- Page 3 Preface Notebook Computer M670SU/M675SU Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
- Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M670SU/ M675SU series notebook PC.
- Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
-
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 8: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. - Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...
-
Page 11: Table Of Contents
HDD & CDROM ................B-19 Removing the Keyboard ..............2-16 CARD READER ................B-20 Part Lists ..........A-1 NEW CARD SOCKET ..............B-21 LAN ....................B-22 Part List Illustration Location ............A-2 USB & CCD .................B-23 Top (M670SU) ................A-3 HITACHI H8 ................B-24 Top without Fingerprint (M670SU) ..........A-4... - Page 12 Preface CRT & LVDS ................B-25 CPU FAN, LPC ROM ..............B-26 MINI-PCI & BLUETOOTH ............B-27 AUDIO VT1708A/ALC883 ............B-28 LED ....................B-29 CHARGER, DC IN ..............B-30 1.05VS, 1.5V, 2.5VS ..............B-31 VCORE ..................B-32 1.8V, 0.9VS .................. B-33 VDD3, VDD5 ................
-
Page 13: Introduction
Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M670SU/M675SU series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer. -
Page 14: System Specifications
Introduction System Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/speeds and CD/DVD device types) may be changed, delayed or updated due to the manufacturer's release schedule. Check with your service center for details. - Page 15 Introduction Feature Specification Security Security (Kensington® Type) Lock Slot BIOS Password BIOS One 4Mb Flash ROM Phoenix™ BIOS 17.0" WXGA (1440 * 900) TFT LCD 17.1" WSXGA+ (1680 * 1050) TFT LCD 17.1" WUXGA (1920 * 1200) TFT LCD Video Adapter NVIDIA GeForce Go 7300 (G72M-V) Discrete Video System (External On Board) TurboCache™...
- Page 16 Introduction Feature Specification Communication AZALIA 56K Plug & Play Fax/Modem V.90/92 Compliant 10M/100Mb Base-T Ethernet LAN 802.11 b/g USB Wireless LAN Module (Option) Bluetooth 2.0 + EDR (Enhanced Data Rate) Module (Factory Option) 300K or 1.3M Pixel USB PC Camera Module (Factory Option) Power Supports ACPI 2.0 and PCI Bus Power Management 1.1 Battery Low Suspend...
-
Page 17: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Optional Built-In PC Camera 2. LCD 3. Speakers 4. Power Button 5. Hot Key Buttons 6. Keyboard 7. TouchPad and Buttons 8. Built-In Microphone 9. LED Indicators 10. -
Page 18: External Locator - Front & Rear Views
Introduction External Locator - Front & Rear Views Figure 2 Front Views 1. LED Indicators Figure 3 Rear Views 1. 1 * USB Port 2. DC-In Jack 3. Battery 1 - 6 External Locator - Front & Rear Views... -
Page 19: External Locator - Left & Right Side Views
Introduction External Locator - Left & Right Side Views Figure 4 Left Side View 1. Security Lock Slot 2. Optical Device Drive Bay 3. RJ-11 Modem Jack 4. S/PDIF-Out Jack 5. Microphone-In Jack 6. Headphone-Out Jack 7. Line-In Jack Figure 5 Right Side View 1. -
Page 20: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent/Fan Intake 2. Battery 3. Hard Disk Bay Cover 4. CPU/RAM Bay Cover Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use. -
Page 21: Mainboard Overview - Top (Key Parts)
Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Audio Codec VT1613 2. Audio Amp 3. Hitachi H8 4. Card Reader Control 5. ExpressCard Assembly Mainboard Overview - Top (Key Parts) 1 - 9... -
Page 22: Mainboard Overview - Bottom (Key Parts)
Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Memory Slots DDRII So-DIMM 3. Northbridge- VN896 4. ICS Clock Generator 5. Southbridge- VT8237A 6. Flash BIOS ROM 1 - 10 Mainboard Overview - Bottom (Key Parts) -
Page 23: Mainboard Overview - Top (Connectors)
Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. External Monitor Port 2. RJ-45 LAN Jack 3. USB Port 4. HDD Connector 5. Hotkey Cable Connector 6. Power Hotkey Cable Connector 7. Touch Pad Cable Connector 8. Keyboard Cable Connector 9. -
Page 24: Mainboard Overview - Bottom (Connectors)
Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. DC-In Jack 2. Fan Cable Connector 3. LCD Cable Connector 4. Batterry Connector 5. Optical Device Drive Connector 6. Bluetooth Cable Connector 7. Card Reader 1 - 12 Mainboard Overview - Bottom (Connectors) -
Page 25: Disassembly
Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M670SU/M675SU series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. -
Page 26: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 27: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 28: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Bluetooth: 1. Remove the battery page 2 - 5 1. -
Page 29: Removing The Battery
Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Slide the latches ( & ) the direction of the arrow, and hold latch in place. Battery Removal 3. Slide the battery in the direction of the arrow 4. -
Page 30: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk. - Page 31 Disassembly 4. Carefully grip the mylar tab and slide the hard disk in the direction of arrow. Figure 3 5. Lift the hard disk up Figure d in the direction of arrow. HDD Assembly 6. Remove the screws and separate the mylar cover from the hard disk Sequence Removal...
