OPERATOR'S MANUAL
MODEL
3185
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
Warning
: This unit is equipped with an internal combustion engine and should not be used on or
near any unimproved forest-covered, brush-covered or grass-covered land unless the engine's
exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). If a
spark arrester is used, it should be maintained in effective working order by the operator. In the State
of California the above is required by law (Section 4442 of the California Public Resources Code).
Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the
muffler is available through your nearest engine authorized service dealer or contact the service
department, P.O. Box 368022 Cleveland, Ohio 44136-9722.
MTD PRODUCTS INC. P.O. BOX 368022 CLEVELAND, OHIO 44136-9722
FORM NO. 770-0835A
(1/98)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cub Cadet 3185
Summary of Contents for Cub Cadet 3185
- Page 1 OPERATOR’S MANUAL MODEL 3185 IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY Warning : This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
-
Page 2: Table Of Contents
SECTION 1: TABLE OF CONTENTS PAGE IMPORTANT SAFE OPERATION PRACTICES......2 SAFETY LABELS FOUND ON YOUR UNIT......7 TABLE OF CONTENTS . - Page 3 • Clear the area of objects such as • Do not operate the machine while rocks, toys, wire, etc., which could be under the influence of alcohol or picked up and thrown by the blade. A drugs. small object have been •...
-
Page 4: Slope Operation
2. SLOPE OPERATION • Avoid starting or stopping on a slope. If tires lose traction, disengage the Slopes are a major factor related to blade(s) and proceed slowly straight loss of control and tip-over accidents down the slope. which can result in severe injury or DO NOT: death. - Page 5 • Remove when machine • Keep all nuts, bolts and screws tight unattended to prevent unauthorized to be sure the equipment is in safe operation. working condition. • Never tamper with safety devices. 4. SERVICE Check their proper operation • Use extreme care handling...
-
Page 6: Calling Service Information
• Use proper containers when draining • DO NOT pour oil or other fluids into fluids. Do not use food or beverage the ground, down a drain or into a containers that mislead stream, pond, lake or other body of someone into drinking from them. -
Page 7: Safety Labels Found On Your Unit
SECTION 5: SAFETY LABELS FOUND ON YOUR UNIT IGNITION WARNING • AVOID SERIOUS INJURY OR DEATH. • GO UP AND DOWN STARTING INSTRUCTIONS SLOPES, NOT ACROSS. BE FAMILIAR WITH • A V O I D S U D D E N CONTROLS BEFORE T U R N S . -
Page 8: Controls
SECTION 6: CONTROLS Figure 3 * Parking Brake Button Gas Fill Cap PTO Button Cup Holder Brake Pedal Hydraulic Lift Lever Reverse Pedal Steering Wheel Tilt Lock Forward Pedal Cruise Control Button Ignition / Light Switch Choke Lever Attachment Height Indicator Throttle Lever Transmission Release Lever Indicator Light Pod... -
Page 9: Steering Wheel
NOTE: Reverse Pedal References to LEFT and RIGHT indicate that side of the tractor when facing forward while seated in the drivers seat. Reference to FRONT indicates the grille end of the tractor; to REAR, the drawbar end. Steering Wheel Figure 6 The steering wheel is centered on the NOTE:... -
Page 10: Throttle Lever
Ignition / Light Switch Gas Fill Cap To prevent accidental starting and/or The gas fill cap is located on the fender battery discharge, remove the key from to the left of the seat. the ignition switch when the tractor is Cup Holder not in use. -
Page 11: Hour Meter
This indicator will illuminate when the engine oil pressure is low. If this indicator illuminates, stop the tractor immediately and check the engine oil level. If the oil level is within the operating range, and the light remains on, contact your Cub Cadet dealer. -
Page 12: Operation
The fuel fill point is located on the the tractor. Contact your authorized fender to the left of the seat. Unscrew Cub Cadet Dealer. The safety interlock the fuel cap and fill tank from an system prevents... -
Page 13: Driving The Tractor
• Place the PTO switch in the “OFF” • Slowly depress the forward control position. Move the throttle control pedal until the desired speed is lever to the “MID” position and allow achieved. the engine to idle for a short time •... -
Page 14: Stopping The Tractor
Opening Tool Box of Cub Cadet’s high quality mowing A convenient tool box and manual decks. The following information will pouch is located under the seat. To be helpful when using a Cub Cadet access this area, pivot seat mowing deck with your tractor. -
Page 15: Adjustments
WARNING: mower will tend to scalp the grass. To avoid Short grass invites weed growth and possible injury, do not allow yellows quickly in dry weather. anyone in the area opposite Mowing should be done with the engine the discharge chute while at full throttle. -
Page 16: Brake Adjustment
Steering Wheel Tilt Adjustment WARNING: Do not adjust the steering wheel when the Axle tractor is moving. Adjusting Hex Nut the steering wheel while the Jam Nut tractor is moving could cause Ball Joint the operator to lose control of the tractor. -
Page 17: Maintenance
.030” to .060”. an equal angle for left and right turns. • Check and adjust the left brake as If adjustment is necessary please necessary. contact your local Cub Cadet dealer. SECTION 9: MAINTENANCE Maintenance Chart Ÿ Ÿ Grease front wheel bearings Ÿ... -
Page 18: Lubrication Illustration
SECTION 10: LUBRICATION ILLUSTRATION Grease Gun (Multipurpose #2 Lithium) Engine Oil: See Figure 24 on page 28. Transmission Oil 10W40 Oil Can (High Quality Oil 30W) - Page 19 Accessing Engine • Open the hood by pulling up. Compartment • Flip quick release fasteners up and turn to align with slots in side panels. engine compartment • Swing the side panel out and away accessed by lifting the hood. If greater from the tractor access is required, the tractor is equipped...
