ORYONE
banknote validator
Quick guide
Rev. 1.02
All possible measures are taken by
Alberici to maintain and improve
the quality of this product.
Unproper installation or incorrect
use of this unit can mar its
performances, as well as their
stability in time.
120
83
100
Support
plate for
mounting
panel
1
To remove the whole validator from the panel,
press upwards button 1 (from any of the 3
positions shown in figure above)
QUICK GUIDE ORYYONE CCTALK
216
191
-
ENG
PULSE
Technical Specs:
To open up the cash-box and take
banknotes out, slide button 3.
2
Press pushbutton 2 to remove
the cash-box from the validator.
3
Advertisement
Table of Contents
Related Manuals for Alberici ORYONE
Summary of Contents for Alberici ORYONE
- Page 1 Quick guide Rev. 1.02 All possible measures are taken by Technical Specs: Alberici to maintain and improve the quality of this product. Unproper installation or incorrect use of this unit can mar its performances, as well as their stability in time.
- Page 2 FIXING PLATE for PANEL (MAX THICKNESS = 7 MM): * Measures of the inlet The optional chrome-plated bezel ref. AA-0238 is cut-out available to smarten the surround of the notes inlet. Panel front view M4 Threaded studs Preset the cut-out for panel mount Take care to preset also the 3 + 1 studs for the lower fixing holes.
- Page 3 CONNECTOR PIN-OUT N° SW DIP-SWITCH FUNCTIONS SW 1 High selectivity – High security High acceptance – Low security SW 2 Anti-fraud, warning enabled: 5 attempts + temporary Anti-fraud, warning disabled inhibit (see ** in Table AF Modes below) (see * in Table AF Modes below) SW 3 SW 4 Set up of slot luminescence...
- Page 4 QUICK GUIDE ORYYONE CCTALK PULSE...