-
Page 32: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 4 The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting RAM Module Removal DDRII 533/667MHz. The main memory can be expanded up to 2GB. The SO-DIMM modules supported are 256MB, 512MB and 1024MB DDRII Modules. - Page 33 Disassembly 5. Gently push the two release latches ( & on the sides of the memory socket in the direction indicated by the Figure 5 arrows (Figure Memory Removal 6. The RAM module(s) will pop-up Figure d , and you can then remove it. Sequence c.
-
Page 34: Removing The Processor
Disassembly Removing the Processor Figure 6 Processor Removal 1. Turn off the computer, and remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - 2. The CPU heat sink will be visible at point on the mainboard. a. - Page 35 Disassembly 5. Turn the release latch towards the unlock symbol , to release the CPU (Figure 6. Carefully (it may be hot) lift the CPU up out of the socket (Figure 7. Reverse the process to install a new CPU. 8.
-
Page 36: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 8 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the module bay cover (page 2 - Module Removal 1. The Wireless LAN module will be visible at point on the mainboard. -
Page 37: Removing The Modem
Disassembly Removing the Modem Figure 9 Modem Removal 1. Turn off the computer, remove the battery (page 2 - 5), and remove the hard disk bay cover (page 2 - 2. The modem will be visible at point on the mainboard. a. -
Page 38: Removing The Bluetooth Module
Disassembly Removing the Bluetooth Module Figure 10 Bluetooth Removal 1. Turn off the computer, remove the battery (page 2 - 5) and remove the hard disk bay cover (page 2 - 2. The Bluetooth module will be visible at point on the mainboard. -
Page 39: Removing The Optical (Cd/Dvd) Device
Disassembly Removing the Optical (CD/DVD) Device Figure 11 Optical Device 1. Turn off the computer, remove the battery (page 2 - Removal 2. Locate the hard disk bay cover and remove screws ( 3. Remove the bay cover a. Remove the screws. 4. -
Page 40: Removing The Keyboard
Disassembly Removing the Keyboard Figure 12 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 2. Press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you a. -
Page 41: Part Lists
Part Lists Appendix A:Part Lists This appendix breaks down the M670SU/M675SU series notebook’s construction into a series of illustrations. The com- ponent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 42: Part List Illustration Location
