3.5 Step 5: Inserting the filter cartridge (see fig. 7)
A Remove the protective cap (1) (see fig. 7).
B Insert the filter cartridge (4) vertically into the filter head (2).
2.
3.
5.
1.
4.
(fig. 7)
The filter cartridge can only be inserted when the locking
!
handle is open.
Make sure that the filter cartridge is positioned correctly.
C Turn the locking handle (3) until you feel it engages.
3.6 Step 6 (optional): Space-saving wall mount
to install the cartridge under the sink
(see fig. 8)
During assembly, note the installation dimensions, bending
!
radii of the hoses and dimensions of the accessories. The
system can be operated vertically and horizontally. When
using the wall mount, install vertically only!
1.
2.
3.
4.
(fig. 8)
A Attach the wall mount in place using the two matching screws
and use two wall plugs, if necessary, depending on the type of
wall.
B Engage the filter head (2) in the wall mount (1). Please use the
fixation holes (4).