-
Page 20: Battery Maintenance
Battery Removal cables. Removing the battery from the unit is recommended. The battery is located under the dash • All batteries discharge during panel. It can be accessed by lifting the storage. Keep the exterior of the hood and reaching between the fire battery clean, especially the top. -
Page 21: Tire Inflation
• Lift the hood to expose the back side cause short tire life. of the headlight assembly. Improperly inflated tires will also affect the level of the mower deck and quality • Pull both locking tabs away from light of cut. bulb and pull wire harness away. - Page 22 • Reconnect the fuel line and run the Check the oil level of the transmission engine until it starts to falter, then use case before each use to see that it is filled to the correct level. Before the choke to keep the engine running until all fuel in the carburetor has checking the transmission oil level, been exhausted.
- Page 23 WARNING: NOTE: The oil fill plug/ Do not reuse the transmission dipstick must be installed oil. Contaminated transmission oil can securely into the fill tube at all damage the hydro transmission. times when the engine is Please dispose of used oil at operating.
- Page 24 full length of each bearing until it Fuse emerges at the end, carrying with it the Fuses are installed to protect the worn lubricant and any dirt that may tractor’s electrical system from damage have entered the bearing. caused by excessive amperage. Miscellaneous working parts...
-
Page 25: Engine Information
SECTION 11: ENGINE INFORMATION BRIGGS & STRATTON CORP., FEDERAL (U.S. EPA) AND CALIFORNIA EMISSION CONTROL SYSTEMS WARRANTY Owner’s Defect Warranty Rights and Obligations) In the interest of the environment, Briggs & APPLICABLE CERTIFIED ENGINES Stratton engines that meet strict emission PURCHASED IN CALIFORNIA IN 1995 AND requirements are labeled, “This engine conforms to THEREAFTER,... -
Page 26: Checking Engine Oil Level
Miscellaneous Items Used in Above Systems for failures of Warranted Parts which are not original Briggs & Stratton parts or because of - Vacuum, temperature, position, time abuse, neglect or improper maintenance as sensitive valves and switches set forth in the Engine Warranty Policy. - Connectors and assemblies Briggs &... -
Page 27: Changing Engine Oil
around the oil level dipstick to prevent Refer to Figure 24 for information debris from entering the crankcase. regarding the proper type of oil to add to the crankcase. See Figure 23. Always keep the oil level between the “FULL” and the •... - Page 28 See (Figure 24), VISCOSITY CHART, • Unseat the plastic dust cap from the below for the proper type of oil. engine oil drain valve. To prevent loss of the cap, do not remove the Above +40° F SAE 30 cap’s retaining ring from the drain 0°...
- Page 29 To remove the spark plugs, always use WARNING: Operating the a spark plug wrench. Check the gap engine with loose or damaged after every 100 hours of operation. air cleaner components will Replace a defective plug with a new allow unfiltered air into the plug.
- Page 30 • Do not wash the paper element or • Reinstall the paper element, foam use pressurized air, as this will precleaner, cover plate and knob. damage the element. Replace a dirty, Reinstall the air cleaner cover and bent or damaged element. Handle reattach the cover.
-
Page 31: Trouble Shooting
SECTION 12: TROUBLE SHOOTING Possible Cause Possible Remedy Hard To Start No gasoline in fuel tank or carburetor Fill the tank with gasoline. Check the fuel line, carburetor and fuel filter. Fuel line or carburetor clogged Clean the fuel line and carburetor with a commercial carburetor cleaner. -
Page 32: Optional Equipment
However, later you may wish to obtain optional equipment or accessories. These items and other allied equipment can be purchased from, and installed by, your authorized Cub Cadet dealer. This tractor can be used for many different types of work, and because it is called on to operate under many different conditions, a variety or equipment is available to adapt it to the requirements of the user. -
Page 33: Specifications
Transmission ..........Hydrostatic Transmission Fluid......See you local Cub Cadet Dealer Transmission Fluid Capacity . -
Page 34: Quick Reference Parts
SECTION 15: QUICK REFERENCE PARTS Description Part Number Engine Oil 737-3029 (SAE 30) 737-3030A (10W30) 737-3049 (5W30) Foam Precleaner BS-271271 Paper Air Cleaner Cartridge BS-394018 Engine Oil Filter BS-492932 Spark Plug 759-3336 Transmission Oil See you local Cub Cadet dealer. Transmission Oil Filter 723-3014 Cutting Blades... -
Page 35: Slope Guage
SECTION 16: SLOPE GUAGE WARNING: Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). A riding mower could overturn and cause serious injury. If operating a walk- behind mower on such a slope, it is extremely difficult to maintain your footing and you could slip, resulting in serious injury. -
Page 36: Limited Warranty
This limited warranty for residential users, covers any defect in materials or workmanship in your Cub Cadet equipment for two years from the date of purchase for the first user purchaser. We will replace or repair any part or parts without charge through your authorized Cub Cadet dealer.