Part Pages# Location page A - 3 Top - (M670SU) page A - 4 Top without Fingerprint - (M670SU) Top - (M675SU) page A - 5 page A - 6 Top without Fingerprint - (M675SU) page A - 7 Bottom - (M670SU/M675SU) -
Page 43: Top (M670Su
Part Lists Top (M670SU) Figure A - 1 Top (M670SU) 印刷)(變更尺寸/公差) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 無鉛 無鉛 無鉛 無鉛 Top (M670SU) A - 3... -
Page 44: Top Without Fingerprint (M670Su
Part Lists Top without Fingerprint (M670SU) Figure A - 2 Top without Fingerprint (M670SU) 印刷)(變更尺寸/公差) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 無鉛 無鉛 無鉛 A - 4 Top without Fingerprint (M670SU) -
Page 45: Top (M675Su
Part Lists Top (M675SU) Figure A - 3 Top (M675SU) 印刷 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 無鉛 無鉛 無鉛 無鉛 Top (M675SU) A - 5... -
Page 46: Top Without Fingerprint (M675Su
Part Lists Top without Fingerprint (M675SU) Figure A - 4 Top without Fingerprint (M675SU) 印刷 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 無鉛 無鉛 無鉛 A - 6 Top without Fingerprint (M675SU) -
Page 47: Bottom (M670Su/M675Su
無鉛 無鉛 無鉛 無鉛 無鉛 藍天2 互億 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 孔心距 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 外 無鉛 外 無鉛 無鉛 無鉛 無鉛 (咬花處理) 無鉛 (黑色)(無鉛) Bottom (M670SU/M675SU) A - 7... -
Page 48: Lcd (M670Su/M675Su
無鉛 無鉛 無鉛 無鉛 無鉛 頭徑3.5MM 頭厚0.8MM 1號穴 鍍白鎳 I頭 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 無鉛 精乘 無鉛 無鉛 無鉛 精乘 M670SU 無鉛 無鉛 無鉛 無鉛 無鉛 銘版 無鉛 無鉛 A - 8 LCD (M670SU/M675SU) -
Page 49: Combo (M670Su/M675Su
Part Lists Combo (M670SU/M675SU) Figure A - 7 Combo (M670SU/ M675SU) 無鉛 無鉛 無鉛 無鉛 (咬花處理) 無鉛 Combo (M670SU/M675SU) A - 9... -
Page 50: Dual Dvdrw (M670Su/M675Su
Part Lists Dual DVDRW (M670SU/M675SU) Figure A - 8 Dual DVDRW (M670SU/M675SU) 無鉛 無鉛 無鉛 (咬花處理) 無鉛 A - 10 Dual DVDRW (M670SU/M675SU) - Page 51 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the M670SU/M675SU notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table B - 1 Diagram - Page Diagram - Page Diagram - Page Schematic...
-
Page 52: Schematic Diagrams
Schematic Diagrams SYSTEM BLOCK DIAGRAM M670SU BLOCK DIAGRAM PWR_HOT BOARD USB BOARD Yonah 478 IMVP-6 VR CLOCK GEN uFCPGA ICS953009AF+ICS9P936AF AUDIO&MODEM BOARD FSB667 CLICK BOARD VGA G72M-V DDR2 Sheet 1 of 41 SO-DIMM VRAM NORTH BRIDGE SYSTEM BLOCK VN896 FINGERPRINTER B'd... -
Page 53: Clock Generator
