Cleaning The Dust Bowl And Filter; Replacing The Filters - Black & Decker HFEJ415JWMF Instruction Manual

K
• While holding the dust bowl over a bin or
sink, pull out the filter (20) to empty the
contents as shown in Figure L.
L
• To replace the dust bowl, push it back onto
the appliance until it clicks firmly into place.
WARNING:
without the filters. Optimum dust collection
will only be achieved with clean filters.

Cleaning the Dust Bowl and Filter

• The dust bowl and filter can be washed in
warm soapy water.
• Make sure the filter and the dust bowl are dry
before re-fitting.
For a more thorough cleaning
• Remove the dust bowl and filter assembly
as described above.
• To separate the plastic filter (21) from the
cloth filter (22), twist the plastic filter in a
counterclockwise direction and lift it off of
the cloth filter as shown in Figure M.
• Shake or lightly brush any loose dust off
both filters.
M
20
Never use the appliance
22
21
• The dust bowls and filters can be washed
in warm soapy water. Allow to dry before
placing back into the vac.
• To replace the filters, slide the outer
plastic filter over the cloth filter.
• Align the wings of the plastic filter with
the slots in the cloth filter and twist in a
clockwise direction.
• Place filters back into the bowl pressing
firmly to ensure a secure fit.
• To replace dust bowl, place it back onto the
handle until it "clicks" firmly into position.
IMPORTANT: Maximum dust collection
will only be obtained with a clean filter and
an empty dust bowl. If dust begins to fall
back out of the product after it is switched
off, this indicates that the bowl is full and
requires emptying.
• Wash the filters regularly using warm,
soapy water and ensure that they are
completely dry before using again. The
cleaner the filter is, the better the product
will perform.
• It is very important that the filter is
correctly in position before use.
Scented filter
BEFORE FIRST USE - remove bag from
the scented pre-filter. Reassemble per
instructions above.
When the vacuum is turned on, the plastic
scented filter will emit an aroma to freshen
the air.
WARNING:
· Causes mild skin irritation
· Toxic to aquatic life
· Harmful to aquatic life with long lasting
effects.
· Dispose of contents/ containers to an
approved waste disposal plant.
NOTE: When the plastic scented filter
no longer lets off the aroma, it can be
an indication that the filter needs to be
replaced. See below for information on
replacement filters.

Replacing the filters

The filters should be replaced every 6 to 9
months and whenever worn or damaged.
Replacement filters are available from your
BLACK+DECKER dealer.
Catalog numbers:
• Scented plastic pre-filter: VSPF10
• Pleated filter: VPF20
* XX is a placeholder for the two-digit
number that indicates the plastic scented
filter's specific scent.
6
XX*
