The FORZA 700 has evolved into a Speed Monster.
The finely honed form minimizes air resistance, and the forward tilting
rotor head helps transform all available power into speed.
Fly beyond limits with the FORZA 700 SPEED.
■ All new streamlined body
■ Newly-designed landing gear to greatly reduce air resistance
■ Blended front and rear fairings for smooth airflow
■ Large canopy ensures visibility at high speed
■ Super strong machined main drive gear and tail drive gear
■ All new large diameter aluminum hub supports oversize main gear for long life and efficient power transmission
FORZA 700 SPEED Specifications
Length
1,399 mm
Height
338 mm
Width
165 mm
Main rotor dia.
1,619 mm
Tail rotor dia.
262 mm
Gross weight
4,000 g ~ (not including battery)
Gear ratio
8.62：1：4.72
Main shaft dia.
12 mm
Tail output shaft dia.
6 mm
Control system
120° CCPM
Tail drive system
Shaft drive
FORZA 700 SPEED
No.88370
Supplemental manual
PLEASE READ THIS FIRST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FORZA 700 SPEED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JR ProPo FORZA 700 SPEED

Summary of Contents for JR ProPo FORZA 700 SPEED

  • Page 1 The FORZA 700 has evolved into a Speed Monster. The finely honed form minimizes air resistance, and the forward tilting rotor head helps transform all available power into speed. Fly beyond limits with the FORZA 700 SPEED. FORZA 700 SPEED No.88370...

  • Page 2: Table Of Contents

    ━━━【Removed and added parts list】━━━ The table below describes part changes for each assembly step. Removed parts from FORZA 700 Qty. Assembly procedure Added parts for FORZA 700 SPEED Qty. Pinion gear T11 Pinion gear T13 Bevel gear B T22...

  • Page 3: Pinion Gear T11

    ━━━【BEFORE COMMENCING ASSEMBLY】━━━ ● Standard FORZA 700 assembly manual - Page 2 to Page 7 - These steps are very important for assembling the FORZA 700 SPEED. Please carefully read and understand each step before commencing assembly. ● Standard FORZA 700 assembly manual - Page 5 Additional items required - The following items are required for the SPEED.

  • Page 4: Carbon Tray S

    SPEED MONSTER Assembly procedure 2-1 to 2-2 There is no change to the assembly method. Please refer to the standard FORZA 700 assembly manual. Assembly procedure 2-3 Body catch L21 has been changed to a body catch L23. 縮尺　1 There is no change to the assembly method. Please refer to the standard FORZA 700 assembly manual. Assembly procedure 2-4 Referring to the figure below install the carbon lower frame and the carbon tray S to the upper frame that has been previously assembled.

  • Page 5: Carbon Bottom Plate

    SPEED MONSTER 縮尺　1:5 2-5_SP_A Assembly procedure 2-5 First, refer to the upper figure and install the landing gear front, side plate, landing strut adapter and the cross member L60M4 to the frame. Note that the landing gear front and the carbon side plate have a left and right. Install so the countersunk holes are to the outside.

  • Page 6: Landing Gear Mount

    SPEED MONSTER 縮尺　1:5 2-6_SP Assembly procedure 2-6 Install the landing gear mount. Then install the landing gear rear. Carefully note the orientation for the landing gear rear. Nylon lock nut M3 (t2.8) (x 2) Button head bolt M3 x 6 (x 6) NEX650-507-00 (LandingGearMount) Landing gear rear (x 2) front...

  • Page 7: Hg Main Drive Gear T112

    SPEED MONSTER Assembly procedure 3-1 Referring to the figure, assemble the HG main drive gear and the HG tail drive gear. Autorotation sleeve Flat head bolt Shim washer HG main drive gear T112 M2.5 x 6 (x 8) 15 x 19 x 0.2 (x 2) * Use these shim washers to eliminate any play between the upper and...

  • Page 8: Body Absorber Plate

    縮尺　1:5 工程4-1_SP_A SPEED MONSTER Assembly procedure 4-1 There is no change to the installation method of the swash servos A, B and C. Please refer to the standard FORZA 700 assembly manual 4-1. Glue the edge protectors onto the four body absorber plate II using CA as shown in the figure. Install the servo horns and the joint ball screw then mount each servo to the helicopter.

  • Page 9: Rear Bevel Gear T22 Assembly

    There is no change to the assembly method. Please refer to the standard FORZA 700 assembly manual. Assembly procedure 5-8 Carbon vertical fin has been changed to a SPEED fin. Button head bolt M3 x 6 (x 2) Button head bolt M3 x 4 Socket head bolt M3 x 8 Carbon vertical fin (FORZA 700 SPEED)

  • Page 10: Body Clip

    Rubber grommet (x 2) Body clip 縮尺　1:5 6-3_SP_B Body clip plate Flat head bolt M3 x 10 (x 2) FRP front body (FORZA 700 SPEED) 縮尺　1:5 Snap pin 4mm (x 2) Carbon bottom plate Body clip Assembly procedure 6-4 There is no change to the assembly method. Please refer to the standard FORZA 700 assembly manual.
  • Page 11 SPEED MONSTER ━━━【ADJUSTMENT ・ OTHERS】━━━ ● Installation of battery and ESC Refer to the standard FORZA 700 assembly manual page 32 for battery mount and wiring. ● Gear ratio and rotor RPM setup The gear ratio is different from the standard FORZA 700. With this change, rotor RPM and flight time are also different from the standard FORZA 700 as shown in the table below.
  • Page 12 ━━━【Place to fly the Forza 700 SPEED】━━━ Because the flight speed is really fast (much faster than a standard model), the FORZA 700 Speed requires a large flying area. Please be sure to fly in a safe place where there is plenty of open area.
  • Page 13 SPEED MONSTER ━━━【PARTS LIST】━━━ Only the parts that are changed or added to the FORZA 700 SPEED are describe here. For unchanged parts, please refer to the standard FORZA 700 assembly manual. 62077 70788 62077 62078 62081 80171 80273 62076...

  • Page 14: Parts List

    SPEED MONSTER ━━━【PARTS LIST】━━━ 62072 62056 80263 80168 80205 70772 62059 62058 62078 62070 70733 80067 62074 62071 62075 80091 70786 70760 61997 80004 62073 62063 80263 Item # Description Qty. Note 61997 Pinion gear T13 80004 x 2 included 62056 Metal front bevel gear T22 assembly 80205 x 1 included...
  • Page 15 Qty. Note 60072 Rubber grommet 62082 Body clip set 80100 x 2 included 62083 Carbon vertical fin (FORZA 700 SPEED) 62084 Carbon tail rotor blade XB92 62088 Body absorber plate II Edge protector included 70789 Body catch L23 80262 x 2 included...
  • Page 16 Oct. 2015 FORZA 700 SPEED Supplemental manual Version 1 The product and the contents of these instructions are subject to change without notice due to improvement.
