OPEN THE HOUSING PROCEDURE 1. Insert a screwdriver or similar tool in the points marked 2. Turn the screwdriver until the case walls begin to separate towards two side lugs , are free. 3. Grab the Signal Conditioner body, at the points marked ‚...
POWER SUPPLY RECOMMENDED WIRING The power supply must be connected to terminals 1 and 7. The characteristics of the power supply are shown on the side label. WARNING.- If the power supply is dc voltage, be careful with the polarity indicated for each terminal.
SIGNAL OUTPUT module MS The signal conditioner provides two different analog output signals, both proportional to the signal input. Output in Current: 4 to 20 mA, terminals 9 - 10 Output in Voltage: 0 to 10 Vdc, terminals 11 - 12 Do not use both outputs simultaneously.
SIGNAL INPUT, module ME OVERVIEW This module together with the "MP" input board, performs the signal conditioning (see Fig. 2). This module contains the trimmers and jumpers for the amplifier gain and the low level output (offset). The signal input connections are made at Terminals 3, 4, 5 and 6. FIG.7 OFFSET ADJUST Solder pad 1 if closed : Adjust the low range level of the output (Offset positive coarse).
CCT-80, ELECTRICAL FEATURES This signal conditioner provides connection to 4- or 6-wire strain-gages (load-cells), which provide a nominal of 2 mV/V or 3 mV/V output with 350 Section. The signal conditioner does not provides the bridge excitation voltage, therefore is necessary to use an external auxiliary power supply.
SIGNAL INPUT RANGE SELECTION The "MP" input board for this signal conditioner, does not have jumpers because it allows only one signal input (0 to 20 mV). To calibrate the signal conditioner, follow the adjustment and calibration procedure. The user can field adjust the tare using the trim- mer PT1, located on the "MP"...
6-WIRE BRIDGE POWER SUPPLY INPUT / ENTRADA The side label, shows the type and value of the OUTPUTS / SALIDAS power supply. 9 10 11 12 SIGNAL OUTPUT Current 4-WIRE BRIDGE POWER SUPPLY The side label, shows the type and value of the power supply.
MECHANICAL DIMENSIONS 36 mm (1.417") TECHNICAL DATA WEIGHT ....270 g. HOUSING BASE ... . Polycarbonate, RAL 7032, UL 94 V-1 light grey, IP-40 TERMINAL HOUSING, COVER AND BLIND PLUGS .
