3. WISP Mode Setup (IP Share)

3-1. Install the antenna & power adapter, and then connect the LAN cable with LAN port of

this equipment. Another side of cable line connects with network card of computer. Please

wait for reboot around 20 seconds.

3-2. Open the IE (or other browser) and type http://192.168.1.254 on URL to enter the setup

frame. If you can't enter to setup frame, please press Reset button around 10 seconds to

restore AP and try to enter again.

3-3. Select the Setup Wizard on the left side of setup frame and press Next>>

3-4. In Operation Mode, select Wireless ISP and press Next>>
