Tekmar 078 Installation And Operaion Manual

078 _ D

10/15

Universal Sensor 078

Accessories Replaces:04/09

Installation & Operation Manual

Introduction

The Universal Sensor 078 is a temperature sensor with a stiff jacketed cable,

making it a perfect choice for easy installation into conduit or domestic hot water

tank temperature wells. The sensor can also be strapped to a pipe to measure

supply or return temperatures.

Installation

Check the contents of this package. If any of the contents listed are missing or

damaged, please refer to the Limited Warranty and Product Return Procedure on

the back of this brochure and contact your wholesaler or tekmar sales representative

for assistance.

Type 078 includes • One Universal Sensor 078 • One Installation and Operation

Manual 078_D.

1 of 4

A Watts Water Technologies Company

078_D - 10/15

Table of Contents

Do you have a question about the 078 and is the answer not in the manual?

Page 1 Installation & Operation Manual Introduction The Universal Sensor 078 is a temperature sensor with a stiff jacketed cable, making it a perfect choice for easy installation into conduit or domestic hot water tank temperature wells. The sensor can also be strapped to a pipe to measure supply or return temperatures.
Page 2 Step Two - Mounting the Sensor The sensor is designed to mount on a pipe, in a temperature immersion well, or in a domestic hot water tank well. The Universal Sensor can be strapped directly to the pipe using the cable tie provided.
Page 3: Technical Data
17,46 15,11 1,474 11,88 10,501 9,299 8,250 Technical Data Universal Sensor 078 Literature 078_C, 078_D Packaged weight 0.5 lbs (160 g) Dimensions /8” OD x /4” (9.5 OD x 19 mm) Sensor material Brass sleeve, 15’ (4.6 m) 18 AWG, HDPE jacket, 00 V cable Operating range -40 to 221°F (-40 to 105°C)
Page 4 (24) months from the production date. The liability of tekmar under the Limited Warranty shall be limited to, at tekmar’s sole discretion: the cost of parts and labor provided by tekmar to repair defects in materials and / or workmanship of the defective product; or to the exchange of the defective product for a warranty replacement product;...