Schematic Diagrams CLOCK GENERATOR D 21 *RB751V -PC I_STOP PM_STPPC I# 3.3VS 3. 3VC LK FB22 3.3VCLK 3V66_0 R 577 22_04 D 20 *RB751V VC LK_SB 17 VD D A 3V66_0 H C B2012KF-121T30_08 R 576 22_04 Z0222 -C PU _STOP PM_STPC PU# VD D R EF **FS4/3V66_1... -
Page 54: Cpu-1
Schematic Diagrams CPU-1 H_A#[31:3] H_A#[31:3] BGA1A H_A#3 Please testpoint on H_ADS# 5 A[3]# ADS# H_A#4 H_IERR# with a GND H_BNR# 5 A[4]# BNR# H_A#5 0.1" away H_BPRI# 5 A[5]# BPRI# H_A#6 A[6]# H_A#7 H_DEFER# 5 A[7]# DEFER# H_A#8 A[8]# DRDY# H_DRDY# 5 H_A#9 BGA1B... -
Page 55: Cpu-2
Schematic Diagrams CPU-2 VCORE BGA1D VCORE VCORE VSS[001] VSS[082] VSS[002] VSS[083] BGA1C VSS[003] VSS[084] AB20 C180 C624 VCC[001] VCC[068] VSS[004] VSS[085] C594 VCC[002] VCC[069] VSS[005] VSS[086] VCC[003] VCC[070] VSS[006] VSS[087] *10U_10V_12 *10U_10V_08 VCC[004] VCC[071] VSS[007] VSS[088] AC12 *10U_10V_08 VCC[005] VCC[072] VSS[008] VSS[089] AC13... -
Page 56: Vn896-1
Schematic Diagrams VN896-1 1.05VS H_D#[63:0] H_D#[63:0] 3 H_A#[31:3] BGA5A H_A#[31:3] H_D#0 HD00# H_A#3 H_D#1 HA03# HD01# H_A#4 H_D#2 HA04# HD02# H_A#5 H_D#3 HA05# HD03# H_A#6 H_D#4 HA06# HD04# H_A#7 H_D#5 HA07# HD05# H_A#8 H_D#6 HA08# HD06# H_A#9 H_D#7 HA09# HD07# H_A#10 H_D#8 HA10#... -
Page 57: Vn896-2
Schematic Diagrams VN896-2 1.8V 1.8V C259 C295 C255 C262 C267 C266 C174 C175 C282 C200 C234 C205 .1U_50V_06 .1U_50V_06 .1U_50V_06 .1U_50V_06 .1U_50V_06 .1U_50V_06 .1U_50V_06 .1U_50V_06 .1U_50V_06 .1U_50V_06 .1U_50V_06 .1U_50V_06 MD_[63:0] 9,10 MD_[63:0] BGA5B MD_0 AF35 MD00 MD_1 AG34 MD01 MD_2 AJ36 AR28 M_BA0... -
Page 58: Vn896-3
Schematic Diagrams VN896-3 1.5VS 1.5VS C379 3.3VS 1.5VS R213 3.3VS 330U_6.3V_D C370 4.7U_10V_08 C359 4.7U_10V_08 1.4K_1%_06 C396 4.7U_10V_08 C358 4.7U_10V_08 C669 4.7U_10V_08 C356 4.7U_10V_08 LVREF_NB C413 4.7U_10V_08 C354 4.7U_10V_08 C676 4.7U_10V_08 C357 4.7U_10V_08 C402 4.7U_10V_08 C355 4.7U_10V_08 R214 C371 BGA5C C672 4.7U_10V_08 C216 4.7U_10V_08 VLAD[0..7]... -
Page 59: Vn896-4
Schematic Diagrams VN896-4 1.05VS 3.3VS BGA5E 1.5VS AE14 VCC15 AE16 VCC15 Y 14 AE18 VCC15 Y 15 AE20 VCC15 Y 16 AE21 VCC15 DVP2D00 Y 17 AE22 DVP2D00 VCC15 DVP2D01 Y 18 AJ10 DVP2D01 VCC15 DVP2D02 Y 19 AJ11 DVP2D02 VCC15 VD08 DVP2D03... -
Page 60: Ddr2-1
Schematic Diagrams DDR2-1 MAA[0:13] JDIMM1A MD_[0:63] 6,10 MAA[0:13] MD_[0:63] 6,10 MAA0 MD_0 1.8V MAA1 MD_1 MAA2 MD_2 MAA3 MD_3 MAA4 MD_4 MAA5 MD_5 1.8V MAA6 MD_6 MAA7 MD_7 JDIMM1B MAA8 MD_8 .1U_16V_04 .1U_16V_04 .1U_16V_04 VDD1 VSS16 MAA9 MD_9 VDD2 VSS17 MAA10 MD_10 A10/AP... -
Page 61: Ddr2-2
