.7%, dew point 11.2°C, rel. air pressure 1017.0hPa, abs. pressure 1001.0hPa G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 101
Rel. Humidity (avg) 100.0 Rel. Air Pressure(min) 300.0 1200.0 Rel. Rel. Humidity (max) 300.0 1200.0 Rel. Rel. Humidity (avg) 300.0 1200.0 Wet Bulb Temperature (act) -58.0 140.0 °F Specific Enthalpy -100.0 1000.0 kJ/kg G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 102
*) Until device version .49 / .212 / Firmware v5.6: 1400.0 W/m Example: Request Buffer ‘0’ 0D0! 0+13.5+85.7+0.2+1017.0+1.8 Air temperature 13.5°C, rel. humidity 85.7%, precipitation 0.2°C, rel. air pressure 1017.0hPa, wind speed1.8m/s G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 103
Wet Bulb Temperature (act) -58.0 140.0 °F Specific Enthalpy (act) -100.0 1000.0 kJ/kg Air Density 0.000 3.000 kg/m3 Compass (act) 359.0 ° *) Until device version .49 / .212 / Firmware v5.6: 1400.0 W/m G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 104
If the sensor type requested with the measurement command is not available with the actual variant of the Smart Weather Sensor (WS200-UMB ... WS700-UMB) the device will respond with a0000<CR><LF> resp. a00000<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 105
Dew Point (act) -58.0 140.0 °F Buffer ‘1’ Dew Point (min) -58.0 140.0 °F Dew Point (max) -58.0 140.0 °F Dew Point (avg) -58.0 140.0 °F Wet Bulb Temperature (act) -58.0 140.0 °F G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 106
Mixing Ratio (max) 1000.0 g/kg Mixing Ratio (avg) 1000.0 g/kg Example: Request with M command 0M2! 00009<CR><LF> 0D0! 0+48.5+48.2+48.8+48.5<CR><LF> 0D1! 0+5.7+5.5+5.9+5.7+29.3<CR><LF> Example: Request with C command 0C2! 000013<CR><LF> 0D0! 0+48.5+48.2+48.8+48.5<CR><LF> 0D1! 0+5.7+5.5+5.9+5.7+29.3<CR><LF> 0D2! 0+4.6+4.4+5.0+4.6<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 107
Rel. Air Pressure (max) 300.0 1200.0 Rel. Air Pressure (avg) 300.0 1200.0 Example: Request with M command 0M3! 00009<CR><LF> 0D0! 0+1001.0+1000.0+1002.0+1001.0+1.119<CR><LF> 0D1! 0+1017.0+1016.0+1018.0+1017.0<CR><LF> Example: Request with C command 0C3! 000009<CR><LF> 0D0! 0+1001.0+1000.0+1002.0+1001.0+1.119<CR><LF> 0D1! 0+1017.0+1016.0+1018.0+1017.0<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 108
Wind chill Temperature (act) -76.0 158.0 °F Wind Speed Standard Dev.* 167.8 Wind Direction Standard Dev.* 359.9 ° *) Note: Std.Dev. values will be available after the first request. See p. 11. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 109
Device configured for measurement values in metric or US units: Measurement Value Unit Channel Buffer ‘0’ Compass (act) 359.0 ° Example: Request with M command 0M5! 00001<CR><LF> 0D0! 0+348.0<CR><LF> Example: Request with C command 0C5! 000001<CR><LF> 0D0! 0+348.0<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 112
-40.0 80.0 °C Example: Request with M Command 0M8! 00001<CR><LF> 0D0! 0+13.5<CR><LF> Device configured for measurement values in US units: Measurement Value Unit Channel Buffer ‘0’ External Temperature (act) -40.0 176.0 °F G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 113
Channel Heating temp. Wind sensor +150 °C Heating temp. Precip. sensor +150 °C Buffer ‘1’, device configured for US units Heating temp. Wind sensor +302 °F Heating temp. Precip. sensor +302 °F G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 114
VALUE_OVERFLOW CHANNEL_OVERRANGE VALUE_UNDERFLOW CHANNEL_UNDERRANGE BUSY other sensor status Example (WS600-UMB, SDI-12 Address ‘0’, no error): 00005<CR><LF> 0D0! 0+0000+000000+00000<CR><LF> 0D1! 0+73.0+65.3<CR><LF> Example (WS600-UMB, SDI-12 Address ‘0’, compass failure): 00005<CR><LF> 0D0! 0+0000+000000+000030<CR><LF> 0D1! 0+73.0+65.3<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 115
The response to the attempt of setting of an invalid altitude (-100 < altitude < 5000) is aXHf<CR><LF> Example: The altitude of the installation location is 135m above sea level 0XH+135! 0XH+135<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 116
The response to the selection of an invalid option or of an invalid combination of mode and device model is aXLf<CR><LF> Example: The device shall be set to power saving mode 2 0XLw! 0XLw<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 117
The response to the attempt of setting of an invalid threshold (200.0<=threshold<=1200.0) is aXBf<CR><LF> Example: The leaf wetness voltage measured in dry condition is 613mV. The recommended setting of the threshold is 633mV 0XB+633.0! 0XD+633.0<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 118
19.6.18 Message: Device Reset The command initiates a device reset. Command: aXR! Response: aXRok<CR><LF> The response is followed by the device reset, i.e. the device will be offline for a few seconds. Example: 0XR! 0XRok<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
19.7.3.1 Function 0x03 Read Holding Registers The Holding Registers are used to make a selected set of adjustable parameters available for Modbus access. As for the measurement values the parameters are mapped to 16bit integers. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 120
0. Subsequently a device reset will be initiated. When writing the value 0x3247 (12871d) to register no. 9 (reg. addr. 8) a device reset will be initiated. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 121
Sensor Status 6 External temperature / external rain gauge, Coding 4 bit per status, see lightning sensor, lightning sensor buffer (see below table below) Reserve Diagnostic: run time in 10sec steps G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 122
