Specifications

Transducer
Rated noise power [rms]
(1)
Nominal Impedance
Transformer Taps
Effective frequency range
(2)
Rated coverage
(3)
Directivity factor
Directivity index [dB]
Sensitivity
(4)
Maximum continuous SPL
(5)
Maximum peak SPL
(5)
Baffle material
Grille material
Cutout dimension
Net weight
Product dimensions (Diameter x Height)
Shipping weight
Shipping dimensions (H x W x D)
1 AES2‑1984 noise signal for 2 Hrs, 8Ω
2 Free‑field, ‑10 dB from on‑axis sensitivity
3 ‑6 dB from on‑axis, 500 Hz–5 kHz
4 Free‑field, on‑axis, 2.83V, 1 m
5 Calculated from rated noise voltage and sensitivity
AC-C4T-nb
100 mm [4 in.] weather treated paper cone
6 W
8Ω
70V: 6, 3, 1.5, 0.75 W
100V: 6, 3, 1.5 W
62 Hz – 18 kHz
140° conical
4
6
93 dB
101 dB
107 dB
ABS
Powder coated steel
Ø 178 mm [Ø 7 in]
1.2 kg [2.6 lb]
Ø 206 x 95 mm [Ø 8.11 x 3.75 in.]
5.9 kg [13.1 lb] (packs of 4)
254 x 324 x 476 mm [10 x 12.75 x 18.75 in] (packs of 4)
Mailing Address:
QSC, LLC
1675 MacArthur Boulevard
Costa Mesa, CA 92626‑1468 USA
Telephone Numbers:
Main Number: (714) 754‑6175
Sales & Marketing: (714) 957‑7100 or toll free (USA only) (800) 854‑4079
Customer Service: (714) 957‑7150 or toll free (USA only) (800) 772‑2834
Facsimile Numbers:
Sales & Marketing FAX: (714) 754‑6174
Customer Service FAX: (714) 754‑6173
World Wide Web:
www.qsc.com
E‑mail:
info@qsc.com
service@qsc.com
tech_support@qsc.com
AC-C8T-nb
200 mm [8 in.] weather treated paper cone
6 W
8Ω
70V: 6, 3, 1.5, 0.75 W
100V: 6, 3, 1.5 W
53 Hz – 20 kHz
130° conical
5.6
7.5
96 dB
104 dB
110 dB
ABS
Powder coated steel
Ø 254 mm [Ø 10 in]
1.5 kg [3.4 lb]
Ø 283 x 84 mm [Ø 11.14 x 3.3 in.]
7.8 kg [17.3 lb] (packs of 4)
343 x 324 x 635 mm [13.5 x 12.75 x 25 in] (packs of 4)