Schematic Diagrams DDR2-2 MAA[0:13] MD_[0:63] JDIMM2A MAA[0:13] MD_[0:63] 6,9 MAA0 MD_0 MAA1 MD_1 0.9VS MAA2 MD_2 MAA3 MD_3 MAA4 MD_4 *150U_4V_B MAA5 MD_5 MAA6 MD_6 150U_4V_B MAA7 MD_7 MAA8 MD_8 MAA6 47_8P4R_04 .1U_16V_04 MAA9 MD_9 MAA7 MAA10 MD_10 1.8V MAA11 .1U_16V_04 A10/AP DQ10... -
Page 62: Vga G72M-1
Schematic Diagrams VGA G72M-1 MAA[0:13] MD_[0:63] JDIMM2A MAA[0:13] MD_[0:63] 6,9 MAA0 MD_0 MAA1 MD_1 0.9VS MAA2 MD_2 MAA3 MD_3 MAA4 MD_4 *150U_4V_B MAA5 MD_5 MAA6 MD_6 150U_4V_B MAA7 MD_7 MAA8 MD_8 MAA6 47_8P4R_04 .1U_16V_04 MAA9 MD_9 MAA7 MAA10 MD_10 1.8V MAA11 .1U_16V_04 A10/AP... -
Page 63: Vga G72M-2
Schematic Diagrams VGA G72M-2 BGA4H PBGA533-08MM COMMON 1. 8VS for NB8M 5/12 IFP_AB C223 .01U_16V_04 Z1201 LVDS-L0N IFP_AB_VPROBE IFP_A_TXD0 LVDS-L0N 24 M660SE ALL DEL L406 LVDS-L0P IFP_A_TXD0 LVDS-L0P 24 HCB1608KF-121T25_06 BGA4J 2. 5VS LVDS-L1N VGA_3.3VS IFP_A_TXD1 PBGA533-08MM LVDS-L1N 24 LVDS-L1P COMMON for G72MV IFP_A_TXD1... -
Page 64: Vga G72M-3
Schematic Diagrams VGA G72M-3 M660SE ALL DEL BG A 4B PBGA533 -08M M COMM ON 1.8VS 2/12 FRAME_ BUFFER FBAD[0..63] FBAD0 FB_ DQ 0 FBAD[0..63] FBAD1 FB_ DQ 1 FB _V TT FBAD2 FB_ DQ 2 FB _V TT FBAD3 FB_ DQ 3 FB _V TT FBAD4... -
Page 65: Vga G72M-4
Schematic Diagrams VGA G72M-4 FBAD39 DQ31 | DQ23 VDDQ FBAD3 FBAD38 DQ31 | DQ23 VDDQ DQ30 | DQ22 VDDQ#A12 FBAD2 FBAD33 DQ30 | DQ22 VDDQ#A12 DQ29 | DQ21 VDDQ#C1 FBAD1 FBAD32 DQ29 | DQ21 VDDQ#C1 DQ28 | DQ20 VDDQ#C4 FBAD4 FBAD34 DQ28 | DQ20 VDDQ#C4... -
Page 66: Vt8237A-1
Schematic Diagrams VT8237A-1 3VUSB 3.3V 3.3VS 3.3VS 3VUSB FB20 PCI_FRAME# R594 8.2K_06 19,26 PCI_FRAME# PCI_AD[31:0] HCB3216KF-800T30_12 PCI_IRDY# R617 8.2K_06 19,26 PCI_AD[31:0] 19,26 PCI_IRDY # C438 C423 C693 C430 C420 C694 C417 C459 PCI_TRDY # R593 8.2K_06 19,26 PCI_TRDY# PCI_STOP# R370 8.2K_06 19,26 PCI_STOP#... -
Page 67: Vt8237A-2
Schematic Diagrams VT8237A-2 VT8237R plus => 4.7K VT8237A => 6.12K AP339A 2.5VS 3.3V 2.5V 2.5VS SREXT R308 6.19K_1%_06 2.5VSATA FB14 HCB3216KF-800T30_12 IDE_PDD[0..15] C447 C440 IDE_PDD[0..15] .1U_50V_06 BGA6B .1U_50V_06 PEXMESCI# IDE_PDD0 AA22 R361 *0_04 PDD00 IDE_PDD1 GPI04 R360 0_04 2.5VS SCI# 23 PDD01 IDE_PDD2 AA26... -
Page 68: Vt8237A-3
Schematic Diagrams VT8237A-3 2.5VS 2.5V 2.5VS 3.3V 2.5VS 2.5V 3.3V C475 C448 C374 C377 C445 C439 C469 C481 VLAD[0..7] VLAD[0..7] 1U_10V_06 4.7U_10V_08 .1U_50V_06 4.7U_10V_08 .1U_50V_06 BGA6C .1U_50V_06 1U_10V_06 1U_10V_06 VLAD0 VAD00 VLAD1 VAD01 MCRS CRS 21 VLAD2 VAD02 MCOL COL 21 VLAD3 VAD03 VLAD4... -
Page 69: Hdd & Cdrom
