- Page 1 CS-C Series In-Ceiling Loudspeakers CS-C8 CS-CSUB8 8” IN-CEILING LOUDSPEAKER 8” IN-CEILING SUBWOOFER CS-C6 6.5” IN-CEILING LOUDSPEAKER CS-C5 5” IN-CEILING LOUDSPEAKER CS-C3 3” IN-CEILING LOUDSPEAKER Installation Guide CS-C Series Installation Guide V2.1...
- Page 2 Tap Switch Grille leash Clamp Screw (x4) Grille Leash Screw Grille TAP SETTINGS CS-CSUB8 CS-C8 CS-C6 CS-C5 CS-C3 100 V 70 V 25 V 100 V 70 V 25 V 100 V 70 V 25 V 100 V 70 V...
- Page 3 Mark and cut hole in ceiling or ceiling tile. speaker in hole. Tighten dog ears. Do not overtighten. Use included hole template. 271mm (10.67”) CS-C3 = 140mm (5.50”) Step 3 Step 6 Insert euroblock into rear of back can. Attach safety restraint Locate euroblock in accessory bag and connect signal wire.
- Page 4 Step 6.1 (CS-C3 only) Step 8 Insert euroblock into rear of back can. Attach safety restraint Check tap setting and replace grille. to side of back can. Close and secure cover plate. Step 7 (Drywall) Step 9 Insert speaker into ceiling opening and tighten dog ear clamps, Remove logo tab if desired.
