VFF Vent Free Fireplace System
Installation & Operating Instructions
Models: VFF32LI, VFF36LI, VFF32LV, VFF36LV,
VFF32CI, VFF36CI, VFF32CV, VFF36CV
WARNING: If the information in this
manual is not followed exactly, a fi re or
explosion may result causing property
damage, personal injury or loss of life.
•
Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
•
WHAT TO DO IF YOU SMELL GAS
– Do not try to light any appliance.
– Do not touch any electrical switch; do
not use any phone in your building.
– Leave the buildling immediately.
– Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
– If you cannot reach your gas supplier,
call the fi re department.
•
Installation and service must be performed
by a qualifi ed installer, service agency or
the gas supplier.
This is an unvented gas-fi red heater. It uses air
(oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventil-
ation air must be provided. Refer to Page 8.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future
reference.
20308184 01.16 Rev. 2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vermont Castings VFF32LI
Summary of Contents for Vermont Castings VFF32LI
- Page 1 VFF Vent Free Fireplace System Installation & Operating Instructions Models: VFF32LI, VFF36LI, VFF32LV, VFF36LV, VFF32CI, VFF36CI, VFF32CV, VFF36CV WARNING: If the information in this manual is not followed exactly, a fi re or explosion may result causing property damage, personal injury or loss of life.
-
