- Page 1 DV-TV5100 DV-TV5100 TV/DVD COMBO...
- Page 2 *Your nearest Authorised TEAC Service Centre is listed in your Owners Manual In the event that this unit or any defective parts must be returned to TEAC Service Centres, a copy of this warranty certificate and of your purchase receipt must be enclosed to be a valid warranty. Such equipment or parts must be sent to the nearest authorised TEAC Service Centre.
- Page 3 Dealer’s Address Postcode Please ensure that your product is packed appropriately upon return to the service centre. If you have any other queries regarding service or warranty please contact the TEAC Service below: TEAC Total Care Ph: 1800 656 700 info@teac.com.au...
-
Page 4: Table Of Contents
Contents DVD Operations........Safety Precautions..........Installation............Play Discs ..........Pause Mode.......... Location of control ..........OSD............ Name and function of remote control ....DVD Menu Play........Battery installation..........Select with Number Button..... Operation of the whole machine......Turn ON/OFF power supply........Audio Mode...... -
Page 5: Safety And Precautions
Safety and Precautions T o a v o i d e l e c t r i c a l s h o c k , n e v e r s u b j e c t t h e T V s e t to rain or moisture. - Page 6 Safety and Precautions To ensure safe and reliable operation of the TV set, the following precautions must be observed in installation, operation and maintenance. Precautions 1. Pay attention to the power cord before installing the TV set. Do not attach anything on the power cord, and avoid treading on the power cord.
-
Page 7: Installation
Installation Instructions on installation Before installation, please first read carefully the relevant contents in Safety and Precautions . Please place the TV set inside a room where sunlight will not directly cast on the screen. Reflection on TV screen will cause eye fatigue. -
Page 8: Location Of Control
LOCATION OF CONTROLS Speaker Remote control receiving window Indicator Menu Button AV/ DVD Button DVD Play Button Open/Close Button Channel Button(P-) Channel Button(P+) 10. Volume Button(V ) 11. Volume Button(V ) 12. Main power switch 13. 75 ohm Antenna Socket 14. -
Page 9: Battery Installation
REMOTE CONTROL UNIT Open/Close Button Pal/NTSC Button Audio Button Angle Button DVD Numeric Buttons Resume Button Zoom Button A-B Button Repeat Button 10. Clear Button 11. Program Button 12. Stop Button 13. Fast Backward Button 14. TV Numeric Buttons 15. Three Digital Program Button 16. -
Page 10: Watching Tv Programs
Operation Turning the power ON/OFF 1.Press the power switch, the power indicator will turn on, and after several seconds, the TV set will start normal operation. 2.When the TV is operating, press the button on the remote controller to enter in standby mode. The power indicator will be on but there will be no sound or picture. -
Page 11: Search
Automatic search When you turn on the TV set for the first time, you must press the MENU button repeatedly in the front panel or in the remote controller, until the TUNING menu is displayed on the screen: Use P+ or P- buttons to select the AUTO STORE option (it turns from white to green). -
Page 12: Basic Operations: Picture And Sound Control
Basic Operation: Picture and sound control Mute The Mute function may be used when you want to eliminate any sound from the set. Press the MUTE button on the remote controller, and the screen will display the red characters MUTE. If you want to restore the sound, press the MUTE button once more. Automatic mute is ON during program switchover, during blue screen in TV and AV modes and during search mode. - Page 13 1.Select the TIMER ON option and enter the starting time as 19:00 for example. 2.Select the PROGRAM option and enter the program number 6 for example. 3.Select the TIMER OFF option and enter the ending time 22:30 for example. Press MENU to store values and leave this menu. Setting the Sleep time You can program your TV to switch automatically to standby mode after a fixed period of time.
-
Page 14: Advanced Operation
ADVANCED OPERATION Previous program Use the previous program button to recall the program being displayed immediately before the current one. Press twice to return to the same current program. Program order arrangement You can use the PROG. SWAP function button to rearrange the position of channels in memory, for example after performing an automatic search for tuning in programs. -
Page 15: Dvd Player Operation
DVD PLAYER OPERATION Basic Operation 1. Press "DVD" button on the front panel of the TV or the "AV " button on the remote controller to switchover to DVD play mode . 2. Press OPEN / CLOSE button to load disc in disc tray. 3. -
Page 16: Closed Captions
DIGITAL OUTPUT This is used to set the audio output. DOBLY SPDIF OFF GENERAL SETUP PAGE Set SPDIF to OFF to disable the digital audio output. Then sorround sound will TV DISPLAY be available. ANGLE MARK OSD LANGUAGE This surround sound format is output SPDIF OFF DIGITAL OUTPUT to a Dolby digital decoder through... -
Page 17: Video Setup
DYNAMIC This option is used to set the compression ratio in order to control the sound (volume) contrast. DOBLY DOLBY DIGITAL SETUP DUAL MONO FULL DYNAMIC SET DRC TO FULL 4.VIDEO SETUP SHARPNESS This option is used to adjust the sharpness DOBLY of the image. -
Page 18: Preference Setup
5.PREFERENCE SETUP DOBLY TV TYPE PREFERENCE PAGE This is selected when the player is TV TYPE connected to an PAL TV. AUDIO MULTI SUBTITLE NTSC DISC MENU MULTI PARENTAL The player will set the TV standard PASSWORD according to the disc in the tray. DEFAULT NTSC SET TV TYPE... -
Page 19: Parental
PARENTAL When playing a disc with parental lock function, you may select an age Control grade according to grade of disc and your own preference. DOBLY For example, if PG is selected, DVD Video disc rated higher than the PG grade cannot be played. PREFERENCE PAGE KID SAF KID SAF... -
Page 20: Dvd Operations
DVD Operations Play Discs 1. Press the OPEN/CLOSE button ( ) on the front panel and load the Disc on the tray. The label side should be facing upwards. For a Double-sided DVD Disc, put the disc with label A/1 up. 2. -
Page 21: Repeat A-B
Repeat A-B This function is applicable to DVD and CD aud io. User can specify the repeating interval by marking the starting point and the end point. 1. Press the REPEAT A-B button to mark the starting point (Playback will continue). 2. -
Page 22: Program Mode
Program Mode This function is appli cable to DVD and CD audio. User can assign the playback sequence according to his/her preference. For CD audio, user can assign the track sequence while for DVD disc, user can assign both the Title and Chapter sequence. PROGRAM:TRACK(01-08) 1. -
Page 23: Picture Cd
MP3 Operation This unit can support ISO9660 file system CD-ROM navigation. Multi-Media files such as MP3 thus can be played. 00:00 00:00 001/002 Operation . Insert the MP3 disc into the tray. Navigation Menu will be displayed. The menu will show up the files in the root directory, and the MP3 files will be played a utomatically. -
Page 24: Specifications
DVD characteristics and terminology DVD characteristics DVD discs are multi-purpose digital discs, on which high quality pictures and sound are recorded in digital signal mode using the latest image compression technology (MPEG-2) and high density recording technology. A DVD disc is in a structure of two 0.6cm thick discs bound together, to realize long time play with double sides.
