  • Page 1 HD Radio Tuner HD Radio Tuner iPod ® (if equipped) Peripheral Electronics Peripheral Electronics ® ® a division of AAMP of America™ a division of AAMP of America™ 13160 56th Court Clearwater, Florida 33760 13160 56th Court Clearwater, Florida 33760 Ph.

  • Page 2: Table Of Contents

    Table of Contents Pages 1. Introduction 2. Precautions 3. Compatibility Notes 4. Programming the Media Gateway (PXAMG) 5. Installation 6. HD Radio Operation 6.1 Selecting HD Radio 7. iPod Operation 7.1 Selecting the iPod (if equipped) Controls Browse by Artist...
  • Page 3 Not Included LCD Retention Harness Part #: PGHFD1A* iPod Media Gateway Harness Not Included Part #: PGHFD1 Media Gateway PXAMG Part #: PXAMG Automotive Media Gateway 11Ft. iPod Cable 3Ft. HD Radio Cable HDRT HD Radio Tuner HD Radio Tuner...

  • Page 4: Introduction

    1. Introduction Thank you for purchasing the Peripheral Electronics Media Gateway. ® The Media Gateway is designed to provide endless hours of listening pleasure from your factory radio. To ensure that your HD Radio tuner or iPod performs correctly with your radio, we recommend that you read this entire manual before attempting installation of the Media Gateway.

  • Page 5: Compatibility Notes

    4. Programming the Media Gateway (PXAMG) The Media Gateway may need to be programmed before installation. To program the interface you will need to set the dip switches located on the side of the interface (see Fig. 1 below) to the proper configuration listed below.

  • Page 6: Installation

    Plug the black micro-fit 24-pin connector on the PGFD1 harness into the PXAMG Media Gateway box. 5. IMPORTANT NOTES for installation in 2008 Mercury Mariner, Ford Focus, or Ford Escape **** 2008 Mercury Mariner, 2008 Ford Focus, and 2008 Ford Escape will require the PGHFD1A harness.

  • Page 7: Installation

    8. To complete the installation secure the Media Gateway (PXAMG) and HD Radio tuner (HDRT) into the cavity in the dash behind the radio. Be sure that the cables and interface modules are not near moving parts or sharp metal edges as they may damage the cables.

  • Page 8: Hd Radio Operation

    6. HD Radio Operation 6.1 Selecting HD Radio Simply press and release the AUX or SAT button until “HD Radio” is displayed on the screen. ** When you press the AUX or SAT button, you will see the corresponding SAT mode (for example SAT 1), a slight delay, and then the current Media Gateway...

  • Page 9: Ipod Operation

    Displaying Text A. Radios equipped with the text/scan button: 1. Press the TEXT/SCAN button to display artist/song title information, if available. B. Radios not equipped with the TEXT/SCAN button: 1. Press the button located in the top right hand corner of the radio to display artist/song title information, if available.

  • Page 10: Browse By Artist

    Display Options Press the Preset # 4 remove button to switch between the song title information and the play counter. After using the fast-forward or rewind function, the radio will display the elapsed time of the song that is currently playing. Menu Down / Select Press and release the Preset # 2 remove button to make a selection or move down one folder in the menu.

  • Page 11: Browse By Album

    Once the desired album is displayed, Press Preset #2 to select the desired Album. The first song in the album will be displayed. “TR:” will be displayed in front of the song title to indicate that a “track” or song title is being displayed.

  • Page 12: Browse By Genre

    Browse by Genre Press Preset #2 to enter the browse menu. The word ”BROWSE” will appear on your display. You have entered the Browse menu. SEEK► ◄SEEK Press the button until Genre is displayed. “F” in front of the different Genres indicates that this is the folder of Genres.

  • Page 13: Browse By Playlist

    Browse by Playlist Press Preset #2 to enter the browse menu. The word ”BROWSE” will appear on your display. You have entered the Browse menu. SEEK► ◄SEEK Press the button until Playlist is displayed. “F:” in front of the different playlists indicates that this is the folder of the Playlists.

  • Page 14: Troubleshooting/Warranty

    10. Trouble Shooting Symptom Cause Remedy When I listen to Factory antenna Use Gateway to access HD Radio the factory AM or cable is connected source. This will provide all AM and FM radio there to the HD Radio FM reception for your vehicle. is only static, no tuner.

  • Page 15: Peripheral Electronics

    Within the first 12 months from date of purchase, subject to the conditions above, Peripheral Electronics will repair or replace the product at their discretion, if it is defective in material or workmanship providing it is returned to an Authorized Pe- ripheral Electronic’s Dealer, with PROOF OF PURCHASE from an authorized Pe-...
