- Page 1 Hikvision Technical Manual DS-2CD8253F-EI(S) Network Camera Technical Manual ©2006 – 2011 by HIKVISION. All rights reserved.
- Page 2 It may not be reproduced in whole or in part, in any form, or by any means or be used for any other purpose without prior written consent of HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or...
- Page 3 Hikvision Technical Manual Contents 1. Key Features 2. Specifications 3. Dimension ©2006 – 2011 by HIKVISION. All rights reserved.
- Page 4 Hikvision Technical Manual 1. Key Features Up to 2 megapixel (1600 × 1200) resolution Standard H.264 video compression with high compression ratio Progressive scan CMOS, capture motion video without sawtooth Support ePTZ (electronic pan/tilt/zoom) Support dual streams, and the sub stream used for the mobile phone surveillance Up to 32GB SD/SDHC card local storage IR cut filter with auto switch PoE (Power over Ethernet) Auto iris, electronic shutter for different environment Weather Proof Rating: IP66 ©2006 – 2011 by HIKVISION. All rights reserved.
- Page 5 Dual Stream Yes Image Max. Image 1600 x 1200 Resolution 50 Hz: 12.5 fps (1600 × 1200), 12.5 fps (1600 × 912), 25 fps (1280 × 960), 25 fps (1280 × 720) Frame Rate 60 Hz: 15 fps (1600 × 1200), 15 fps (1600 × 912), 25 fps (1280 × 960), 30 fps (1280 × 720) Saturation, Brightness, Contrast adjustable through client software or Image Settings web browser Network Network Storage NAS (iSCSI optional) Motion detection, Network disconnect , IP address conflict, Storage Alarm Trigger exception TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, PPPoE, SMTP, NTP Protocols (SNMP, HTTPS, FTP, SIP, SRTP, 802.1x, IPv6 optional) Security Password protection, Watermark Interface Communication 1 RJ45 10 M/100 M Ethernet interface Interface Local Storage Built‐in SD/SDHC slot, up to 32 GB ©2006 – 2011 by HIKVISION. All rights reserved.
- Page 6 IR Range Approx 20 to 30 meters Dimension 98 × 88.58 × 328.79 mm (3.86” ×3.49” × 12.94”) Weight 1700 g (3.75 lbs) *DS‐2CD8253F‐E, DS‐2CD8253F‐ES is not equipped with infrared lights and doesn't have IR cut filter function. *”‐S” is equipped with audio interface, alarm interface and RS‐485 interface. Order Models DS‐2CD8253F‐E, DS‐2CD8253F‐ES DS‐2CD8253F‐EI, DS‐2CD8253F‐EIS 3. Dimension Unit: mm ©2006 – 2011 by HIKVISION. All rights reserved.
