Page 1: Installation Guide
CS-S Series Surface Mount Loudspeakers CS-S4 4” SURFACE MOUNT LOUDSPEAKER CS-S6 6.5” SURFACE MOUNT LOUDSPEAKER Installation Guide CS-S Series Installation Guide V1.1... - Page 2 Euro block Baffle Bracket screws Bracket TAP SETTINGS CS-S6 CS-S4 100 V 70 V 25 V 100 V 70 V 25 V 16 ohm 16 ohm 2.5W 1.3W 0.6W 0.5W 2.5W 0.3W 0.3W 2.5W 1.3W 0.2W CS-S Series Installation Guide V1.1...
- Page 3 Port plug Step 6 Step 3 Locate euroblock in accessory bag and connect signal wire. Insert euroblock into rear of speaker. For daisy-chaining use “LINK” output to run to next speaker. CS-S Series Installation Guide V1.1...
- Page 4 Step 7 Step 8 Slide speaker into bracket and tighten bracket screws. Aim speaker and tighten bracket screws. www.cloud.co.uk www.cloudusa.pro CS-S Series Installation Guide V1.1...
