Attaching extended reach tool

• Slide the nozzle (3) into the extended
reach tool (13) as shown in Figure F.
• To remove the floor extension tube,
depress the floor extension release button
(12) and pull the tube off of the vacuum.
F
• A flip-up brush (15) is built into the
extended reach tool (13) and can be
flipped upwards for use as shown in
Figure G.
G

Fitting the floor head

• Ensure the flip-up brush (15) is folded
back behind the extended reach tool (13).
• Slide the extended reach tool onto the
floor head (16) as shown in Figure H.
H

AUTOSENSE

(EXCLUDES HFEJ415JWMF22)
The appliance is fitted with a unique floor
sense feature. It will automatically switch
between low and high mode when you are
vacuuming between a hard floor and a thick
pile carpet.
• To operate the floor sense feature,
depress the power button (1) once. The
feature will automatically detect the
service that is being vacuumed.
NOTE: Once the power button is depressed
twice, the vacuum will only operate in
BOOST mode.
Removing and clearing the
beater bars
• Depress the beater bar release button
(18) as shown in Figure I.
I
• The beater bar (19) can now be removed.
The end pieces are removable, allowing
you to clear the brushes from any hair or
other debris that has accumulated during
use (Figure J).
J
19
Dry pick up
• For everyday spills of dry material.
• Do not fill the dust bowl (8) beyond the
end of the intake chute.

Optimizing the suction force

In order to keep the suction force optimised,
the filters must be cleared regularly during use.
EMPTYING AND CLEANING
THE PRODUCT
Removing the dust bowl and
filters - Figures K & L
WARNING:
and should be cleaned regularly.
• Press the dust bowl release button (9) as
shown in the insert of Figure K, then pull
the dust bowl (8) straight off as shown in
Figure K.
5
18
The filters are reusable
