Engine Coolant - Mitsubishi Carisma Owner's Manual

3. With the engine idling and the brake
pedal fully depressed, move the trans-
mission selector lever through all the
positions from the "P" (PARK) to "L"
(LOW) (with INVECS–II 4A/T), the "P"
(PARK) to "D" (DRIVE) (with INVECS–
II Sports Mode 4A/T), stopping mo-
mentarily at each position.
4. Move the selector lever to the "N"
(NEUTRAL) or "P" (PARK) position.
5. Remove the dipstick and wipe it with a
clean lint–free cloth.
6. Reinsert the dipstick as far as it goes.
7. Remove the dipstick and read the oil
level. The fluid level should always be
between the two marks on the dip-
stick.
8. Use only the following transmission
fluid to ensure optimum transmission
performance: "DIA QUEEN ATF SP
III".
WARNING
Do not spill the fluid onto a hot ex-
haust manifold during topping up or
inspection, or a fire may occur.
Petrol–powered vehicles

Engine coolant

A translucent coolant reserve tank is located
in the engine compartment. The coolant
level in this tank should be kept between the
two marks on the reserve tank when
measured while the engine is cold. The cool-
ing system is a closed system and normally
the loss of coolant should be very slight. A
noticeable drop in the coolant level could
indicate leakage. If this occurs, have the sys-
tem checked at an authorized MITSUBISHI
dealer as soon as possible.
If the level should drop below the "LOW"
level on the reserve tank, open the lid and
add coolant.
Also, if the reserve tank is completely empty,
remove the radiator cap and add coolant
until the level reaches the filler neck.
MAINTENANCE
Diesel–powered vehicles
N26A034a
NOTE
EM36ALY On diesel–powered vehicles, the radiator
has no filler port. Supply coolant from the filler
port in the reserve tank.
WARNING
Do not open the reserve tank lid or
radiator cap while the engine is hot.
The coolant system is under pressure
and any hot coolant escaping could
cause severe burns.
N26A160a
9–5
