Summary of Contents for Monte Carlo Fan Company 5FNR60 Series
- Page 1 ’ WNER ANUAL Ceiling Fan Installation Instructions For 5FNR60XXD-L Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weight with light...
-
Page 2: Tools Required
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes ANSI/NFPA 70-1999), including fire-rated construction. - Page 3 Place yoke cover on downrod. (as Thread leadwires and safety cable Place downrod into fan yoke. shown) through downrod. (as shown) Align the hole in the downrod with the hole in the yoke. Insert the pin Tighten the 2 set screws on the yoke Install the keeper to pin.
- Page 4 white black Make wire connections to power source using wire nuts provided. Make sure that no filiments Make wiring connections as indicated above. are outside of the wirenut. After making the White from fan to white from remote marked N. Blue from fan to blue from remote marked wire connections, the wires should be spread light.
- Page 5 WALL MOUNT INSTALL HAND HELD INSTALL Attach the wall trim plate to the wall Place battery cover over battery compartment Install wall control unit to outlet box and buttons. Place hand remote cover over 2 control with the screws provided. using machine screws provided.
- Page 6 Remote Control Transmitter Features: FAN REVERSE (Press once to LED LIGHT change direction of the fan)Fanmust be MEDIUM SPEED running to reverse. HIGH SPEED LOW SPEED LIGHT ON/OFF SET- TING AND DIMMER FAN OFF SETTING (Press and hold to (Turns fan off only) dim light infinitively) FAN SPEED Depress “l dot”...
- Page 7 ROUBLE HOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