Schematic Diagrams HDD & CDROM CD-ROM IDE_PDD[15:0] IDE_PDD[15:0] CD_L J_ODD1 SATA HDD CD_G CD_R IDERST# R445 33_04 CD_RESET# IDE_PDD8 IDERST# IDE_PDD7 IDE_PDD9 J_HDD1 IDE_PDD6 IDE_PDD10 IDE_PDD5 IDE_PDD11 SATATXP0 IDE_PDD4 IDE_PDD12 SATATXP0 16 SATATXN0 IDE_PDD3 IDE_PDD13 SATATXN0 16 IDE_PDD2 IDE_PDD14 Sheet 18 of 41 Z1801 C471 .01U_50V_04 SATARXN0... -
Page 70: Card Reader
Schematic Diagrams CARD READER CLOSE TO CARD SOCKET VCC_CARD MS_CLK R344 47K_04 3.3VS SD_CD# SD_CD# 20 SD_WP SD_WP 20 RN13 47K_8P4R_06 3.3VS MS_CLK SD_D3 MS_CLK 20 SD_D2 MS_D3 20 MS_D2 20 MS_D0 20 R608 0_06 PCM_RST# PCIRSTC# MS_D1 20 SD_D1 RN14 47K_8P4R_06 VCC_CARD... -
Page 71: New Card Socket
Schematic Diagrams NEW CARD SOCKET 3 IN 1 SOCKET SD/MMC/MS(Pro) TPM 1.2 J_CR1 SD _CD# U 38 SD _CD# 19 CD_SD SD _D2 SD _D2 19 17,23,25 LPC_AD0 3.3VS DAT2_SD LAD0 VDD1 SD _D3 CD/DAT3_SD SD _D3 19 17,23,25 LPC_AD1 LAD1 VDD2 SD _CMD... -
Page 72: Lan
Schematic Diagrams For VIA platform 3.3V 3.3VLANPH 3.3VLANPH HCB2012KF-121T30_08 CRS# R257 33_04 CRS 17 C382 COL# R256 33_04 COL 17 3.3V TXD3 TXD3 17 .1U_10V_04 TXD2 Sheet 21 of 41 TXD2 17 C384 C365 C315 C372 C394 C378 C395 Z2108 .1U_10V_04 .1U_10V_04 .1U_10V_04... -
Page 73: Usb & Ccd
Schematic Diagrams USB & CCD USB PORT 60 mil R122 68K_04 HCB2012K-500T40_08 USBVCC EMI solution,when placement OC0# near to USB Port? OC0# 5VS_CCD R132 82K_04 *HCB2012K-500T40_08 48 mil Z2207 HCB3216K-800T30_12 J_USB1 Z2201 C960403 VIA ? ? AO3409 J_CCD1 60 mil Z2202 330K_1%_04 88266-05001... -
Page 74: Hitachi H8
Schematic Diagrams HITACHI H8 J_KB2 3.3VS KB-SI0 KB-SI1 JHOTKEY 2 3. 3VS KBC_VDD KB-SI2 JH OTKEY 1 R247 KB-SI3 WEB2# KB-SI4 WEB0# 1K_06 KB-SI5 M_BTN# WEB1# M_BTN# R249 R255 KB-SI6 W EB3# Z2301 KB-SI7 W EB4# 10K_06 10K_06 W EB5# KB-SO0 H_A20GATE GA20... -
Page 75: Crt & Lvds
Schematic Diagrams CRT & LVDS PANEL INTERFACE NB (SE) *0_06 LA_DATAN0 VGA (SU) LVDSLN0 0_06 LVDS-L0N LVDS-L0N 12 *0_06 LA_DATAP0 LVDSLP0 0_06 LVDS-L0P J_LCD1 LVDS-L0P 12 3.3VS LVDSD ATA *0_06 LA_DATAN1 *0_06 3.3VS NB_RED 8 LVDS-U CLKN LVDSC LK LVDSLN1 0_06 LVDS-L1N 0_06... -
Page 76: Cpu Fan, Lpc Rom
Schematic Diagrams CPU FAN, LPC ROM FAN CONTROL VDD5 VDD5 40MIL 40MIL Sheet 25 of 41 3.3VS R762 R763 HCB2012K-500T40_08 *HCB2012K-500T40_08 CPU FAN, 0_04 *0_04 FW ROM 20mil C632 C633 LPC ROM Z2514 Z2503 .1U_10V_04 .1U_10V_04 10U_10V_08 PLT_RST# R503 100_04 Z2505 11,15,20,26 PLT_RST#... -
Page 77: Mini-Pci & Bluetooth
