Cleaning & Maintenance
Warning: Before cleaning, please ensure that the power is
switched off by detaching the plug from the wall socket.
10.1 Clean the surface of hood every week with mild soap
or detergent . Avoid solvents, acid, alkali, scouring pads
or powders that could irreparably damage the stainless
steel surface.
10.2 The grease filters may be washed using mild soap,
detergent or degreasing agent.
10.3 Charcoal filters cannot be cleaned and must be gen-
erally replaced after 6 months of use.
PUM60X&PUM90X
RANGE HOOD
INSTRUCTION MANUAL
Thank you for your purchase of this product. Please read the
manual carefully before operating the appliance.
Advertisement
Related Manuals for Smeg PUM60X
Summary of Contents for Smeg PUM60X
- Page 1 Cleaning & Maintenance Warning: Before cleaning, please ensure that the power is PUM60X&PUM90X switched off by detaching the plug from the wall socket. RANGE HOOD 10.1 Clean the surface of hood every week with mild soap or detergent . Avoid solvents, acid, alkali, scouring pads...
-
Page 2: Installation Diagram
Installation Diagram Specifications PUM60X Power Supply 220V~240V 50Hz Rated Input Power 140W Lighting Power 2W×1 Motor Power 138W Outlet Diameter 150mm PUM90X Power Supply 220V~240V 50Hz Rated Input Power 142W Lighting Power 2W×2 Motor Power 138W Outlet Diameter 150mm... - Page 3 Electrical Diagram Contents PUM60X Introduction………………………….1 Features……………………………...2 Installation………………………..2 Charcoal filter (Optional)………….4 How To Use…………………………..5 Lamp Change……………………..…6 PUM90X Safety Information………………….7 Trouble Shooting………………..….8 Electrical Diagram……………..…..9 Specifications……………………….10 Cleaning & Maintenance………….11...
-
Page 4: Trouble Shooting
Introductio Trouble Shooting If any problem occurs, please detach the plug from the sock- 1.1 This appliance has been manufactured with materials et and contact the manufacturer or its service agent or a sim- and processes that respect the environment. We hope that ilarly qualified person in order to avoid a hazard. -
Page 5: Safety Information
Safety Information Features ◆ There must permanent & adequate ventilation of the room 2.1 This appliance is manufactured from top quality materials, when operating the range hood with appliances burning and offers superb streamlined effects. gas or other fuels. 2.2 With high suction power and low noise, it is designed to ◆... - Page 6 Lamp Change As with any maintenance on the appliance, first turn off the power supply by unplugging from the wall socket. 1.Remove the filters from the appliance. pic 5 pic 3 pic 2 pic 4 2.Unload the screws on the stainless steel hood panel. 3.Remove the stainless steel panel before changing the lamp 3.7 Ensure that the wall to be installed on is sufficiently (see pic 12).
-
Page 7: How To Use
How To Use Charcoal filter (Optional) The hood can be fitted with a charcoal filter which can make your kitchen cleaner. ) ) . Step 1. Take out the charcoal filter from the package.(see pic 6) ◆ Push Stop button, and the motor will stop. ◆...
