- Page 1 ARGtek ARG-1210 WLAN AP Router For 802.11b/g/n POWER KING-X Quick Installation Guide Ver. 08.11 ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
-
Page 2: Package Content
DC 12V Power Adapter Antenna PoE DC Injector Paper QIG Manual/QIG CD AP Router Connection Before installing the router, please connect your PC to the internet through your internet service provider. ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742... - Page 3 Connect the power adapter between the DC-Jack on the router and an electrical outlet. The router will start to work automatically. Turn on your PC(s) and the cable/ADSL modem. The front LED indicators ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
-
Page 4: Ap Router Configuration
PC is in the same subnet as the device, such as 192.168.1.X. It will take about 55 seconds to complete the boot up sequence after power on. ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742... - Page 5 You can use it to integrate the power and the Ethernet then connected with the RJ45 cable. With POE, you can bring the power and Ethernet together in one cable for long distance as far as the RJ45 cable can reach. Part II: Internal Web Management ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 6 AP and try to enter again. 1-3. Select the Setup Wizard on the left side of setup frame and press Next>> 1-4. In Operation Mode, select Gateway and press Next>> ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 7 1-6. In LAN Interface Setup, you may change the setting of IP address, DHCP and etc. Then press Next>> 1-7. In WAN Interface Setup, select PPPoE Client for your connection of WAN Access Type and press Next>> ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 8 1-8. In Wireless Basic Setting, select AP Mode and change your SSID name, then press Next>> 1-9. In Wireless Security, select your setup of wireless security (WEP, WPA) and press Finished to reboot, and wait for 20 seconds for reboot. ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 9 Note: You have to connect ADSL cable with WAN port on Gateway Mode 2. AP Mode Setup (IP Share) ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 10 AP and try to enter again. 2-3. Select the Setup Wizard on the left side of setup frame and press Next>> 2-4 . In Operation Mode, select Bridge and press Next>> ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 11 2-5. In Time Zone Setting, if you don’t need any change, please press Next>> 2-6. In LAN Interface Setup, you may change the setting of IP address, DHCP and etc. then press Next>> ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 12 2-7. In WAN Interface Setup, select DHCP Client for your connection of WAN Access Type and press Next>> 2-8. In Wireless Basic Setting, select AP for your Mode and change your SSID setup, then press Next>> ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 13 2-10. Select the TCP/IP Settings from left side of setup frame and choice LAN Interface. Then choosing Disable from DHCP and press Apply Changes to reboot around 20 seconds to complete the setup. ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 14 Note: Please connect cable line with LAN port when you use Bridge Mode to connect IP Share. ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 15 AP and try to enter again. 3-3. Select the Setup Wizard on the left side of setup frame and press Next>> 3-4. In Operation Mode, select Wireless ISP and press Next>> ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 16 3-5. In Time Zone Setting, if you don’t need any change, please press Next>> 3-6. In LAN Interface Setup, you may change the setting of IP address, DHCP and etc. then press Next>> ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 17 User Name & Password which presented by your ISOP. And then press Next>> Note: Connecting Telecom Access Point usually is based on PPPoE, but in general, a pure connection is via Static IP or DHCP Client. ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
- Page 18 3-9. In Wireless Security, select your setup of wireless security (WPA) and press Finished to reboot around 20 seconds, and wait for 20 seconds for reboot. Note: Please connect cable line with LAN port when you use WISP Mode. ARGtek Communication Inc. www.argtek.com E-Mail:sales@argtek.com Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742...