Schematic Diagrams MINI-PCI & BLUETOOTH MINI FFC CONN MINI-PCIE CARD PC I_AD [31:0] R1.6? ? C960339 15,19 PCI_AD [31:0] JMIN I1 PM_WAKE# PM_W AKE# W LAN3.3VS W AKE# 3. 3V_0 Z 2601 JD FFC 2 1.5VS BT_D ATA 1. 5V_0 Z 2602 Z2616 C648... -
Page 78: Audio Vt1708A/Alc883
Schematic Diagrams AUDIO VT1708A/ALC883 PLEASE PLACE CLOSE CODEC & 5VS_AU D Z2712 C739 270P_10V_06 AMP THE POWER INPUT PINS AUDG Z2713 C536 270P_10V_06 AUDG Z2714 C737 10U_10V_08 AUDG R714 0_06 C512 C502 C556 C731 C534 C538 C535 INT-MIC-VREF O EXT-MIC-VREFO 10U_10V_12 .1U_16V_04 .1U_16V_04... -
Page 79: Led
Schematic Diagrams GREEN GREEN Z2801 R434 200_1%_06 Z2804 Z2805 R436 200_1%_06 Z2808 SATA_LED# 3.3VS VDD5 VDD5 SATA_LED# Z2802 R433 200_1%_06 Z2806 R435 200_1%_06 R432 ORANGE ORANGE Z2809 4.7K_06 DLED Z2803 DLED Z2807 DTA114EUA CD_DASP# PD_LED# CD_DASP# LED_ACIN LED_PWR LED_BAT_CHG LED_BAT_FULL IMN10 DTC114EUA DTC114EUA... -
Page 80: Charger, Dc In
Schematic Diagrams CHARGER, DC IN PQ21 SI4835 4A 160mil PQ23 SI4835 PR119 15U_10*10*4 PR122 4A 160mil 3A 120mil Z2902 J USB1 .02_1%_25 .025_1%_25 FM1040-T1 PD 14 PR 10 PR111 Z2901 FM5822 10K_08 220K_1%_06 VDD3 OC2# LID _SW# ACIN PR106 Z2903 OC2# LID_SW# 23,24 USB1-... -
Page 81: 1.05Vs, 1.5V, 2.5Vs
Schematic Diagrams 1.05VS, 1.5V, 2.5VS PR91 0_06 Z3001 PR92 10_06 Z3010 PC93 1U_10V_06 VDD5 PR101 10K_04 PR103 10_06 Z3011 PC101 1U_10V_06 3.3V VCCP_PWRGD SGND1 SGND2 PC92 PC87 PC88 PC86 FM0540-N FM0540-N .1U_50V_06 10U_25V_12 10U_25V_12 *10U_25V_12 PC168 1000P_50V_04 PC91 PC85 PC84 PGOOD1 PGOOD2 PC98... -
Page 82: Vcore
Schematic Diagrams VCORE VCORE FOR YUNA AND NAPA CPU PR62 3.3VS 10_06 FM0540-N VCCA 3.3VS PC42 PR56 PR67 Z3104 1U_10V_06 PQ36 680_1%_06 PR54 PQ37 0_06 PC4 6 IRF7413ZPBF 1K_04 IRF7413ZPBF 1 U_1 0V_ 06 GND_SIGNAL CLKEN# PR63 0_06 Z3113 3.3VS VCORE PR71 .6U_13*13*4... -
Page 83: 1.8V, 0.9Vs
Schematic Diagrams 1.8V, 0.9VS 3.3V V1.8 PR59 PR61 PR65 1.5M_04 10_06 *100K_04 FM0540-N PR58 10_06 Z3201 Z3217 VDDQS PC32 PC56 PC37 PR60 Z3202 Sheet 32 of 41 100P_50V_04 2.2K_1%_06 1U_10V_06 1U_10V_06 Z3203 PR70 Z3216 Z3204 Z3210 PC144 PC143 PC145 1.8V, 0.9VS PR68 PC49 0_06... -
Page 84: Vdd3, Vdd5
Schematic Diagrams VDD3, VDD5 VIN2 Z3314 PR129 0_06 Z3302 PR120 10_04 VDD5 PR123 10_04 Z3319 PR 125 VIN1 VDD5 Z 3301 SY S5V VDD5 1M_04 PR86 PQ33 PD19 PQ14 Z3315 SI4800BDY F M5822 4.7U_7*7*3.5 PR144 NTGS4141NT1G 100K_04 PC131 .022U_25V_06 RUN _SS1 Z3316 PR84 Z3331... -
Page 85: Ext Gpu 1.0Vs/1.2Vs
Schematic Diagrams EXT GPU 1.0VS/1.2VS VI N PR 136 Z 3402 10_06 PC 148 PR 139 PD 22 1U _10V_06 PC60 PC54 PC 58 1.5M_04 FM0540-N SGN D 3 Z3403 PQ44 .1U _25V_06 10U_25V_12 10U _25V_12 PU 7 Z3404 IR F 7413ZPBF PR 140 1.0V_EN EN /PSV... -
