BEFORE PLUGGING IN THE NI-CD BATTERY, YOU'LL NEED TO MAKE SURE THAT BOTH THE TRANSMITTER
AND THE RECEIvER ARE TURNED OFF. THIS WILL ENSURE THAT THE MOTOR DOESN'T TURN ON BY
ACCIDENT WHEN YOU PLUG IN THE NI-CD BATTERY.
IMPORTANT As a safety feature, the connectors can only be plugged in one way.
PRO TIP If you have difficulty sliding the antenna wire through the antenna support tube, first pull the antenna wire through your
fingers several times to straighten it out, then lightly wet the antenna wire with glass cleaner. The glass cleaner will make the
antenna wire slide through the support tube much easier.
❑ Check to ensure that the transmitter on/off switch is in the "OFF"
position.
❑ Check to ensure that the receiver on/off switch is in the "OFF" position.
IMPORTANT If you look closely, you'll notice that "On" and "Off" are
moulded into the switch mounting plate.
❑ Plug the connector on the Ni-Cd battery into the matching connector
in the boat.
INSTALLING THE ANTENNA SuPPORT TuBE
❑ Uncoil the receiver antenna wire and slide it into one end of the antenna
support tube and out the other end.
IMPORTANT Leave the excess antenna wire hanging from the top of the
tube. Under no circumstances should you cut the antenna wire shorter.
❑ Push the end of the antenna support tube firmly into the antenna support
tube mount.
