Legacy AERIS Owner's Manual page 14

Speaker Connections
XP-4080 Processor Cable Connections
For use with standalone amplifiers
From
Left channel of preamp output
Right channel of preamp output
Processor Output 1
Processor Output 2
Processor Output 5
Processor Output 6
*The redundant feed of left and right input signals to the processor allows a low frequency correction algorithm to be ap-
plied. This compensates for the decrease in channel separation at longer wavelengths in listening rooms. This algorithm
may be defeated at any time by muting inputs 3,4 on the processor's front panel.
To
Processor Input 1 and Input 3*
Processor Input 2 and Input 4*
Left Aeris rear panel Bass Input (XLR)
Left channel input to amplifier driving Aeris upper range
Right Aeris rear panel Bass Input (XLR)
Right channel input to amplifier driving Aeris upper range
13
(use Y adapter)
(use Y adapter)