Page 86: Pwr Hot Board
Schematic Diagrams PWR HOT BOARD FOR M670SU FOR M675SU PPSW1 PPSW2 PPSW11 PPSW22 PPWEB5# PPWEB4# PPWEB5# PPWEB4# HCH STS-05 HCH STS-05 *HCH STS-05 *HCH STS-05 P IN5 ,6 =PP GND PIN5,6=PPGND P IN5 ,6 =P PGND PIN5 ,6=PP GND PPGND... -
Page 87: Audio & Modem Board
Schematic Diagrams AUDIO & MODEM BOARD AJSPDIF1 Z3705 SPDIF OUT Z3706 CONN.? ? ? ? ? /Side Surronnd ASPD_IFO ASPDIF FCM1608K-121T06_06 AHMDCC1 AJMODEM1 HK2125 R10J-T_08 Z3701 Z3703 1000P_50V_06 AUDIO JACK AGND Z3702 Z3704 RING HK2125 R10J-T_08 AL10 AGND 85204-2 PIN GND1=AGND AJMIC1 AGND 680P_50V_06... -
Page 88: Click Board
Schematic Diagrams CLICK BOARD TTC_VDD TJ_FP2 TMISO/MODE3 TTC_VDD TMOSI TMUXOUT TMCS TAVDD TGRID0/SENSE 951127 TMCLK TTC_VDD TMCS TDVDD1 TMISO/MODE3 TMOSI TDATA2 47K_04 TGPIO1 TPD_REG .1U_16V_04 TDATA0 TNRESET TC24 TC25 TC26 TDATA1 47K_04 TDATA1 TDATA2 HOLD# TGPIO0/INT TESD_RING 1U_10V_06 1U_10V_06 1U_10V_06 TMCLK TXIN M95128WMN6TP... -
Page 89: Usb Board
Schematic Diagrams USB BOARD UJUSB2 UJAC1 UPF1 UVA+ UVA++ UPR2 0_12 Z3905 GND1 UPL1 GND2 UGND UGND UPC1 UPC2 UPC3 ACIN_CON U+5V PIN GND3~4 =UGND .1U_50V_08 .1U_50V_08 .1U_50V_08 U+5V U+VDD3 UGND *EMI_CHOKE UUSB_OC2# ULID_RSUM# Z3901 UUSB_PN1 UUSB_PP1 UPR1 0_12 U+VDD3 UGND CON20A U+VDD3... -
Page 90: Fingerprint Board
Schematic Diagrams FINGERPRINT BOARD FESD_RING EXT_RING2 FGRID0/SENSE CRIDO FGND RING FMUXOUT MUXOUT AVDD FAVDD FMCS FTC_VDD PAD_VDD1B Sheet 39 of 41 FMISO/MODE3 MISO FINGERPRINT DVDD FDVDD1 FGPIO1 BOARD GPIO1 FGND AGND FMUXOUT FAVDD FDATA0 FGRID0/SENSE DATA0 FTC_VDD FMCS FDVDD1 FDATA1 FMISO/MODE3 FMOSI DATA1... -
Page 91: Hdd Converter Board
Schematic Diagrams HDD CONVERTER BOARD TO SATA HDD FROM M/B DJ_HDD1 DJ_HDD2 DSATATXP0 DSATATXP0 DSATATXN0 DSATATXN0 4mil/6mil/4mil DSATARXN0 DSATARXN0 DSATARXP0 DSATARXP0 D3.3VS D3.3VS S5VS S5VS Z4001 Z4005 Z4002 Z4006 Sheet 40 of 41 Z4003 Z4007 Z4004 Z4008 HDD CONVERTER C166B7-122A4L SD-87703-002 P IN P IN... -
Page 92: Odd Converter Board
Schematic Diagrams ODD CONVERTER BOARD TO CD-ROM FROM M/B FJ_ODD1 FCD_L FCD_R FJ_ODD2 FCD_G FCD_L FCD_R FCD_RESET# FIDE_PDD8 FCD_G FCD_RESET# FIDE_PDD7 FIDE_PDD9 FIDE_PDD8 FIDE_PDD6 FIDE_PDD10 FIDE_PDD7 FIDE_PDD9 FIDE_PDD5 FIDE_PDD11 FIDE_PDD6 FIDE_PDD10 FIDE_PDD4 FIDE_PDD12 FIDE_PDD5 FIDE_PDD11 FIDE_PDD3 FIDE_PDD13 FIDE_PDD4 FIDE_PDD12 FIDE_PDD2 FIDE_PDD14 FIDE_PDD3 FIDE_PDD13... - Page 93 www.s-manuals.com...
