- Page 1 BILLYONE UN1 note validator (ARM3) BILLYONE UN1 M.S. note validator (ARM3) Operator’s Manual Rev. 1.05 Operator’s Manual Pag. 1 MANUALE BILLYONE CCTALK...
- Page 2 NOTICE Every possible care has been taken in the preparation of this manual. Alberici S.p.A. reserve the right to change, without notice, in any way any portion of this manual. Pag. 2 MANUALE BILLYONE CCTALK...
-
Page 3: Table Of Contents
CONTENTS General.............................. 4 Package contents ..........................5 Product description ........................5 Mounting instructions ........................8 Messages ............................16 Maintenance ........................... 17 Calibration ............................18 Disposal of the Product ........................ 20 Terms of Guarantee ........................20 10. Customer Service .......................... 20 STORICO REVISIONI Revisione n°... -
Page 4: General
Dear Customer, we would like to thank you and congratulate for your choice. We trust that you will appreciate the quality and performance of our BILLYONE UN1 note validator. 1.1 Host machine design - The manufacturer takes all possible measures to ensure the quality of this unit. However, performance decay or circuit faults could occur at the end of the product’s life. -
Page 5: Package Contents
Package contents The package contains the following items: 1. BILLYONE UN1 note validator 2. Installation manual (this manual) This unit has been carefully packed, with special attention to protect it againt damages. However, if you find anything damaged or missing, please contact immediately your local distributor. - Page 6 Parts description A. Front-plate B. Notes inlet C. Removal button D. Sled button to pull top open E. Dip-switch row E. Accepted notes outlet F. 10p Connector H. USB Mini-B port Technical Specifications 62 – 82,5 mm larghezza / width - vers. $ M.S. = 67 mm Pag.
- Page 7 Dimensions Left side wiew Face view BillyOne UN1 - BillyOne UN1 Univ. M.S BillyOne UN1 $ M.S. View from top N.B.: All measures in mm Pag. 7 MANUALE BILLYONE CCTALK...
-
Page 8: Mounting Instructions
Mounting instructions General Installation Preferably indoors; always integrated into cabinets suited to the place of use. Positioning Positioning Level mounting on plate (protected against vibrations and shocks). Allow at least 50 cm free space on the device, in order to operate with ease when opening or removing it. - Page 9 Mechanical fitting 1. Mounting panel must be up to 7 mm thick. Cut out a window as shown in figure below, size 43mm (height) x 95mm (width). Even a simple rectangular cut-out of 43mm (height) x 105mm (width) will do. Door can be up to 7 mm thick...
- Page 10 Electrical connections and settings of the unit 4.3.1 Connection wiring Make use of quality components complying with the current draw values, as for example: Socket IDC socket Socket for flat cable Wire AWG24 (UL1061) Flat cable, pitch 1,27 mm - AWG28 (UL2651/UL20012) To connect the validator to the machine board: 1.
- Page 11 (interface protocol) and other useful features. The DS row is located on the left side of the validator. BEWARE! The functions that can be set by Dip-Switch in the BillyOne UN1 do not correspond to the ones in the previous BillyOne generation.
- Page 12 (*) The pulse length can be modified by the dedicated function available in the Alberici Upg programming software menu. Such programming software is available for download in our Website.
- Page 13 4.3.5 Enable/Disable programmed denominations All the notes of the programmed currency are factory enabled. The denominations are stocked in the validator memory. It is possible to disable/re-enable one (or more) denomination(s) by following the steps described below: - Disabling banknotes Move DS No.
- Page 14 Interface circuit The BILLYONE UN1 operates by default with 16 bit CRC Checksum. To convert 16 bit to simple checksum (8bit), please make use of the Alberici Update Software (available on https://www.alberici.it/eng/products/note-validators/without-stacker/billyone). Open the Options menu and set checksum as follows: 1) OPTIONS: choose and open ADVANCED OPTIONS: choose "Menu Tool: Enable all tools"...
- Page 15 4.3.8 Supported ccTalk headers (16-bit Cyclic Redundancy Check) (Cyclic Redundancy Check) Supported Specifications Supported Command Headers CcTalk supported commands list 1. Core Commands Header 192 - Request build code Header 244 - Request product code Header 245 - Request equipment category id Header 246 - Request manufacturer id Header 254 - Simple poll 2.
-
Page 16: Messages
Messages Error red and yellow flashes: The number of red flashes emitted from the front plate allows to check the possible reason for malfunction. N° of red flashes Description Validator is open Jammed banknote Fraud attempted Adjust optics Low power supply Check encoder+motor efficiency ROM error If ccTalk communication drops off, the validator face led will lit up solid yellow:... -
Page 17: Maintenance
Maintenance Manual cleaning The ability of acceptance may decrease due to the accumulation of dust and cellulose dust released by banknotes during transit, or because of residues or sprays, which may spread on the detecting sensors and on transmission parts. It is therefore recommended that you clean these parts monthly, as indicated below. 1. -
Page 18: Calibration
Calibration should be carried out when acceptance rate decreases substantially, and/or after thorough cleaning of the note validator and particularly of its optic sensors glasses. Full Calibration requires usage of the Alberici Calibration Card (AA-0245). A more basic calibration (Partial Calibration) can be carried out as well without such Card. - Page 19 Once positioned the Calibration Card, press OK button and wait until confirmation of process ended. Partial Calibration: If the ‘Enable advanced functionalities’ box has been ticked in the ‘Options/Advanced’, the program will ask to choose between High Sensibility (factory default) and Low Sensibility.
-
Page 20: Disposal Of The Product
- detailed report of the problem found and the circumstances in which it occurs. Before sending the product, please get in touch with your Dealer or with Alberici S.p.a. (+39 051 944300); very often, malfunctions can be fixed via a simple phone call, saving you costs and time. - Page 21 UN 1 MANUALE BILLYONE Pag. 21...
- Page 22 Pag. 22 MANUALE BILLYONE CCTALK...
- Page 23 aim of constantly improve the quality of the products. Pag. 23 MANUALE BILLYONE CCTALK...
- Page 24 Via Ca’ Bianca 421 Terme (BO) – ITALY Pag. 24 MANUALE BILLYONE CCTALK...