Factor 1, s Wind Measurement Quality Factor 1, u Global Radiation (act.) Factor 10, s Global Radiation (min.) Factor 10, s Global Radiation (max.) Factor 10, s Global Radiation (avg.) Factor 10, s G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 123
Wind Speed fast m/s Factor 10, s Precipitation abs. mm Factor 100, u, limited to 655.34mm Precipitation diff. mm Factor 100, u, limited to 100.00mm Precipitation intens. mm/h Factor 100, u, limited to 200.00mm/h G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 124
Wind Speed fast mph Factor 10, s Precipitation abs. In Factor 1000, u, limited to 25.800 Precipitation diff. in Factor 10000, u, limited to 3.9370in Precipitation Intens. in/h Factor 10000, u, limited to 6.5534 in G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 125
Wet Bulb Temp. °F (act) Factor 10, s Specific Enthalpy (act) Factor 10, s Air Density (act) Factor 1000, s *) Note: Standard deviation values are available after the first request. Please see p. 11 G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 126
External Temperature °C (act) Factor 10, s External Temperature °F (act) Factor 10, s Wind Value Quality (fast) Factor 1, u Lightning Events (minute) Factor 1, u Lightning Events (Intervall) Factor 1, u Reserved G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 127
High Precipitation Compass High Global Radiation Buffer High Global Radiation Sensor Status 5 High Leaf Wetness Buffer Leaf Wetness High High External Temperature Sensor Status 6 High Lightning Sensor Buffer Lightning Sensor G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 128
= register AND 0x000F Following table shows the status coding: Coding of Sensor Status: Sensor State Code UNGLTG_KANAL E2_CAL_ERROR E2_CRC_KAL_ERR FLASH_CRC_ERR FLASH_WRITE_ERR FLASH_FLOAT_ERR MEAS_ERROR, MEAS_UNABLE INIT_ERROR VALUE_OVERFLOW CHANNEL_OVERRANGE VALUE_UNDERFLOW CHANNEL_UNDERRANGE BUSY Other Sensor State G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
(seconds) Output Interval NMEA Interval for automatic result message transmission NMEA talker device identifier Select the Talker ID part of the NMEA telegram header G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 130
Example: 0100EW*0100J3=1<CR><LF> 0100EW<CR><LF>*0100J3=1<CR><LF> are both valid command sequences for setting the pressure mode. Setting commands not requiring a preceding write enable are marked in the command description. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 131
*) The message header can be modified. The UMB config tool allows modifying the talker ID bytes. The XDR setting command NH allows changing the complete message header. The leading '$' is fixed and can not be modified. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 132
XDR sentence, which can be modified by the UMB config tool or the XDR setting command NH. The leading '$' is and the identifier MWD are fixed and can not be modified **) here wind direction “true” and wind direction “magnetic” are identical. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 133
% unit % separator identifier air pressure separator e.eeee air pressure in Bar unit Bar separator identifier precipitation difference separator ff.ff precipitation difference (related to last transmission) in mm unit mm separator G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 134
Operating Manual Smart Weather Sensor identifier precipitation type separator precipitation code (00 no precip., 60 rain, 70 snow) unit: Code <CR><LF> sentence terminator G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 135
The continuous mode is terminated by a Single Measurement Command (19.8.6.1, 19.8.6.3). 19.8.6.3 Single Measurement 0R0 Format Command identifier: Parameter: none Command example: Command *0100PB<CR><LF> Response: 0R0,Dm=<wind dir.>D,Sm=<wind speed>M,Ta=<air temp.>C,Ua=<rel. humidity>P,Pa=<air press.>B,Rc=<precip. diff.>M, Pt=<precip. type>N<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 136
The continuous mode will be stored in the E2PROM of the device, so that after a reset the device will continue to transmit automatically. The continuous mode is terminated by a Single Measurement Command (19.8.6.1, 19.8.6.3). G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 137
The command requests the current setting of the wind data average setting. Setting command example (to be preceded by the write enable command) Command: *0100JW=0<CR><LF> Response: *0001JW=0<CR><LF> The command sets the wind data average or spot transmission. G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 138
Setting command example (to be preceded by the write enable command): Command: *0100JS=82<CR><LF> or *0100JS=82.3<CR><LF> Response: *0001JS=82<CR><LF> Sets the elevation of the sensor above sea level in m (range -100m to 5000m) G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 139
ID. The command does not require to be preceded by the write enable command. Setting command example: Command: *9900ID<CR><LF> Response: *9901ID<CR><LF> Sets the unit ID to source ID + 1 G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Page 140
The command is not available as request command and does not generate a response. This command is valid with and without termination characters. Command example: *0100EW *0100EW<CR><LF> G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
Figure. 42: Connecting to a logger and a separate power supply up to device version 41 ..............79 Figure. 43: Connecting to a logger and a separate power supply device version 42 and newer ............79 Figure 44: Sensor Configuration XDR ..............................129 G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany...
