CORDLESS PIVOTING SCREWDRIVER KIT
Rotation:
Single speed:
Battery:
Charger input:
Charger output:
Battery charger:
Drive:
Weight:
Need Assistance?
Call us on our toll-free customer support line:
1-800-689-9928
Technical questions
Replacement parts
Parts missing from package
Imported by Mastercraft Canada Toronto, Canada M4S 2B8.
PRODUCT SPECIFICATIONS
Clockwise or counter clockwise
220 RPM (no load)
3.6V nickel-cadmium
120 V AC, 60 Hz, 8 W
6 V, 8 W300 mA
AC charging adaptor; 3–5 hours
¼" hex
14 oz (0.39 kg)
COMPACT
054-2502-6
Owner's Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MasterCraft 054-2502-6
Summary of Contents for MasterCraft 054-2502-6
- Page 1 AC charging adaptor; 3–5 hours Drive: ¼" hex Weight: 14 oz (0.39 kg) Need Assistance? Call us on our toll-free customer support line: 1-800-689-9928 Technical questions Replacement parts Parts missing from package Imported by Mastercraft Canada Toronto, Canada M4S 2B8.
-
Page 2: Power Tool Safety
POWER TOOL SAFETY When operating a power tool outdoors, use WARNING: Read all safety warnings an extension cord suitable for outdoor use. and instructions. Failure to follow the warnings Use of a cord suitable for outdoor use reduces and instructions may result in electric shock, fire the risk of electric shock. - Page 3 POWER TOOL SAFETY Personal safety – cont’d Hold power tool by insulated gripping surfaces, when performing an operation If devices are provided for the connection of where the fastener may contact hidden dust extraction and collection facilities, wiring or its own cord. Fasteners contacting a ensure these are connected and properly "live"...
-
Page 4: Specific Safety
BATTERY & CHARGER SPECIFIC SAFETY SAFETY WARNING: For safety reasons, do not plug in the charger, charge the battery or operate the tool until this Owner’s Manual WARNING: The nickel-cadmium battery is has been read and understood. an integral part of the tool. If it no longer charges properly or is damaged, the tool and Always use safety goggles or other suitable battery must not be discarded as household... - Page 5 BATTERY & CHARGER SAFETY Unplug the charger when not in use and before cleaning or maintenance. Do not abuse the cord. To reduce the risk of damage to the electric cord or plug, never carry the charger by the cord or yank the cord to unplug it.
- Page 6 SYMBOLS WARNING: Some of the following symbols may appear on the cordless screwdriver. Study these symbols and learn their meaning. Proper interpretation of these symbols will allow for more efficient and safer operation of this tool. Direct current Volts Amperes No load speed Alternating or direct Hertz...
- Page 7 KNOW YOUR PIVOTING SCREWDRIVER Pivoting handle release button Magnetic bit holder Charging LED Charger receptacle Rotation direction switch LED light Rotating LED light handle switch Trigger switch Charger plug Charger PIVOTING SCREWDRIVER COMPONENTS DESCRIPTION Cordless screwdriver Charger 2" (25 mm) Screwdriver bits: #1 &...
-
Page 8: Assembly And Operation
ASSEMBLY & OPERATION CHARGING THE BATTERY Place the cordless screwdriver near a 120 V, 60 Hz electrical outlet. Insert the battery charger plug (1) into the charger receptacle (2) in the handle of the cordless screwdriver (3) (Fig. 1). Plug the battery charger (4) into a 120 V 60 Hz wall receptacle. -
Page 9: Led Light
ASSEMBLY & OPERATION TRIGGER SWITCH – cont’d Clamp components that are to be screwed together in their desired position (Fig. 6). Drill a pilot hole (1) through the outer piece (2) and into the inner piece (3). Pilot hole drill bit should be 2/3 the diameter of the smooth portion of the screw shank. -
Page 10: Installing Screwdriver Bits
ASSEMBLY & OPERATION INSTALLING SCREWDRIVER BITS WARNING: Read "POWER TOOL WARNING: Never hold the screwdriver SAFETY", "SPECIFIC SAFETY RULES", with your fingers near the switch while "BATTERY & CHARGER SAFETY" and changing screwdriver bits. Accidentally "SYMBOLS" on pages 2 through 6 of this touching the switch may start the tool and manual before operating this cordless possibly cause an injury. - Page 11 ASSEMBLY & OPERATION DRIVING SCREWS – cont’d While holding the screwdriver firmly against the screw and the bit aligned with the screw, press the trigger switch to start the screwdriver and drive the screw. When the screw is driven to the correct depth, release the switch.
-
Page 12: Maintenance
MAINTENANCE GENERAL REPARATION FOR RECYCLING WARNING: To preserve our natural resources, please When servicing, use only recycle or dispose of battery-operated tools identical original equipment parts. Use of properly. any other part may create a hazard or cause product damage. This product contains nickel-cadmium batteries. -
Page 13: Nickel-Cadmium Battery Maintenance
MAINTENANCE HOW TO EXERCISE A NICKEL-CADMIUM NICKEL-CADMIUM BATTERY MAINTENANCE BATTERY NOTE: Nickel-cadmium and nickel-methyl Nickel-cadmium batteries are powerful, rugged and provide hundreds of charge/discharge hydride batteries have a self discharge rate of cycles if properly maintained and periodically approximately 1% per day. The self discharge "exercised". -
Page 14: Exploded View
EXPLODED VIEW... -
Page 15: Parts List
PARTS LIST ® WARNING: When servicing, use only Mastercraft replacement parts. The use of any other parts may create a safety hazard or cause damage to the cordless screwdriver. Any attempt to repair or replace electrical parts on this cordless screwdriver may create a safety hazard unless repairs are performed by a qualified technician. - Page 16 3-Year Limited Warranty This Mastercraft product is guaranteed for a period of 3 years from the date of original retail purchase against defects in workmanship and materials, except for the following components: Component A: Batteries, chargers and carrying case, which are guaranteed for a period of 2 years from the date of original retail purchase against defects in workmanship and materials;...
- Page 17 3-Year Limited Warranty – cont’d These warranties are subject to the following conditions and limitations: this warranty will not apply to any product or part thereof if any part from another manufacturer is installed therein or any repairs or alterations have been made or attempted by unauthorized persons; this warranty will not apply to normal deterioration of the exterior finish, such as, but not limited to, scratches, dents, paint chips, or to any corrosion or discolouring by heat, abrasive and chemical cleaners;...
